INSTALLATION INSTRUCTIONS FOR PART 95-7895
95-7895
KIT FEATURES
DDIN Head Unit Provision
ISO Stacked Head Unit Provision
A) Double DIN Brackets B) Double DIN Trim Plate
KIT COMPONENTS
Small Flat Blade Screwdriver Panel Removal Tool
Phillips Screwdriver
1-800-221-0932
© COPYRIGHT 2007-2009 METRA ELECTRONICS CORPORATION
www.metraonline.com
TOOLS REQUIRED:
APPLICATIONS
Honda Accord
1998 - 2002
WIRING AND ANTENNA CONNECTIONS (Sold Separately)
Harness:
70-1721 - Honda Harness 1998-up
AB
Dash Disassembly
-Honda Accord 1998 - 2002. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Kit Assembly
- DDIN / Stacked ISO DIN Head Unit Provisions . . . . . . . . . . . . . . . . . . . . . . . . 2
TABLE OF CONTENTS
95-7895
*Note:
Refer also to the instructions included with the aftermarket radio.
K
NOWLEDGE IS
P
OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP certified
technicians.
95-7895 DASH DISASSEMBLY
HONDA ACCORD 1998 - 2002
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unsnap the clock panel, disconnect
the wiring and remove.
(Figure A)
2
Remove (1) Phillips screw exposed in
the clock cavity.
(Figure A)
3
Remove (2) Phillips screws below the
factory head unit.
(Figure A)
4
Unclip the radio trim bezel and dis-
connect the wiring.
5
Remove (4) Phillips screws securing
the factory head unit assembly and
disconnect the wiring.
6
Continue to kit assembly.
A
