INSTALLATION INSTRUCTIONS FOR PART 99-7952
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2004 METRA ELECTRONICS CORPORATION
KIT FEATURES
DIN head unit provision
ISO DIN head unit provision
A) Radio Housing l B) ISO Brackets | C) Trim Plate
KIT COMPONENTS
TOOLS REQUIRED:
99-7952
A
APPLICATIONS
2005-2007 Suzuki Aerio
Phillips Screwdriver I Small Flat Blade Screwdriver I Utility Knife
B C
Dash Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Kit Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2, 3
Final Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TABLE OF CONTENTS
99-7952
99-7952
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove the trim panels
from both sides of radio/climate
controls.
(Figure A)
2
2005-2007 SUZUKI AERIO
Remove (4) Phillips screws holding
radio to sub dash and remove radio.
(Figure B)
3
Remove (4) )Phillips screws securing
the radio and brackets to the factory
radio trim panel.
(Figure C)
4
DASH DISASSEMBLY
A
A/C AUTO
AUTO
OFF
75
65 85
PUSH
PUSH
PUSH
B
Rear View
C
