INSTRUCTION MANUAL

WE’RE HERE TO HELP

Get it right the ﬁrst time.

HeightFinder™ shows you

where to drill.

Check it out at:

SANUS.com/1172

Want to watch a video that

shows how easy this DIY

project will be?

Watch it now at:

SANUS.com/2814

Our US-based install experts

are standing by to help.

Call us at:

800-359-5520

Or, chat at:

SANUS.com/chatSP

Texto en español, página 13

TV Weight Limit

(including accessories)

DO NOT EXCEED

If your TV, plus accessories, weighs MORE

than indicated, this mount is NOT compatible.

Visit SANUS.com or call customer service to

ﬁnd a compatible mount.

Call Customer Service

Tools

Needed

Wall

Construction

ONLY install on

these acceptable

wall types.

Unsure

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ ENTIRE MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS

Please read through these instructions completely to be sure you’re comfortable with this easy install process.

Check your TV owner’s manual to see if there are any special requirements for mounting your TV.

If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product,

contact Customer Service.

CAUTION: Avoid potential personal injuries and property damage!

●This product is designed ONLY to be installed into wood studs, solid concrete or concrete block.

— DO NOT INSTALL INTO DRYWALL ALONE — DRYWALL ALONE WILL NOT HOLD THE WEIGHT OF YOUR TV .

●This product is designed for .INDOOR USE ONLY

●The wall must be capable of supporting ﬁve times the weight of the TV and mount combined.

●Do not use this product for any purpose not explicitly speciﬁed by manufacturer.

●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.

175 lbs.

(79.3 kg)

Drywall alone

will NOT hold

the weight of

your TV.

wood concretestuds Solid or

concrete block

ACCEPTABLE ACCEPTABLE

CAUTION:

DO NOT install

in drywall alone

Wood Stud

Install

Concrete

Install

Awl

Pencil Level Tape

Stud

Finder

ScrewdriverTape

Measure

7/32 in.

(5.5 mm)

Wood

Drill Bit

Electric

Drill

Hammer

1/2 in.

(13 mm)

Socket

Wrench

Drill Bit

3/8 in.

(10 mm)

Concrete

BEFORE YOU BEGIN

Remove the stand from

your TV if attached.—

Install any accessories you may

have purchased, if they requireTV removal

prior to assembly. Note that the TV is

removable for future accessory purchases.

Soft clean surface

Protect the face of your TV

when laying it down for installation.

DIMENSIONS IN. [MM]

Legrand AV Inc. and its aliated corporations and subsidiaries (collectively, “Legrand ”), intend to make this manual accurate and complete. However, Legrand makes no claim that the information

contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this

document is subject to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, regarding the information contained herein. Legrand assumes

no responsibility for accuracy, completeness or suciency of the information contained in this document.

15.75in

400mm

MAX

23.62in

600mm

MAX

7.87in

200mm

MIN

7.87in

200mm
