RouterBOARD 953GS-5HnT
Quick Setup Guide and Warranty Information
The RB953 is equipped with three Gigabit Ethernet ports, two SFP cages and two miniPCI slots. It also has a built-
in 5GHz wireless device with three-chain support (three antenna connectors).
Assembling the Hardware
First use of the board:
1. Insert the miniPCI cards
2. Install the board in a case and connect antenna cables
3. Connect other peripherals and cables
4. Plug in PoE powered Ethernet to turn on the board
The device comes with a thermal pad, which is located inside a small bag. This thermal pad will ensure heat
transfer between the backside of RB953 wireless device heatsink, and the indoor or outdoor case, where it will be
mounted. The thermal pad should be put on the rectangular area of the RB953 heatsink, so that it is pressing
against the device case, when it is mounted.
Powering
It’s possible to power the device with the following methods:
The first Ethernet port (Ether1) accepts 8-30V DC input (at the board; higher voltage needed to compensate
for power loss on long cables; at least 18V suggested) from non-standard (passive) Power over Ethernet
injectors. This device does work with IEEE802.3af compliant 48V power injectors. not
DC power jack which accepts 8-30V (5.5mm outside and 2mm inside diameter, female, pin positive plug)
Booting process
RouterOS is the operating system of all RouterBOARD routers. Please see detailed configuration guide
here: http://wiki.mikrotik.com/wiki/Category:Manual
First, RouterBOOT loader is started. It displays some useful information on the onboard RS232C asynchronous
serial port. The serial port is set by default to 115200bit/s, 8 data bits, 1 stop bit, no parity.
The RouterOS system will then load. It will be also indicated by two beeps. Winbox or a web browser should be
used to connect to the default IP address of with the username and .192.168.88.1 admin no password
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of
the device when starting it until the LED light turns off, and it will start to look for Netinstall servers.
In case IP connection is not available, Winbox can also be used to connect to the MAC address of the device. More
information here: http://wiki.mikrotik.com/wiki/First_time_startup
See for more information. Contact www.routerboard.com support@mikrotik.com for support questions. 10/07/17
Extension Slots and Ports
Three 10/100/1000 Gigabit Ethernet ports, supporting automatic cross/straight cable correction (Auto
MDI/X), so you can use either straight or cross-over cables for connecting to other network devices. The
first Ethernet port accepts 8-30V DC powering from a passive PoE injector. The other two Ethernet ports
do not support PoE powering.
Two miniPCIe slots for wireless or 3G card (SIM slot will be used for 3G)
Three SMA connectors on top of the board, connected to the built-in three chain radio. Connectors are for
chains 0,1,2 in that order, from left to right (chain0 is next to the USB port).
Two SFP cages (Supports 1.25G SFP modules, supports DDMI)
One powered USB 2.0 port, cannot be used simultaneously with J404 miniPCIe slot for 3G modem
(software selectable USB/miniPCIe)
One 8-30V DC power jack
Two fan headers, for connecting an optional cooling fan, same Voltage as DC jack input
Buttons
Bootloader backup button (Reset 1). Holding the button while booting will cause the backup bootloader to
be used
RouterOS reset hole (While booting, and holding a metal object in this hole (for example a screwdriver) will
cause RouterOS software to be reset to defaults
Operating System Support
Currently tested operating system is MikroTik RouterOS (starting from v6).
Copyright and Warranty information
Copyright MikroTikls SIA. This document contains information protected by copyright law. No part of it may be
reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD,
RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks
appearing in this document are the property of their respective holders.
Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the
shipping date to be free of defects in materials and workmanship under normal use and service, except in case of
damage caused by mechanical, electrical or other accidental or intended damages caused by improper use or due
to wind, rain, fire or other acts of nature.
To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization)
procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA
process.
1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company
regarding all warranty and repair issues, the following instructions apply ONLY if you purchased your
equipment directly from MikroTik in Latvia.
2. MikroTik does not offer repairs for products that are not covered by warranty. Exceptions can be made for:
CCR1016-12G, CCR1016-12G-BU, CCR1036-12G-4S, RB1100, RB1100AH, RB1100AHx2, RB1200,
RB600, RB600A and RB800 as a paid service (fees apply).
3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotik will be returned to the sender
at sender's cost. If the customer has not organized return of such rejected devices within 12 months from
the day of arrival, MikroTik has the right to discard them.
RMA Instructions are located on our webpage here: http://rma.mikrotik.com
See for more information. Contact www.routerboard.com support@mikrotik.com for support questions. 10/07/17
This document is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to,
the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every
effort to ensure the accuracy of the contents of this document, however, it is possible that it may contain technical
inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found in this publication, nor
for direct or indirect, incidental, consequential or other damages that may result from such an inaccuracy, including,
but not limited to, loss of data or profits. Please report any inaccuracies found to support@mikrotik.com
Federal Communication Commission Interference Statement
(FCC ID: TV7RB953GS5HNTM)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. This device and its antenna must not be co-located or operation
in conjunction with any other antenna or transmitter.
IMPORTANT: Exposure to Radio Frequency Radiation.
3.3 m minimum distance has to be maintained between the antenna and general public. Under such configuration,
the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied.
List of additional approved antennas:
8.5 dBi Omni MTI Wireless MT-482016NA
24 dBi Panel Pacific Wireless PA58-24
32 dBi Dish Pacific Wireless HDDA5W-32-DP
Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the authorized antennas in
the United States (or where FCC rules apply); only those antennas certified with the product are used. The use of
any antenna other than those certified with the product is expressly forbidden in accordance to FCC rules CFR47
part 15.204. The installer should configure the output power level of antennas, according to country regulations and
per antenna type. Professional installation is required of equipment with connectors to ensure compliance with
health and safety issues.
See for more information. Contact www.routerboard.com support@mikrotik.com for support questions. 10/07/17
