Sida 1/28
LT
25
INSTRUCTION MANUAL
Scan for easy install video
http://san.us/630
We’ll Make It Stress-Free
If you have any questions along the way, just give us a call.
1-800-359-5520. We’re ready to help!
2
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE
No
—
Perfect!
Yes
—
This mount is NOT compatible. Visit MountFinder.Sanus.com or call
1-800-359-5520 (UK: 0800-056-2853) to fi nd a compatible mount.
Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Also check your TV owner’s manual to see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use
of this product, contact Customer Service at 1-800-359-5520 (UK: 0800-056-2853).
Do you have
all the tools
needed?
Before getting started, let’s make sure this mount is perfect for you!
1
2
3
4
What is your
wall made of? Unsure?
Drywall with
wood studs?
Solid concrete or
concrete block?
175 lb
(79.4 kg)
CAUTION: Avoid potential personal injuries and property damage!
●This product includes directions and hardware for use with wood stud, solid concrete and concrete block walls –
DO NOT install into drywall alone.
●The wall must be capable of supporting fi ve times the weight of the TV and mount combined.
●Do not use this product for any purpose not explicitly specifi ed by manufacturer.
●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
Call Customer Service:
1-800-359-5520 (UK: 0800-056-2853)
Perfect! Perfect!
Ready to
begin?
Does your TV weigh
more than 175 lb
(79.4 kg) including
accessories?
1/2 in.
(13 mm)
3/16 in.
(5 mm)
Wood
Screwdriver Tape Measure Drill Bit Drill Bit Electric Drill Hammer Socket Wrench
1/2 in.
(13 mm)
Concrete
CAUTION:
DO NOT install
into drywall alone
Awl Pencil LevelStud Finder
3
27.541
MAX.
699.53
17.323
440.00
18.220
462.79
1.503
MIN.
38.18
2.000
50.80
0.506
12.86
2.000
50.80
8.635
219.34
12.166
309.02
30.006
762.16
3.098
78.69
8°
MAX TILT UP
10°
MAX TILT DOWN
NOTE:
MAX. HEIGHT ADJUST
.5 IN.
in.
[mm]
Dimensions
