Sida 1/2
© COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION REV. 10/14/16 REV. 10/14/16
axxessinterfaces.com • metraonline.com axxessinterfaces.com • metraonline.com
Axxess Integrate
®Axxess Integrate
®
Installation Instructions for AX-NIS32SWC-6VInstallation Instructions for AX-NIS32SWC-6V
INTERFACE FEATURES
• Pre-wired ASWC-1 harness (ASWC-1 sold separately)
• Retains the factory backup camera to an aftermarket radio
• Includes the AX-CAM6V 12-volt to 6-volt converter
AX-NIS32SWC-6V
Nissan 2010-up(with 4.3" display radio)
INTERFACE COMPONENTS
AX-NIS32SWC-6V harness • AX-CAM6V 12-volt to 6-volt converter
APPLICATIONS
Wire cutter • Crimping tool Solder gun • Tape
• Connectors (example: butt connectors, bell caps, etc.)
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
NISSAN
Altima coupe 2010-2013*
Altima sedan 2010-2012*
Altima sedan 2013-up
Cube 2010*
Frontier 2013-up*
Juke 2015-up*
Murano 2015-up
Quest (without Bose)
2011-up*
Rogue 2011-2013*
Rogue 2014-up
Rogue Select 2014-2015*
Sentra 2010-up*
Titan 2013-2015*
Versa Note 2014-up*
* For use when retaining the OE backup camera only.
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Connections to be made
Connect the Black wire to chassis ground, and also to the wire of the Black
AX-CAM6V.
Connect the Red Blue/Red wire labeled "Camera Power 6V" to the wire
of the AX-CAM6V.
Connect the Green/Purple wire to the reverse wire of the aftermarket radio,
and also to the wire of the AX-CAM6V.Blue/White
Connect the Yellow RCA jack to the rear camera input of the aftermarket radio
.
12-pin pre-wired ASWC-1 harness:
For the Altima 2013-up / Rogue 2014-up only: sedan
This harness is to be used along with the optional ASWC-1 (not included) to
retain steering wheel audio controls. Please refer to the ASWC-1 instructions
for radio connections and programming.
Note: Disregard the harness that comes with the ASWC-1.
• Connect the unlabeled wire to the accessory wire.Red
