BC
NT 3600, NT 3610
Specifications are subject to change without
notice.
© 2020 Koninklijke Philips N.V.
All rights reserved.
Las especificaciones están sujetas a
modificaciones sin previo aviso.
© 2020 Koninklijke Philips N.V.
Todos los derechos reservados.
4222.002.9249.4 (2/24/2020)
2
3
AA
4
5
6
7
8
9
10
11
12
13
14
15
2 min.
Max.
16
17
18
19
20
21
English
IMPORTANT
SAFETY
INSTRUCTIONS
When using an electric product, basic
precautions should always be followed,
including the following:
Read all instructions before using this
product.
WARNING
To reduce the risk of burns, fire, electric
shock, or injury to persons:
-Use product only in dry condition. Do not
use while bathing or in a shower.
-Close supervision is required when this
product is used by, on, or near children,
or persons with limited physical, sensory,
or mental capabilities or invalids.
-Use this product only for its intended
household use as described in this
manual. Do not use attachments not
recommended by Philips North America
LLC.
-Never drop or insert any object into any
opening.
-Never operate this product if it is not
working properly, after it has been
dropped or damaged, or after the
product has been dropped into water.
For assistance call 1-800-243-3050.
-Do not use this product outdoors or
operate where aerosol (spray) products
are being used or where oxygen is being
administered.
-Never put the product in direct sunlight
or store at a temperature above 140 °F
(60 °C).
-Always check cutters, cutting unit and
guards before using the product. Do not
use the product if cutters, cutting unit or
guards are damaged, as injury may occur.
-Only use the accessories supplied with
the product.
-If product will not be used on a regular
basis, remove the battery to prevent
possible damage due to chemical
leakage. If battery does leak, remove it
carefully. Do not allow bare skin to touch
leaking fluid.
-The batteries used in this product may
present a fire or chemical burn hazard if
mistreated. Do not disassemble, heat
above 100 °C (212 °F) or incinerate.
-Do not recharge non-rechargeable
batteries.
SAVE THESE
INSTRUCTIONS
Introduction
Congratulations on your purchase and
welcome to Philips Norelco!
To fully benefit from the support that
Philips Norelco offers, register your product
at .www.norelco.com/register
General description (Fig. 1)
1 Short eyebrow comb (1/8 in, 3 mm)
AA
NT3610 only
4
8
9
3
10 11 12
1 2
13
7 56
1
2 Long eyebrow comb (13/64 in, 5 mm)
3 Cutting element
4 Trimming head
5 'Unlocked' indication
6 'Locked' indication
7 Setting indicator
8 Handle
9 On/off slide
10 Rotary trimmer
11 AA Lithium battery
12 Cleaning brush
13 Pouch (NT3610 only)
Preparing for use
Inserting the battery
Note: Make sure your hands and product
are dry when you insert the battery.
1 To remove the battery compartment
cover, turn it clockwise until the setting
indicator points to the 'unlocked'
indication (^) (Fig. 2).
2 Pull the battery compartment cover off
the handle (Fig. 3).
3 Put the battery in the battery
compartment (Fig. 4).
Make sure the + and - poles of the
battery point in the right direction.
Note: The product operates on one
replaceable lithium AA 1.5-volt battery
(included).
4 Slide the battery compartment cover
back onto the handle (Fig. 5).
5 Turn the battery compartment cover
counterclockwise until the setting
indicator points to the 'locked' indication
(0) (Fig. 6).
Using the product
Use the product for the following purposes:
-Trim your eyebrows with the eyebrow
comb attached to the trimming head.
-Trim your ear, nose and neck hair with
the trimming head.
-The rotary trimmer can also be used to
trim ear and nose hair.
Rinse the cutting element of each
attachment with lukewarm water after
each use.
Be careful to always keep cutting
element away from eyes and eyelashes.
For hygienic reasons, the product should
only be used by one person.
Apply gentle pressure. Pressing too hard
may cause skin irritation, and the trimmer
will not function properly.
Do not use trimmer on sensitive areas or
irritated skin.
Switching the product on and off
1 To switch on the product, slide the on/off
slide upwards.
2 To switch off the product, slide the
on/off slide downwards.
Detaching and attaching the attachments
Note: Switch off the product before
attempting to detach or attach the
attachments.
1 To detach an attachment from the
handle, firmly grip the attachment below
the cutting element and turn it until the
setting indicator points to the 'unlocked'
indication (^).
2 Lift the attachment off of the handle.
1 To attach an attachment, place the
attachment on the handle with the
setting indicator pointing to the
'unlocked' indication (^).
2 Firmly grip the attachment below the
cutting element and turn it until the
setting indicator points to the 'locked'
indication (0).
Trimming eyebrows with the eyebrow
guard
1 Comb your eyebrows in the direction of
hair growth (Fig. 7).
2 Make sure the product is switched off.
Slide the eyebrow comb onto the
trimming head (Fig. 8). The short eyebrow
comb trims the hairs to a length of 1/8 in,
3 mm. The long eyebrow comb trims the
hairs to a length of 13/64 in, 5 mm.
Note: Make sure the comb slides into the
grooves on both sides of the trimmer.
