Symbols
ENG
WARNING
ENG
x3
Screws must get at
least three full turns
and t snug.
ENG Do not overtighten screws.
ENG
Tools Needed for Assembly.
ENG
1
2
ENG To properly tighten screws: Tighten until screw
head makes contact, then tighten another 1/2
turn. Do not overtighten screws.
4
+1/2
3
3/8"
(10mm)
ENG - Do not begin to install product until you have read and understood the instructions and warnings
contained in this user guide. Before installing make sure the supporting surface will support the combined load of
the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur
and product may fail. Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting
equipment to safely lift and position equipment. This product is intended for indoor use only. Use of this product
outdoors could lead to product failure or personal injury. To reduce the risk of electric shock or re, do not expose
product to water or moisture. Be sure power cord is routed so that it will not be tripped on, stepped on, or pinched
by heavy items. Avoid overloading electrical outlets or extension cords. Always disconnect the power cord from
the power outlet when installing, servicing, or not using the product for an extended period of time. Do not block
ventilation slots or fan exhaust on product. Blocking airow could damage product. Arrange product to allow air to
ow freely around product. Keep product away from direct sunlight or any source of heat. For support please call
800-4-SIGNAGE.
WARNING
32018-04-02 #:150-9211-1
Parts (Before beginning, make sure you have all parts shown below).
ENG
Parts List
Part #Description Qty
Abase assembly
KILH540-EUK 151-P1995-S1
KILH540-S-EUK 151-4995-S1
KILH542-EUK 151-P1995-S1
KILH542-S-EUK 151-4995-S1
KILH543-EUK 151-P1995-S1
KILH543-S-EUK 151-4995-S1
KILH546-EUK 151-P1995-M1
KILH546-S-EUK 151-4995-M1
KILH547-EUK 151-P1995-M1
KILH547-S-EUK 151-4995-M1
KILH548-EUK 151-P1995-M1
KILH548-S-EUK 151-4995-M1
KILH549-EUK 151-P1995-L1
KILH549-S-EUK 151-4995-L1
KILH550-EUK 151-P1995-L1
KILH550-S-EUK 151-4995-L1
KILH555-EUK 151-P1995-XL1
KILH555-S-EUK 151-4995-XL1
Badaptor bracket 2 202-SG1695
Cdisplay hood
KILH540-EUK 151-P19571
KILH540-S-EUK 151-49571
KILH542-EUK 151-P19591
KILH542-S-EUK 151-49591
KILH543-EUK 151-P19611
KILH543-S-EUK 151-49611
KILH546-EUK 151-P19631
KILH546-S-EUK 151-49631
KILH547-EUK 151-P19651
KILH547-S-EUK 151-49651
KILH548-EUK 151-P19671
KILH548-S-EUK 151-49671
KILH549-EUK 151-P19691
KILH549-S-EUK 151-49691
KILH550-EUK 151-P19711
KILH550-S-EUK 151-49711
KILH555-EUK 151-P19731
KILH555-S-EUK 151-49731
D4mm allen wrench 1 560-1146
EM4 x 12mm 520-10794
FM4 x 25mm 520-10824
GM6 x 12mm 520-10504
HM6 x 25mm 520-12114
IM8 x 12mm 520-17244
JM8 x 25mm 520-11014
KM4 x 1mm washer 540-94004
LM6/M8 x 1.5mm washer 540-94068
M1/4" (6mm) height spacer 600-12158
NM8 x 50mm 521-10134
