Imported by / Importeret af
NSH NORDIC A/S
Virkefeltet 4
DK-8740 Brædstrup
Made in EU
Art no. 805-627/805-628
1
DK
SE
GB Swing set
Gyngestativ
Gungställning
NO Lekestativ
FI Keinu
DK
SE
GB Instruction
Brugsanvisning
Bruksanvisning
NO Instruktion
FI Ohjeet
2
Before installation
Carefully read this instruction before use.
Before setting up and installing it is recommended to sort the wood parts, brackets screws and bolts in
part numbers. Then follow the assembly instructions step by step.
The swing frame is made of wood - a natural product that works depending on temperature and humidity.
This means that the wood will expand during periods of high humidity and pull together in times of low
humidity, which can cause wind scratches and cracks in the surface. This does not aect the durability of
the wood.
If the assembly of the swing set is not completed within a short time, the remaining wood stored away for
sunlight and moisture.
Follow the instructions for inspection and maintenance
The swing set must be build on a at surface and at least 2 meters away from other buildings or
constructions such as fences, garages, trees, cloth driers or electrical wires.
The swing set must be secured to the ground. We recommend using ground anchors (not included)6
The swing set must not be installed over concrete, asphalt or other hard surfaces. We recommend the
installation over grass, sand, gravel, wood chips or synthetic fall protection.
Distance from the swing seat to ground must be at least 35 cm.
The swing set must be periodically inspected - at least every 3 months and after the winter period. The
construction must be inspected for any damage and attack of rot. The swing set and screws should be
checked for stability and tightened if necessary. Swing clamps, swing seat, ropes and other accessories
should be checked for wear and replaced if necessary. If the discovered defects can not be repaired the
swing set should be taken down and removed.
All moving metal parts should be lubricated regularly. All screws and sharp edges must be checked and
replaced if necessary.
Installation of swing seats
Install the swing seats to the swing clamps of the swing set. 1. The swing next to the slideNOTE!
section must be a trapeze swing with short ropes.
Adjust the ropes.2.
The distance between the swing seat (P1) and the ground should be at least 35 cm.3.
The distance between an accessory and the frame, should be at least 30 cm.4.
The distance between the swing clamps should be 45 cm.5.
The distance between swinging accessories, should be 45 cm.6.
Check the swing seats has been installed correctly by hanging in the rope few seconds.7.
Follow the manual for inspection and maintenance.8.
Warnings!
Only for domestic use.
Only for outdoor use.
Maximum user weight is 50 Kg.
Suitable for children from 3-10 years.
Maximum number of users is 2.
GB
3
CAREFULLY READ THIS INSTRUCTION BEFORE USE
General safety instructions:
The safe play area refers to a zone extending 200 cm beyond the play set on all sides. The safe play zone in front of and •
behind a swinging accessory is 200 cm.
The safe play area must be free of all structures, fences, garage, house, overhanging branches, laundry lines, electrical wires•
and other obstacles to ensure safe play.
Do not situate your play set in the directions of walks or gangways.•
The ground surface must be level. Installing your play set on sloping ground can cause it to lean or “rack”. This leaning puts •
additional stress on all connections and joints and in time will cause those connections to loosen and fail.
Do not install your play set over concrete, gravel asphalt, packed earth, or any other hard surface. A fall onto a hard surface •
can result in serious injury.
The following is a list of recommended ground covers.•
Double shredded bark mulch 50 cm•
Uniform wood chips 50 cm•
Fine gravel 50 cm•
Fine sand 50 cm•
Save these instructions for future reference.•
Safe play:
On site adult supervision must be provided for children of all ages and at all times.•
Teach the children to play safe.•
Dress children appropriately. Avoid accessories, clothing with drawstrings, loose tting clothes and stringed items placed •
around the neck, which could become entangled or snagged on equipment. Also bike helmets should be taken o before
playing on playground equipment.
Last but not at least: use common sense to avoid any possible unsafe situations.•
Equipment should not be played upon in wet weather conditions because of potentially slippery surfaces and in periods of •
frost, even the softest pavement can change into a very hard surface.
Accessories should be removed and taken indoors when temperatures drop below 0°C•
Using the playground or the accessories in any other manner than the way intended could lead to damage or injury. Do not •
twist or wrap swings, chains ropes or any other accessories. Twisting will reduce the strength of the accessories and may
cause entrapment.
Caution children no to:•
Jump o swings while they are in motion.•
Swing empty seats or other empty accessories.•
Swing at an angle.•
Hang upside down from any part of the gym set.•
Grasp or stop another child on any moving equipment.•
Walk close to, in front of, between, or behind moving accessories.•
Caution children to sit in centre of the swings with their full weight on the seats. Only one child per each planned occupant •
seat should be allowed.
Climbing or hanging on the frame of the play set must not be permitted. Serious injuries can be result from fails.•
Inspection and maintenance:
To ensure the safety of the users of the play set, the play set has to be subjected to the safety inspections mentioned below •
once at the beginning of each season and further twice monthly during the usage season.
Check all hardware to be sure it is tight. Caution: overtightened hardware crushes the bres of the wood resulting in split •
boards.
Check the remaining hardware, brackets and swing clamps also for rust, which can have eect on the strength. Replace •
when necessary.
Check the ground anchors to be sure that they are secured. If necessary, reposition or replace.•
Check all coverings for bolts and sharp edges and replace when required.•
Check swing seats and bars for integrity and check swing ropes for fraying or extreme creation of bre. To examine the rope , •
open the strands of the rope there where the fraying occurred and securely check whether the laments are broken.
All accessories can be cleaned with warm water and a mild detergent. •
Check the play sets stability.•
Check the environment for direct danger like overhanging branches, laundry lines and loose materials.•
Customer responsibilities:
It is the customer´s responsibility to perform regular inspections and maintenance to ensure that the product is not prema-•
turely ageing. These inspections and maintenance are mentioned in this manual.
The customer has to take all precautions to safeguard the safety of the children.•
GB
