DO7010
Rugged portable micro ohmmeter for low
resistance measurement
The DO7010 is a very rugged and very compact, portable digital ohmmeter
for the measurement of low resistance. Using rechargeable and replaceable
NiMh batteries with external charger, the DO7010 is capable of measuring
with a current of 1 and 10A on all except the highest range.
The DO7010 has been designed with the latest solid state and
microprocessor techniques to ensure the very best in measurement reliability
and features. The LCD graphic display panel gives full information regarding
the measurement configuration, and a single measurement start button
ensures that the operation is simple and easy to use.
The measurement may be triggered when the measurement leads are
applied to the device under test, ensuring fast single-person operation.
The data-logging function also permits up to 1,000 date and time stamped
readings to be stored.
www.seaward.co.uk/DO7010
For USA, Canada and Mexico enquiries Tel: +1 (813) 886 - 2775
For all other enquiries Tel: +44 (0) 191 587 8741
Email: sales@seaward.co.uk
Key Features
True 4 wire measurement eliminates
lead resistance errors
4 ranges 6mΩ Ω to 6
Resolution 1µ on 6m rangeΩ Ω
Graphics Display with backlight
3 languages (English, French,
German)
1 and 10A measuring current
even on the 600mΩ range
Forward and reverse current
measurement
Auto average of forward and
reverse measurement
True zero offset
Built in test resistor for confidence
check
Data logging with up to 1000 readings
stored with date and time stamp
Hi-Lo limits with audible and visual
warning
Automatic measurement trigger
when leads are connected to DUT
Small size and light weight <4Kg
RS232 interface with option remote
terminal to enable operation up to
15m distance
Rechargeable NiMh batteries with
charge indicator and easily
replaceable battery pack
Ideal For
Aerospace
Automotive
Military
Manufacturing
Utilities, electrical, water and gas
DO74A Plus Optional Accessories
Part Number Item Part Number
DO7010-BP Additional battery pack 100123
HS01-7010 Duplex handspikes with 3m lead length 190052
HS02-7010 Duplex handspikes with 3 and 15m lead length 190056
LS03-7010 Lead set with 3m leads and terminated with large Kelvin clips type KC3 190043
LS04-7010 Lead set with 3 and 15m lead length terminated in large Kelvin clips type KC3 190047
MTS3 Calibration Standard 930242
RSL04 RS232 interface cable 1m 920069
Technical Specifications
General Specifications
Dimensions
390 x 160 x 270mm / 15 x 6.3 x 11” (w x h x d) approx
Mass
4kg / 9lbs approx
Services
1 year warranty (subject to product registration with Seaward. Visit
www.seaward.co.uk/register-product)
Service and calibration by Calibrationhouse.
Go to www.calibrationhouse.com for more information.
Part Number
930217
Range Resolution Typical Current FSV Accuracy at 20°C±5°C 1 year
6 1m 100mA/1A ±(0.1% Rdg +0.1% FS) 40ppm Rdg + 30ppm FSΩ Ω
600m 100µ 1/10A ±(0.1% Rdg +0.1% FS) 40ppm Rdg + 30ppm FSΩ Ω
60m 10µ 1/10A ±(0.1% Rdg +0.1% FS) 40ppm Rdg + 30ppm FSΩ Ω
6m 1µ 1/10A ±(0.1% Rdg +0.1% FS) 40ppm Rdg + 30ppm FSΩ Ω
Measurement
4 Terminal Kelvin/Thomson principle eliminates errors due to
lead resistance.
Open circuit measurement voltage = 5VDC
Display
240 x 64 dot graphics LCD with backlight
Ranges
4 ranges with auto range mode. Two selectable measuring
currents for each range
Terminals
The measurement leads are connected via Jaeger connectors
and a full range of lead configurations are available
Working Temperature
0 to +50°C rel. humidity up to 80% non condensing
Storage Temperature
-20 to +50°C
Safety
Conforms to EN 61010-1, Main instrument Class III (SELV),
Battery pack Class III (SELV) and external mains charger Class II
Battery
The DO7010 is supplied with battery fitted. The batteries are
NiMh and the charger is external. The battery pack may be
removed from the front panel when discharged and a
replacement charged pack inserted. This ensures minimum
down-time when making measurements
Lead Sets
We offer a wide variety of lead sets with 3 sizes of Kelvin clip or
handspikes. Lead lengths may be up to 100m total loop
Data Logging
The DO7010 has data logging modes. The first will store each
reading with record number date and time. The second is a
sequence mode which will store values with operator ID, serial
number etc
Rev 2
www.seaward.co.uk/DO7010
For USA, Canada and Mexico enquiries Tel: +1 (813) 886 - 2775
For all other enquiries Tel: +44 (0) 191 587 8741
Email: sales@seaward.co.uk
