Sida 1/1
Installing batteries
1. Remove the battery compartment door by applying thumb pressure to area indicated
on battery door and then lift the door out and off the cabinet.
2. Before inserting the batteries, observe the polarities (+ and -) of the battery, then
relate the polarities to the engraved diagram inside the battery compartment. Install
4xD/R20/UM1 size batteries to battery compartment.
3. Replace the compartment door.
Battery precautions
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the
battery compartment. Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline an Carbon-Zinc) or old
batteries with fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to
prevent damage or injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can over heat
and rupture.
6. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
GB - 1
GB - 2 GB - 3
LOCATION OF CONTROLS AND INDICATORS
POWER SUPPLY
Note:
- The AC cord must be unplugged from both the jack on the unit and the power outlet
for the unit to run on the batteries.
- When the AC cord is connected from the main unit to the power outlet, the power
source automatically switches to AC. You may leave the batteries inside the unit if
you wish. There is no battery consumption when the AC cord is connected to a
power outlet and/or the the unit.
Connecting power cord
1. Connect the detachable AC cord (included) to the AC socket on the rear of the unit.
2. Plug the power cord into 230V~50Hz AC outlet.
CONNECTING THE AUX
4-BAND PORTABLE RADIO
User Manual
PLEASE READ THE INSTRUCTION CAREFULLY
BEFORE OPERATING THE UNIT
1. Slide ON/OFF (2) to switch on the unit.
2. Slide the BAND button (5) to switch to the desired broadcast band
(FM/SW/LW/MW).
3. Turn the TUNING knob (6) to select a station.
4. Adjust the volume level by the VOLUME knob (1).
5. You may lengthen the antenna located at the top of the unit for better reception of
SW/FM stations. For LWor MW stations, you may try rotating the unit to get better
reception.
6. Slide ON/OFF button (2) again to switch off the radio.
RADIO OPERATION
Connect the earphones ( not included) to the earphone jack on unit.
LISTENING WITH EARPHONES
Connect your auxiliary source (e.g. mp3 player) to the AUX input jack on the top side
of the unit, the unit will change to AUX function automatically.
TECHNICAL SPECIFICATION
POWER SUPPLY :
RADIO :
POWER CONSUMPTION:
OUTPUT POWER:
UNIT DIMENSION:
N.W:
SAFETY INFORMATION
•
•
•
•
•
•
•
•
•
•
If at any time in the future you should need to dispose of this product please note
that Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer
for recycling advice. (Waste Electrical and Electronic Equipment Directive)
In full power, the continuous listening of the player may damage the user’s
hearing.
AC 230V 50 Hz
DC 6V 4 x D / R20 SIZE (not included)
FM: 88 - 108 MHz
SW: 6.0 - 18MHz
LW: 150 - 280 KHz
MW: 540 - 1600KHz
4W
800mW
180 (H)x92 (W)258 (L) mm
0.9 KG APPROXIMATELY
Before throwing any batteries away, consult your distributor who may be able to
take them back for specific recycling.
M-052R
The ventilation should not be impeded by covering the ventilation openings with items
such as newspapers, table-cloths, curtains, etc.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
The use of apparatus in moderate climates.
The apparatus should not be exposed to dripping or splashing.
Ensure a minimum distance of 5cm around the apparatus for sufficient ventilation.
Do not place objects filled with liquids, such as vases, on the apparatus.
Excessive sound pressure from earphones and headphones can cause hearing loss.
The marking plate is located on the botton of unit.
Mains plug is used as the disconnect device and it shall remain readily operable. To be
completely disconnected the power input, the mains plug of the apparatus shall be
disconnected from the mains completely. The mains plug should not be obstructed or
should be easily accessed during intended use.
Under the influence of electrical fast transient or/and electrostatic phenomenon, the
product may malfunction and require user to power reset.
VOLUME Knob
ON/OFF Button
Phone Jack
AUX IN Jack
BAND (FM/SW/LW/MW) Selector Switch
TUNING Knob
1.
2.
3.
4.
5.
6.
Dial Pointer
Speaker
Carrying Handle
FM Telescopic Antenna
AC Cord Jack
Battery Compartment
7.
8.
9.
10.
11.
12.
R-2161 IB MUSE 001 REV0 - GB.P65 2009-11-3, 10:481
