Sida 1/4
microphones & acoustic systems - founded 1928 by Georg Neumann
M I C R O T E C H G E F E L L
STUDIO CONDENSER
MICROPHONE
Extreme dynamic range
Noise floor 7 dB-A
Large diaphragm capsule
Polar pattern
Universal applications
Advanced circuit design
Transformerless output
Internal elastic suspension
Optical ready indicator
with
Phantom powering P 48 V
M 1030
STUDIO CONDENSER MICROPHONE
High output level and exceptionally low noise
M 1030 with cardioid directional pattern
The studio condenser microphone M 1030 combines modern large diaphragm capsule tech-
nology with the latest in semiconductor circuit topology. The size of the microphone housing
is optimized with regard to the expectations of a large diaphragm microphone for studio appli-
cations. The microphone is specifically designed to meet the needs of professional and semi-
professional users who demand the highest performance.
The microphones are ideally suited for universal miking applications in broadcast and sound
studios. Applications include vocalists, announcers, dialog pickup and as spot microphones for
recording guitars, keyboard, percussion, wind and string instruments.
The pick-up pattern is perpendicular to the direction of the microphone axis (side addressed).
The model number and pick-up pattern symbol mark the front of the microphone. The green
light-emitting diode (LED) inside the protection grid operates as optical ready indicator.
The condenser capsule exhibits a smooth frequency response with a slight presence boost in
the 8 to 14 kHz range. The polar response exhibits an exceptionally high degree of rejection for
sounds impinging from the rear of the microphone. The electronic impedance converter uses a
newly perfected circuit topology. This design reduces the noise floor to an extremely low level
while also raising the maximum output capability. As a result, this microphone have a clean, dis-
tortion free sound over an extremely wide dynamic range. RFI susceptibility is very low. The mic-
rophone capsule and electronics are elastically suspended inside the compact metal housing.
This reduces the sensitivity to mechanical impact and structure born noise. The microphone
stand holder MH 93.1 can be exchanged for an elastic suspension EA 92 with the adaptor A 93
to further attenuate noise in extreme situations. The M 1030 connect to the microphone cable
with a standard 3-pin XLR plug. Powering must be provided by an external 48 V phantom supply
according to IEC 61938.
The microphone is finished in satin nickel.
M 1030 satin nickel
DELIVERY
Microphone with M 1030
the microphone holder MH 93.1
in a wooden case
l x d x h 250 x 175 x 110 mm
satin nickel Order-No. 2111121
M 1030 with adaptor A 93 and elastic
suspension EA 92
M 1030 with adaptor A 93 and elastic
suspension EA 92
Windscreen, anthracite W 93 Order-No. 202415
Popscreen, black PO 70 Order-No. 600018
Elastic suspension, satin nickel EA 92 Order-No. 202312
Adaptor for EA 92, satin nickel A 93 Order-No. 202354
Connection cable, 3-pin XLR plug C 70.1 Order-No. 202212
ACCESSORIES optional
MOUNTING ASSEMBLING
