Installation instructions for part GMOS-13

REV. 4/3/2017 INSTGMOS-13

Axxess Integrate

CAUTION!

All accessories, switches, climate controls panels, and

especially air bag indicator lights must be connected before cycling

the ignition. Also, do not remove the factory radio with the key in the

on position, or while the vehicle is running.

• Provides accessory power (12-volt 10-amp)

• Retains R.A.P. (retained accessory power)

• Provides NAV outputs (parking brake,

reverse, speed sense)

• Retains chimes

• Pre-wired ASWC-1 harness

(ASWC-1 sold separately)

• Retains OnStar / OE Bluetooth

• Adjustable OnStar level

• Designed for amplified models

• Retains balance and fade

• USB-CAB (sold separately) updatable

INTERFACE FEATURES

• Wire cutter • Crimp tool • Solder gun • Tape

• Connectors (example: butt-connectors, bell caps, etc.)

• Small flat-blade screwdriver

TOOLS REQUIRED

GM Data Interface

2005-2011

APPLICATIONS

• GMOS-13 interface • GMOS-13 harness

• 16-pin harness with stripped leads

INTERFACE COMPONENTS

Connections to be made .........................................2

Installing the GMOS-13 ..........................................3

Initializing the GMOS-13.........................................3

Adjusting the GMOS-13 ..........................................3

Table of Contents

CADILLAC

STS 2005-2011

GMOS-13

Connections to be made

Attention! This vehicle comes equipped with a digital amplifier. Ensure that the factory

radio was removed with all settings in their default positions.

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the wire to the accessory wire.Red

Note: If installing an ASWC-1 (sold separately), there will be an accessory wire

there to connect as well.

• Connect the wire to the amp turn on wire. This wire must be Blue/White

connected to hear sound from the factory amplifier.

•

If the aftermarket radio has an illumination wire, connect the wire to it.Orange/White

• If the aftermarket radio has a mute wire, connect the wire to it. If the Brown

mute wire is not connected, the radio will turn off when OnStar is activated.

• Connect the wire to the right front positive speaker output.Gray

• Connect the wire to the right front negative speaker output.Gray/Black

• Connect the wire to the left front positive speaker output.White

• Connect the wire to the left front negative speaker output.White/Black

• Connect the wire to the left rear positive speaker output.Green

• Connect the wire to the left rear negative speaker output.Green/Black

• Connect the wire to the right rear positive speaker output.Purple

• Connect the wire to the right rear negative output.Purple/Black

The following (3) wires are only for multimedia/navigation radios that require these wires

• Connect the wire to the VSS/speed sense wire.Blue/Pink

• Connect the wire to the reverse wire.Green/Purple

• Connect the wire to the parking brake wire.Light Green

From the GMOS-13 harness to the aftermarket radio:

• Connect the wire to the ground wire.Black

• Connect the Yellow wire to the battery wire.

• Connect the wire to the power antenna wire.Blue

• The Black/Yellow wire is used for OnStar level adjustment for models that

do not come equipped with steering wheel controls. Refer to the OnStar level

Adjustment section for further instructions.

12-pin pre-wired ASWC-1 harness:

• This harness is to be used along with the optional ASWC-1 (not included) to

retain steering wheel audio controls. If the ASWC-1 is not being used, disregard

this harness. If it will be used, please refer to the ASWC-1 instructions for radio

connections and programming.

Note: Disregard the harness that comes with the ASWC-1.

• Connect the wire to the accessory wire.Red

GMOS-13

Installing the GMOS-13

With the key in the off position:

• Connect the 16-pin harness with stripped leads, and the GMOS-13 harness, into

the interface.

• Connect the GMOS-13 harness to the wiring harness in the vehicle.

Note: If using the ASWC-1, connect it after you initialize and test the GMOS-13,

with the key in the off position.

Initializing the GMOS-13

Attention! If the interface loses power for any reason, the following steps will need

to be performed again. Also, if installing an ASWC-1, connect it after you initialize

and test the interface/radio, with the key in the off position.

• Turn the key (or push-to-start button) to the ignition position and wait until the

radio comes on.

Note: If the radio does not come on within 60 seconds, turn the key to the

off position, disconnect the interface, check all connections, reconnect the

interface, and then try again.

• Turn the key to the off position, pause for a moment, and then to the accessory

position. Test all functions of the installation for proper operation, before

reassembling the dash.

Adjusting the GMOS-13

Audio level adjustment:

• With the vehicle and radio turned on, turn the volume up 3/4 of the way.

• With a small flat-blade screwdriver, adjust the potentiometer clockwise to

raise the audio level; counterclockwise to lower the audio level.

• Once at a desired level, audio level adjustment is complete.

Chime level adjustment:

• Refer to the vehicle owner’s manual to adjust the chimes.

OnStar Level Adjustment:

• Press the OnStar button to activate it.

• While OnStar is speaking, press the VOLUME UP or VOLUME DOWN button on

the steering wheel to raise or lower the OnStar level.

• If the vehicle does not come equipped with steering wheel controls, or they no

longer function, locate the Black/Yellow wire on the GMOS-13 harness.

•

While OnStar is speaking, tap the Black/Yellow wire to ground. Once the

OnStar level is set, it will stay at that level until the Black/Yellow wire is

tapped to ground again
