The new Solar Utility Pro from Seaward takes PV testing to the next
level. With the introduction of more efficient 1500V modules and
inverters, Seaward have answered the industry call for an easy to use
and robust tester with 1500V capabilities.
Its market leading 40A current capability enables the to test parallel Solar Utility Pro
wired strings up to a maximum of 1500V / 40A, eliminating the time consuming task
of separating strings to keep within lower limits of other instruments.
A single press of the Test button will give values for Open Circuit Voltage and Short
Circuit Current, and when paired with the Seaward Solar Survey 200R irradiance
meter, will also record irradiance, module and ambient temperature measurements.
The large internal storage memory can record up to 999 complete record sets,
which can be downloaded as a CSV file to a PC for review.
To make on site testing easier, the is supplied with 1.5M long Solar Utility Pro
conversion leads that convert the standard MC4 leads to alligator clips – particularly
useful in combiner boxes and junction boxes.
These features, in a rugged enclosure, give the larger scale PV engineer the most
efficient, portable and highest rated tester available.
The only 1500V, 40A string checker.
Solar Utility Pro
To see the new for yourself, request your live Solar Utility Pro
online demonstration today at seaward.com/SUP
T: +44 (0) 191 587 8741 sales@seaward.com E:
Why buy the
Solar Utility Pro?
> Test up to 1500V / 40A systems
– ideal for today’s more modern
powerful PV installations
> Highest rated PV tester
on the market – minimizing
accidental damage to the
instrument or the user by
testing across multiple strings
> Record up to 999 full sets of
string data – maximizing time
in the field to complete testing
without downloading and
clearing the memory
> Rugged case design – giving
more protection while being
transported around large
utility scale sites
> Contact us for product training
and support
Key Features:
> 1500V / 40A rated
> Large display designed for reading
in direct sunlight
> Direct MC4 connections, with the
option to add a conversion lead
set for safer connections in
combiner boxes
> Simple single button test
> Rugged case designed for
continuous site work
> Store up to 999 complete record
sets
> CSV output to PC to review data
> Pairs to Solar Survey 200R irradiance
meter to capture the irradiance and
temperature measurements at the
time to test (single person testing)
Kit includes:
> Solar Utility Pro unit
> Set of 1.2M red and black MC4 leads
with test probe and aligator clip
> Set of 2M red and black MC4
extension leads
> SS200R irradiance meter
> SS200R irradiance meter clamp
> PV hold-all bag
> 3 x 18650 protected lithium-ion
batteries
> Battery charger
> 2 x Dust covers
> 1 x UK mains lead
> 1 x Schuko mains lead
The only 1500V, 40A string checker.
Solar Utility Pro
To see the new Solar Utility Pro for yourself, request your live
online demonstration today at seaward.com/SUP
T: +44 (0) 191 587 8741 sales@seaward.com E:
Seaward Solar Cert
Software
> Compatable with Solar Cert to
give you the ability to compare
measured Voc and Isc against
expected values calculated using
the panel parameters
> If temperature or irradiance is
missing, Solar Cert now has an
interpolation option
Technical Specification:
Display Range
Measuring Range
Resolution
Accuracy
Short Circuit Current Measurement
Display Range
Measuring Range
Maximum Power
Resolution
Accuracy
General Specifications
Dimensions
Weight
Power Source
Communication
Display
On-board Memory
Storage Environment
Operating Conditions
Environmental Protection
Connectivity
USB download to PC, via DataLogger Utility
Wireless “Solarlink” to Survey 200R
0.0VDC – 1500VDC
5.0VDC – 1500VDC
0.1VDC max
±(0.5% + 2 digits)
0.00ADC – 40.00ADC
0.50ADC – 40.00ADC
45kW
0.01ADC
±(1% + 2 digits)
340mm x 300mm x 152mm (L x W x H,
Closed)
13.4” x 11.8” x 6.0” (L x W x H, Closed)
4.7kg (10.4lbs)
3x 3.7V / 3000mAh Li-ion batteries
USB Download
Custom LCD with backlight
Up to 999 datasets
-25°C to +65°C (-13°F to 149°F)
0°C to 40°C (32°F to 104°F)
IP 40 open, IP64 closed
(CSV format)
Frequency 433MHz, range 30m/100ft (ROW)
Frequency 915MHz, range 30m/100ft (USA)
Open Circuit Voltage Measurement (PV Terminals)
Part Number: 416A910 (433MHz, ROW), 416A912 (915MHz, USA Only)
The only 1500V, 40A string checker.
Solar Utility Pro
To see the new for yourself, request your live Solar Utility Pro
online demonstration today at seaward.com/SUP
T: +44 (0) 191 587 8741 sales@seaward.com E: Rev 1.8
