Installation and User’s Manual for
Meridian Ice Maker-Dispensers
Wall Mount Models
HID312AW, HID525AW and HID540AW
HID312AW, HID525AW and HID540AW
Installation and User’s Manual
July 2018
Page 2
Introduction
The ice maker-dispensers covered in this manual
were designed by to be the nest on the market. Their
design is a result of Scotsman’s long experience in ice
maker-dispensers.
This manual includes the information needed to
install, start up and operate the machine. Because
there are three models covered, be sure that any
instructions apply to your unit.
HID312 is 16 inches wide.
HID325 is 21 inches wide and 35 inches tall.
HID340 is also 21 inches wide, but it is 40 inches tall.
Observe any caution or warning notices. They are
important and provide notice of potential hazards.
Keep this manual for future reference.
If additional technical information is needed, go to
Scotsman’s website, www.scotsman-ice.com to
download a service manual.
Contents
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 3
HID312AW Cabinet Drawing Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
HID525AW Cabinet Drawing Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
HID540AW Cabinet Drawing Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Placement Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Wall Mounting Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Initial Start Up Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operation: Ice and Water Vending Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Controller Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintenance and Cleaning Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Maintenance and Cleaning - Dispensing bin and ice level controls Page . . . . . . . . . . . . . . . . 14
Ice level controls, Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Ice Making and Ice Dispensing System Cleaning Instructions Page . . . . . . . . . . . . . . . . . . . 16
Basic Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 18
Controller Diagnostics Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
HID312AW, HID525AW and HID540AW
Installation and User’s Manual
March 2015
Page 3
Specications
The ice maker-dispenser is designed to be installed
indoors, in a controlled environment. Although
it can operate in a wide range of air and water
temperatures, it will provide the best performance if
not subject to extremes.
Air Temperature Limitations
• Maximum: 100oF. or 38oC.
• Minimum: 50oF. or 10oC.
Water Temperature Limitations
• Maximum: 100oF. or 38oC.
• Minimum: 40oF. or 4.4o
C.
Water Pressure, potable
• Maximum: 80 PSI or 5.5 Bar
• Minimum: 20 PSI or 1.3 Bar
Water Conductivity:
• Minimum: 10 microSiemens/cm
RO water may be supplied to the potable water
system, but if it has less than the above conductivity,
the water level sensor will not detect water and the
unit will not make ice.
Deionized water will not work and isn’t recommended.
Voltage
• Maximum: 126 Minimum: 104
Operating the machine outside of any of the above
limitations is considered abuse and any resulting
damage is not covered by warranty and could cause a
complete loss of warranty coverage.
Warranty Information
The warranty statement for this product is provided
separately from this manual. Refer to it for applicable
coverage. In general warranty covers defects
in material or workmanship. It does not cover
maintenance, corrections to installations, or situations
when the machine is operated in circumstances that
exceed the limitations printed above.
Product Information
The product is an ice maker-dispenser. It is designed
to be hung on a wall over a sink.
• All models require a drain. An internal drain basin
separates the ice storage bin’s drain from other
drains.
• A backow preventer may be required by local
plumbing codes.
• A power cord with NEMA 5-15P plug is included.
• Air cooled models ow air left to right and include
a cleanable air lter.
• Ice or water vending is triggered by touch free
sensors, no other activation method is available.
• For available options and kits, see sales literature.
Scotsman Ice Systems are designed and
manufactured with the highest regard for safety and
performance. They meet or exceed the standards of
UL and NSF.
Scotsman assumes no liability or responsibility of
any kind for products manufactured by Scotsman
that have been altered in any way, including the use
of any part and/or other components not specically
approved by Scotsman.
Scotsman reserves the right to make design changes
and/or improvements at any time. Specications and
design are subject to change without notice.
Model Electrical Condenser Typical Amp Draw Maximum Fuse Size
HID312AW-1A 115/60/1 Air 155.7 - 6
HID525AW-1A 115/60/1 Air 157.2 - 8
HID540AW-1A 115/60/1 Air 157.2 - 8

Produktspecifikationer

Varumärke: Scotsman
Kategori: Inte kategoriserad
Modell: Prodigy Plus C0530R
