Scan for easy install video

http://san.us/401

We’ll Make It Stress-Free

If you have any questions along the way, just give us a call.

1-800-359-5520. We’re ready to help!

VST4 INSTRUCTION MANUAL

IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE

Before getting started, let’s make sure this mount is perfect for you!

2 What is your wall made of?

3 Do you have all of the tools needed?

4 Ready to begin?

Please read through these instructions completely to be sure you’re comfortable with this easy install process. Also check your TV

owner’s manual to see if there are any special requirements for mounting your TV.

If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact

Customer Service at 1-800-359-5520 (UK: 0800-056-2853).

Does your TV weigh more than 50 lb (22.7 kg) including accessories?

No — Perfect!

Yes — This mount is NOT compatible. Visit MountFinder.Sanus.com or call 1-800-359-5520 (UK: 0800-056-2853) to ﬁ nd a compatible mount.

Drywall with

wood studs

Perfect!

Unsure?

Call 1-800-359-5520 (UK: 0800-056-2853)

50 lb

(22.7 kg)

12 mm

(7/16 in.)

3 mm

(1/8 in.)

Wood

10 mm

(3/8 in.)

STEP 1 Attach Bracket to TV

WARNING: This product contains small items that could be a choking hazard if swallowed.

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged

item to your dealer; contact Customer Service. Never use damaged parts!

Parts and Hardware for STEP 1

NOTE: Not all hardware included will be used.

*You may need to separate the TV

bracket 01 from the wall plate 18

before starting this step.

TV Bracket* 200 x 200 Extension 200 x 200 Extension Screw

200 x 200 Extension Nut

M6 x 12mm

02 x201 x1

03 x4

04 x4
