The M 900 and M 910 condenser microphones have been
developed for recordings of instrumental and vocal soloists in the
professional market. Its well balanced frequency response in the
free field as well as in the diffuse field and the appropriate distinct
characteristics ensure clean and colourless recordings of any
sound sources with good selectivity.
It is advisable to use the M 910 by soloists because it shows a
specially optimised frequency response for this kind application.
A distance of less than 8 to 12 inches, which is recommended as
minimum distance between lips and microphone, causes a
coloration with an emphasis of lower frequencies, the proximity
effect.
An acoustic filter integrated in the protective basket reduces the pop
sensitivity. The direction of maximum sensitivity is axial, i.e. endwise
to the microphone. This fact and the ergonomic design make these
microphone the right choice for live performance of soloists.
Following the modern trend of technique the transducer is equipped
with a gold plated polyester membrane.
The newly developed transformerless impedance transducer having
a balanced output stage guarantees a high output capability and low
intrinsic noise. Together with the good qualities of the microphone
capsule a higt brillance of the live performance is reached. A 10 dB
attenuator is installed to reduce the sensitivity of the microphone
when placed near extremely loud sound sources. And a low
frequency roll-off switch will reduce the proximity effect when close
miking. The two switches are sunk placed in the middle of the
amplifier.
At the lower end of the amplifier the microphone is equipped with a
3-pin XLR connector fitting to the microphone cable C 70. These
microphones use 48 volt phantom powering according to the
international standards DIN 45596 and ICE 26815.
large diameter pressure gradient transducer
M 900 with cardioid polar pattern
M 910 with hypercardioid polar pattern
Studio Condenser Microphones for extraordinary
demands with a future oriented design
M 900 M 910
Delivery
Microphone M 900 in wooden case L x B x H
Order-No. 211140
275 x 90 x 70 mm
dark bronze
Microphone M 910 in wooden case L x B x H
Order-No. 211141
275 x 90 x 70 mm
dark bronze
M I C R OT E C H G E F E L L
F Ü R S T U D I O - U N D M E S S T E C H N I K
K O N D E N S A T O R M I K R O F O N E
SEIT 1928
MICROTECH GEFELL GMBH GEORG NEUMANN PLATZ D-07926 GEFELL TEL. ++49 (0)36649 / 882-0 FAX ++49 ( 36649 / 882 11- - 0)
INTERNET http://www.microtechgefell.de e-mail info@microtechgefell.de
Frequency responses M 900
20 50 100 200 500 1000 2000 5000 10000 20000 Hz
- 20
- 10
0
+10
dB
0°
180°
20 50 100 200 500 1000 2000 5000 10000 20000 Hz
- 20
- 10
0
+10
dB
0°
135°
30°
60°
150°
180°
210°
240°
300°
330°
0°
0
-10
-20
dB
270° 90°
120°
4 kHz
10 kHz
30°
60°
150°
180°
210°
240°
300°
330°
0°
0
-10
-20
dB
270° 90°
120°
125 Hz
1 kHz
4 kHz
10 kHz
125 Hz
1 kHz
hypercardioid
Pressure gradient transducer
40 ... 18000 Hz
14 mV/Pa
-10 dB
150 Ω
22 dB
15 dB - A
72 dB
79 dB
135 dB
145 dB
120 dB
3 mA
229 g
218 mm x 47/28 mm
Polar patterns
Acoustical operating principle
Frequency range
Sensitivity at 1 kHz
Switch position "reduced bass roll-off" at 90 Hz
Equivalent loudness level CCIR 468-4
DIN EN 60 651
CCIR-weighted
(re. 1 Pa at 1 kHz) A-weighted
Max. SPL for THD 0,5 %≤
with 10 dB preattenuation
Total dynamic range of the microphone amplifier
Current consumption (P 48, DIN 45596, IEC 268-15)
Output connector
Weight
Dimensions (L x )∅
Specifications M 900 M 910
Certifikate
Transformerless Studio Condenser Microphone
Rated impedance
Signal-to-noise-ratio
3-pin XLR connector
goldplated contacts
dark bronzeFinish
cardioid
40 ... 18000 Hz
17 mV/Pa
-10 dB
150 Ω
21 dB
13 dB - A
73 dB
81 dB
133 dB
143 dB
120 dB
3 mA
229 g
218 mm x 47/28 mm
dark bronze
Windscreen, anthrazite Order-No.
, black Order-No. 600018
Clamp, black Order-No. 600014
Order-No. 202314
anthracite Order-No. 600004
Table stand, Order-No. 212306
Table stand for 2 microphones Order-No. 202309
with Double mount, Order-No. 202332
Power supply Order-No. 202101
Order-No. 202212
202403
Popscreen
Elastic suspension, dark bronze
Elastic suspension,
dark bronze
dark bronze
Connection cable
W 90
PO 70
MKV 8
AT 8410 a
N 200
C 70
EA 90
TS 90
TS 68
TD 93
Accessories, optional
only for delivered by MTG
due to inherent noise
Frequency responses M 910
