REV. 4/6/2016 INST95-7811
INSTALLATION INSTRUCTIONS FOR PART 95-7811
METRA. The World’s best kits.metraonline.com © COPYRIGHT 2016 METRA ELECTRONICS CORPORATION
CAUTION!
All accessories, switches, climate controls panels,
and especially air bag indicator lights must be connected before
cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
ISO DDIN radio provision
95-7811B - Painted matte black
95-7811HG - Painted gloss black
A) Radio trim panel • B) Radio brackets • C) (4) #8 x 3/8” Phillips screws
20;-,(;<9,:
20;*64765,5;:
>0905.(5;,55(*655,*;065: (sold separately)
Wiring Harness: 70-1729
Antenna Adapter:40-HD11 • 40-HD12 (EX and higher)
Panel removal tool Phillips screwdriver
10mm socket wrench with extension
E-12 reverse (external) Torx socket
;663:9,8<09,+
Honda Pilot 2016-up
95-7811
A
Table of Contents
B C
Dash Disassembly ..............................................2-4
Kit Assembly .......................................................... 5
95-7811
2
Dash Disassembly
1. Open the passenger door and
remove the dash trim on the side
of the dash. (Figure A)
2. Open the glove box and remove
the dash trim above the opening.
(Figure B)
3. Open the driver’s door and remove
the dash trim on the side of the
dash. (Figure C)
Continued on the next page
(Figure A) (Figure B) (Figure C)
95-7811
3
Dash Disassembly
4. Unsnap and remove the panel
under the steering wheel.
(Figure D)
5. Unclip and remove the hazard/
airbag switch panel. (Figure E)
6. Remove (3) Phillips screws
securing the climate control trim
panel and then remove. (Figure F)
Continued on the next page
(Figure D) (Figure E) (Figure F
