Sida 1/6
GB
User Manual
PORTABLE RADIO CD PLAYER
RD306/ RD306BL/ RD306R/ RD306W
Read the instructions carefully before operating the unit.
LOCATION AND DESCRIPTION OF CONTROLS
1. LED display
2. indicator ON
3. Program indicator (PROG.)
GB
4. Repeat indicator (REP.)
5. Play/ Pause indicator
6. Speakers
7. SKIP button
8. SKIP button
9. PLAY/ PAUSE button
10. STOP button
11. PROGRAM button (PROG.)
12. REPEAT button (REP.)
13. CD compartment
14. Carrying handle
15. FM telescopic antenna
16. AUX IN jack
17. Function selector (CD/AUX, RADIO, Unit ON/OFF)
18. Volume control
19. TUNING knob with dial scale
20. Dial pointer
21 Band selector ( ) . FM/MW
22. Battery compartment
23. AC socket (~ AC IN)
POWER SUPPLY
This set operates on AC 230V~ 50Hz or 6 x 1.5V R14/ UM- size batteries (not provided). 2/ “C”
AC OPERATION
Connect the detachable AC cord (included) to the AC socket on the rear of the unit. Insert the AC power cord into a
convenient standard AC wall outlet.
DC OPERATION
Install the batteries in their compartment. Use only the size and type of batteries specied. Respect the polarity
indicated in the compartment. Improper polarity can cause damage to the device. Do not attempt to recharge the
batteries, they can catch re or explode. The batteries need to be replaced when: The volume decreases, or sound is
distorted during operation. In order to avoid leakage, remove the batteries when unit will not be used for a long period
of time.
CAUTION: Danger of explosion if batteries are incorrectly replaced. Replace only with the same or equivalent type.
Note:
-The AC cord must be unplugged from both the socket on the unit and the power outlet for the unit to run on the
batteries.
- When the set is connected to the mains, the power source automatically switches to AC.
- In a concern of saving energy, when playback has reached to the end or not playing, the unit will automatically turn
off after minutes. To reset the unit, slide the Function switch to OFF position. Wait a few seconds and then turn 10
ON the unit again.
GB
TURNING UNIT ON/OFF
1 Slide the Function switch to or . CD/AUX RADIO position to turn on the unit. The ON indicator will light up.
2. Slide the Function switch to position to turn off the unit. The ON indicator will turn off. OFF
LISTENING TO THE RADIO
1. Slide the Function switch to position. RADIO
2. Slide the Band switch to select between FM and MW band.
3. Use the TUNING control to tune to your desired radio station.
4. Adjust the volume level.
To enhance radio reception ability:
FM: Extend the telescopic antenna.
MW: Rotate the unit horizontally for optimum reception.
LISTENING CD TO
1. Slide the function switch to CD/AUX position. The ON indicator will light up.
2. Open the CD door. Insert a CD with label facing up and close the CD door. After few seconds, the total number a
of tracks will show on display.
3. Press to start playback. The current track number will show on display. The indicator will light up.
PLAY/PAUSE
To temporarily stop playing, press button. The indicator will ash.
To resume play, press this button again.
STOP
If the button is pressed in the course of playing, the disc will cease to play. (Total number of tracks will show on
display).
SKIP AND SEARCH
You can always skip forward or backward to your desired track number by pressing the SKIP( / ) buttons. When
playing any audio CD, press and hold the SKIP button. The CD will search at high speed in the forward or backward
direction. Normal play will continue when you release the button.
REPEAT
To repeat the track currently playing, press the REP. button once. The repeat indicator will ash.
To repeat all tracks, press the REP. button twice. The REPEAT indicator will light up and stay lit.
To cancel the repeat function, press REP. button again. The repeat indictor will turn off.
PROGRAM
1. In stop mode, press PROG button. ash on display. “01“ will
2. Press / to select a desired track and press PROG button to conform. The program indicator will ash in the
course of programming.
3. Repeat above steps to program up to tracks. 20
4. Press button to start program playback. The program indicator will light up and stay lit.
5. To cancel program playback, press button twice. The program indicator will turn o.

Produktspecifikationer

Varumärke: Muse
Kategori: Radio
Modell: RD306
