产品特性
·轻巧便携式小头灯
·多种色温可选
·NU20：高性能CREE XP-G2 S3 LED
·NU20 CRI：日亚219B LED，CRI≥90
·内置可充电锂电池，续航时间长达100小时
·自带智能锂电池充电电路（Micro-USB通
用充电接口）
·单键开关设计，单手即可操作
·开关按钮内藏电量指示灯，可以提示电池
剩余电量（受专利保护：
ZL201220057767.4）
·设有4种亮度和2种特殊功能可选
·独特的按键保护灯架设计，可保护按键，
防止头灯误触发
·橘皮反光杯照明设计
·52°照明角度调节
·灯体采用PC材料制造，坚固耐用
·超轻设计，方便携带
·1.5米防摔能力
体积
尺寸：55.5mm×33mm×21mm（含支架）
重量：47克（含电池）
配件
USB线，头灯带，支架
·1·
·3·
广州希脉创新科技有限公司
咨询热线：+86-20-83862000
销售邮箱：info@nitecore.com
网 址：www.nitecore.cn
地 址：广东省广州市天河区高普路1021号5楼6355号
邮 编：510653
NU06062022
更多信息请关注新浪微博：
NITECORE奈特科尔
NU20/NU20 CRI
使用说明书
头灯
亮度&时间
· ·2
®
奈特科尔—全能照明专家
注:以上数据按照国际手电筒测量标准
ANSI/NEMA FL1所述之测量方法，所使用
电池为：内置锂电池（3.7V 600mAh）。不
同使用环境可能会对以上数据产生影响。
*超高亮档位续航时间为理论数值。
使用头灯
开启/关闭
亮度调节
在头灯处于点亮状态的3秒内，连续按下开关按钮，头灯将按“超低亮-中亮-高亮-待机”顺序切
换。3秒内不进行任何操作，再按下开关按钮，头灯关闭。
开启超高亮
在头灯开启状态下，长按开关按钮1秒以上，头灯直接开启超高亮档位（360流明/270流明）。
注：在超高亮状态下工作30秒后，头灯将降低亮度以防止内部温度过热。
使用特殊档位（SOS/信标）
在头灯关闭状态下，长按开关按钮超过3秒，头灯进入SOS特殊档位。开启3秒内再次按下按
钮，头灯切换至信标档位。如需退出特殊档位，可在信标特殊档位启动后按下开关按钮，或在
任何特殊档位停止操作3秒钟后，再按下开关按钮。
电量提示
在头灯关闭状态下，按下开关按钮1秒，位于开关按钮的电量提示灯将闪烁提示剩余电量：闪烁
三下表示电量大于50%，闪烁两下表示电量少于50%，闪烁一下表示电量少于10%将近耗尽。
注：当电池电量不足，头灯会出现亮度变暗或者无法调光的情况。此时，应对头灯进行充电。
充电
保固
NITECORE 产品拥有售后保固服务。在购买本产品的15天内，如果有任何质量问题均可向经®
销商要求免费更换。在购买本产品的12个月内享受免费保固服务。在超过12个月免费保固期
后，本产品享有终身有限度保固服务，如需要更换重要部件则需收取成本费用。
本保固规则不适用于以下情况：
1. 人为破坏，拆解，改装本产品。
2. 错误操作导致产品损坏。
如对奈特科尔产品有任何疑问，欢迎联系当地的代理商或发邮件到4008869828@nitecore.cn
※ 本说明书的所有图片、陈述及文字信息仅供参考，请以官网www.nitecore.cn实际信息
为准。思迈工贸有限公司拥有对说明书内容的最终解释权和修改权。
*30分钟
360 360 360流明 流明 流明
1600
坎德拉
80米
920
坎德拉
180
坎德拉
6
坎德拉
60 27 5米 米 米
IPX7（防水等级，水下1米）
1.5米（防跌落高度）
超高亮
220流明
高亮
40流明
中亮
1流明
超低亮 SOS 信标
6小时 7小时
45分钟
100小时 ─ ─
─ ─
─ ─
NU20
NU20 CRI
如图所示，调节灯体使按钮与保护盖分开并按下开
关按钮，开启头灯。3秒内不进行任何操作，再按
下开关按钮，头灯关闭。
注：头灯在开启3秒内连续按下开关按钮，头灯进
入亮度调节模式。
1.本产品自带USB充电功能。掀开头灯机身的USB保护盖，把USB
充电线一端连接至USB插孔，另一端接上电源（适配器、电脑或
其他充电设备）即可充电。充电时间约2小时。
2.充电提示：当头灯处于正常充电状态下，位于开关按钮背面的红
色指示灯将长亮；充电完成后，绿色指示灯亮起。
*30分钟
270 270 270流明 流明 流明
1200
坎德拉
69米
500
坎德拉
45米
90
坎德拉
19米
3
坎德拉
3米
IPX7（防水等级，水下1米）
1.5米（防跌落高度）
超高亮
170流明
高亮
30流明
中亮
1流明
超低亮 SOS 信标
6小时
7小时
45分钟 100小时 ─ ─
─ ─
─ ─
Features
·Highly portable headlamp
·Multiple colour temperature options available
·NU20: Fitted with a CREE XP-G2 S3 LED
·NU20 CRI: Fitted with a Nichia 219B LED, CRI≥90
·Built-in Li-ion battery provides runtime up to 100 hours
·Onboard USB charging circuit
·Single switch user interface design offers easy one-handed operation
·Built-in power indicator (Patent No. ZL201220057767.4)
·4 brightness level and 2 special modes available
·Unique switch guard to prevent accidental activation
·Textured reflector
·52°adjustable illumination angle
·Made from durable PC materials
·Lightweight and compact dimensions
·Impact resistant to 1.5 metre
Dimensions
Size: 2.18”×1.29”×0.82”(with bracket)
Weight: 1.66oz(with battery and bracket)
Output & Runtime
NOTICE: Stated data has been measured in accordance with the international flashlight
testing standards ANSI/NEMA FL1 using an integrated and fully charged 3.7V 600mAh
rechargeable Li-ion battery under laboratory conditions. End-user results may vary due to
individual usage habits and environmental conditions.
*Runtime for turbo mode is calculated based on theoretical arithmetic.
Operating Instructions
ON/OFF
Draw out the NU20/NU20 CRI to expose the switch from the switch guard as
illustrated in the diagram below, press the switch to turn the light on, pressing the
switch again after 3 second to turn the light off.
Brightness Adjustment
Press the switch repeatedly within 3 second from the initial activation will switch
output from ultralow-mid-high-off. Pressing the switch again after 3 second from
initial activation turns the light off.
Access to Turbo
With the light turned on, hold down the switch for more than 1 second to enter
turbo mode (360 lumens for NU20 and 270 lumens for NU20 CRI).
Note: The turbo mode will run for 30 second before stepping down to the next
available output to prevent overheating.
®
The All-Round Flashlight Expert User Manual
NU20/NU20 CRI
SYSMAX Innovations Co., Ltd.
TEL: +86-20-83862000
FAX: +86-20-83882723
E-mail: info@nitecore.com
Web: www.nitecore.com
Address： Unit 6355, 5/F, No. 1021 Gaopu Road, Tianhe District,
Guangzhou, 510653, Guangdong, China
NU06062022
Please find us on facebook:
NITECORE Flashlight
Made in China
Thanks for purchasing NITECORE!
Special Modes (SOS/Location Beacon)
With the light turned off, hold down the switch for over 3 second to enter SOS,
pressing the switch again within a 3 second interval to switch to location beacon.
To exit special mode, press the switch in location beacon mode, alternatively,
cease any operation for 3 second then press the switch again.
Power Tips
With the light turned off, hold down the switch for 1 second, the power indicator
will blink to indicate remaining battery power upon the release of the switch: 3
blinks represent battery power above 50%, 2 blinks represent battery power below
50%, 1 blink represents battery power below 10%.
Note: Recharge the product when output appears to be dim and/or unresponsive.
Recharging
1.This product is USB rechargeable. Raise the micro-USB port cover to expose
the charging port, connect the port to a power supply with a USB cord to initiate
the charging process. Fully charges the battery take approximately 2 hours.
Warranty Details
All NITECORE products are warranted for quality. Any defective /malfunctioning
NITECORE product can be repaired free of charge for a period of 12 months from
the date of purchase. Beyond 12 months, a limited warranty applies, covering
the cost of labor and maintenance, but not the cost of accessories or
replacement parts. The warranty is nullified in either or both of the following
situations:
1. The product(s) is/are broken down, reconstructed and/or modified by
unauthorized parties.
2. The product(s) is/are damaged through improper use.
For the latest information on NITECORE® products and services, please contact
a local NITECORE® distributor or send an email to service@nitecore.com.
※All images, text and statements specified herein this user manual are for
reference purpose only. Should any discrepancy occurs between this manual
and information specified on www.nitecore.com, information on our official
website shall prevail. Sysmax Industry Co., Ltd. reserves the rights to interpret
and amend the content of this document at any time without prior notice.
Accessories
USB cord, head band,
holder
Note: Pressing the switch again within 3
second from when the light is turned on will
switch output to the next available brightness.
2. Charging Tip: A red light under the switch will be lit to
indicate charging in progress, and it will turn green
upon charging completion.
NU20
TURBO HIGH MID ULTRALOW SOS BEACON
LUMEN S
220
LUMEN S
360
LUMEN S
360
LUMEN S
360
LUMEN S
40
LUMEN
1
*30
min
6
h
7
h
45
min
100
h
80m
1600cd
60m
920cd
27m
180cd
5m
6cd
IPX7, 1m
(Wat erproof AND Submer sible)
1.5m
(Impa ct Resista nt)
─
─ ─
─
─
─
NU20 CRI
TURBO HIGH MID ULT RALOW
LUMEN S
170
LUMEN S
270
LUMEN S
270
LUMEN S
270
LUMEN S
30
LUMEN
1
*30
min
6
h
7
h
45
min
100
h
69m
1200cd
45m
500cd
19m
90cd
3m
3cd
IPX7, 1m
(Wat erproof AND Submer sible)
1.5m
(Impa ct Resista nt)
─ ─
─ ─
─ ─
SOS BEACON
