Sida 1/6
■ ModelEncoding
■ Description
■ ■ Features Applications
File Na me:LPF -60- SPE C 2017-04-14
60W Constant Voltage + Constant Current LED Driver L P F - 6 0 s e r i e s
‧LEDpanellighting
‧LEDdownlight
‧LEDdecorativelighting
‧LEDtunnellighting
‧Movingsign
LPF-60seriesisa60WAC/DCLEDdriverfeaturingthedualmodesconstantvoltageand
constantcurrentoutput.LPF-60operatesfrom90 305VACandoffersmodelswithdifferent～
ratedvoltagerangingbetween12Vand54V.Thankstothehignefficiencyupto90%,with
thefanlessdesign,theentireseriesisabletooperatefor-40 ~+80 casetemperatureunder℃ ℃
freeairconvection.TheentireseriesisratedwithIP67ingressprotectionlevelandissuitable
toworkforavarietyofapplicationsatdry,damporwetlocations.
- 20LPF - 60
Ratedoutputvoltage(12V/15V/20V/24V/30V/36V/42V/48V/54V)
Ratedwattage
Seriesname
‧ConstantVoltage+ConstantCurrentmodeoutput
‧PlastichousingwithClassIIdesign
‧Built-inactivePFCfunction
‧Class2powerunit
‧FullyencapsulatedwithIP67level
‧Typicallifetime>50000hours
‧5yearswarranty
IP67
F M M
110 SELV
(for48V,54Vonly) (exceptfor48V,54V)
LP F - 60 s e r i e s
SPECIFICATION
MODEL
OUTPUT
VOLTAGE RANGE Note.5
FREQUENCY RANGE
POWER FACTOR
EFFICIENCY (Typ.)
AC CURRENT
INPUT
INRUSH CURRENT(Typ.)
LEAKAGE CURRENT
EMC IMMUNITY
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
MTBF
DIMENSIONOTHERS
NOTE
PACKING
OVER TEMPERATURE
OVER VOLTAGE
47 ~ 63Hz
<0.75mA / 240VAC
Compliance to EN55015,EN61000-3-2 Class C (@load 60%) ; EN61000-3-3≧
20 ~ 95% RH non-condensing
-40 ~ +80 , 10 ~ 95% RH℃
± ℃ ℃0.03%/ (0 ~ 50 )
10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes
440.5Khrs min. MIL-HDBK-217F (25 )℃
ENVIRONMENT
EMC EMISSION Note.8
SAFETY &
EMC
PROTECTION
SHORT CIRCUIT
I/P-O/P:3.75KVAC
I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH℃
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
TOTAL HARMONIC DISTORTION
DC VOLTAGE
RATED CURRENT
RATED POWER Note.5
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME Note.6
HOLD UP TIME (Typ.)
RIPPLE & NOISE (max.) Note.3
VOLTAGE TOLERANCE Note.4
CONSTANT CURRENT REGION Note.2
OVER CURRENT
SAFETY STANDARDS Note.8
COLD START 55A(twidth=270 s measured at 50% Ipeak) at 230VACμ; Per NEMA 410
MAX. No. of PSUs on 16A
CIRCUIT BREAKER 8 units (circuit breaker of type B) / 14 units (circuit breaker of type C) at 230VAC
MAX. CASE TEMP. Tcase=+80℃
Compliance to EN61000-4-2,3,4,5,6,8,11; EN61547, light industry level (surge immunity Line-Line 2KV)
(Please refer to "STATIC CHARACTERISTIC" section)
90 ~ 305VAC 127 ~ 431VDC
1.AllparametersNOTspeciallymentionedaremeasuredat230VACinput,ratedcurrentand25 ofambienttemperature.℃
2.Pleasereferto"DRIVINGMETHODSOFLEDMODULE".
3.Ripple&noisearemeasuredat20MHzofbandwidthbyusinga12"twistedpair-wireterminatedwitha0.1uf&47ufparallelcapacitor.
4.Tolerance:includessetuptolerance,lineregulationandloadregulation.
5.De-ratingmaybeneededunderlowinputvoltages.Pleasereferto“STATICCHARACTERISTIC”sectionsfordetails.
6.Lengthofsetuptimeismeasuredatfirstcoldstart.TurningON/OFFthedrivermayleadtoincreaseofthesetuptime.
7.Thedriverisconsideredasacomponentthatwillbeoperatedincombinationwithfinalequipment.SinceEMCperformancewillbeaffectedbythe
completeinstallation,thefinalequipmentmanufacturersmustre-qualifyEMCDirectiveonthecompleteinstallationagain.
8.ThemodelcertifiedforCCC(GB19510.14,GB19510.1,GB17743andGB17625.1)isanoptionalmodel.PleasecontactMEANWELLfordetails.
9.To fulfill requirements of the latest ErP regulation for lighting fixtures this LED driver can only be used behind a switch ,
without permanently connected to the mains .
10.Thisseriesmeetsthetypicallifeexpectancyof>50,000hoursofoperationwhenTcase,particularlytcpoint(orTMP,perDLC),isabout70 orless.℃
11.PleaserefertothewarrantystatementonMEANWELL'swebsiteathttp://www.meanwell.com
60W Constant Voltage + Constant Current LED Driver
95 ~ 108%
Hiccup mode, recovers automatically after fault condition is removed
Constant current limiting, recovers automatically after fault condition is removed
PF 0.97/115VAC, PF 0.95/230VAC, PF 0.92/277VAC@full load≧ ≧ ≧
(Please refer to "POWER FACTOR (PF) CHARACTERISTIC" section)
THD< 20%(@load 60%/115VC,230VAC; @load 75%/277VAC)≧ ≧
(Please refer to “TOTAL HARMONIC DISTORTION(THD)” section)
Tcase=-40 ~ +80 (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)℃
Shut down and latch off o/p voltage, re-power on to recover
Shut down o/p voltage, re-power on to recover
12V
7.2 ~12V
15V
9 ~ 15V
20V
12 ~ 20V
24V
14.4 ~ 24V
30V
18 ~ 30V
36V
21.6 ~ 36V
48V
28.8 ~ 48V
5A 4A 3A 2.5A 2A 1.67A 1.25A
60W 60W 60W 60W 60W 60.12W 60W
150mVp-p 150mVp-p 150mVp-p 150mVp-p 200mVp-p 250mVp-p 250mVp-p
±±±±±4.0% 4.0% 4.0% 4.0% 4.0% ±4.0% ±4.0%
±±±±±0.5% 0.5% 0.5% 0.5% 0.5% ±0.5% ±0.5%
±±±±±2.0% 1.5% 1.0% 0.5% 0.5% ±0.5% ±0.5%
54V
32.4 ~ 54V
1.12A
60.48W
350mVp-p
±4.0%
±0.5%
±0.5%
42V
25.2 ~ 42V
1.43A
60.06W
250mVp-p
±4.0%
±0.5%
±0.5%
LPF-60-12 LPF-60-15 LPF-60-20 LPF-60-24 LPF-60-30 LPF-60-36 LPF-60-42 LPF-60-48 LPF-60-54
1000ms, 80ms / 115VAC 500ms, 80ms / 230VAC
16ms/230VAC 16ms/115VAC
86% 87% 88% 89% 90% 90% 90%90% 90%
0.8A / 115VAC 0.4A / 230VAC 0.32A/277VAC
15 ~ 17V 17.5 ~ 21V 23 ~ 27V 28 ~ 35V 34 ~ 40V 41 ~ 49V 54 ~ 63V46 ~ 54V 59 ~ 66V
UL8750, CSA C22.2 No. 250.0-08(except for 48V, 54V), ENEC EN61347-1, EN61347-2-13 independent, EN62384, IP67,
J61347-1, J61347-2-13 approved ; design refer to UL60950-1, TUV EN60950-1
162.5*43*32mm (L*W*H)
0.45Kg; 32pcs/15.4Kg/0.93CUFT
Fil e Na m e:LPF-6 0-S PEC 20 1 7-04-14
L P F - 6 0 s e r i e s
BLOCK DIAGRAM
fosc : 100KHz
60W Constant Voltage + Constant Current LED Driver
※ This series is able to work in either Constant Current mode (a direct drive way) or
Constant Voltage mode (usually through additional DC/DC driver) to drive the LEDs.
DRIVING METHODS OF LED MODULE
Typical output current normalized by rated current (%)
In the constant current region, the highest voltage at the output of the driver
depends on the configuration of the end systems.
Should there be any compatibility issues, please contact MEAN WELL.
100
60
(min.)
Vo(%)
50 100 Io(%)
(B)
Constant
Current area
(C)
Hiccup
Protection
(A)
Constant
V areaoltage
DETECTION
PWM & PFC CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS +V
-V
I/P
CONTROL
O.V.P.
&
O.L.P.
PFC
CIRCUIT
Fil e Na m e:LPF-6 0-S PEC 20 17-04-14
