© Copyright 2010 Smart-AVI, All Rights Reserved
NOTICE
T h e i n f o r m at i o n c o nt a i n e d i n t h i s d o c u m e n t
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
SmartAVI, Inc. / Twitter: smartavi
2840 N. Naomi Ave. Burbank, CA 91504
Tel: (818) 565-0011 Fax: (818) 565-0020
http://www.SmartAVI.com
Extends USB 2.0 up to 300 feet over
CAT5 Cable
USB2Pro
USB 2.0 Extender over CAT5
www.smartavi.com
Installation
Manual
Technical Specications
What’s in the Box?
PART NO. QTY DESCRIPTION
USB2Pro 1 USB 2.0 over CAT5 Extender Link. Includes:
[USB-2PTX, USB-2PRX and PS5VD2A ]
Power Supply 1 PS5VDC2A
User Manual 1
USB
Signal Type USB 2.0
Input Interface (TX) (1) USB Type B (Female)
Output Interface (RX) (4) USB Type A (Female)
OTHER
Power External 100-240 VAC/5VDC2A @20W
Dimensions 3.625 in W x 1 in H x 3 in D
Weight 1.5 lb
Operating Temp. 0-55 °C (32-131°F)
Storage Temp. -20-85 °C (-4-185 °F)
Humidity Up to 95%
up to 300 ft over CAT5
USB2Pro-TX USB2Pro-RX
USB FLASH DRIVE USB KEYBOARD USB MOUSE
USB CAMERA
COMPUTER
Introduction
SmartAVI’s USB2Pro extends standard USB (Universal
Serial Bus) 2.0 signals up to 300 feet using a single CAT5
cable. The USB2Pro supports all USB 2.0 high-speed
devices, from keyboards to digital cameras and will
operate on Windows®, Mac and Linux® operating systems.
An integrated four-port hub allows for multiple devices
to be connected to the USB2Pro at once. Additional USB
hubs can be added, increasing the amount of devices
that can be plugged into the USB2Pro.
Connecting the USB2Pro
1. Power o all devices.
2. Connect the USB source (computer) to the USB
port on the front of the USB2Pro Transmitter
labeled .
3. Connect the USB2Pro Transmitter to the USB2Pro
Receiver with a CAT5 cable using the front ports
labeled .
4. Connect up to 4 USB 2.0 devices to the rear ports
on the USB2Pro Receiver labeled .
5. Power on the USB2Pro Transmitter and Receiver
by plugging the AC Adapter into the front ports of
the unit labeled .
6. Power on the computer and USB devices.
Applications
• Digital Signage
• Home Networking
• Remote USB Connections
• USB Device Sharing
• Webcam
• USB Electronics Devices
• Security Systems
• KVM Extension
Features
• Supports all USB 2.0 and1.1 Devices Transparently
(Flash Drives, Printers, Cameras, Scanners, etc.)
• Supports USB 1.1 keyboard and mouse
• Works on Windows, Mac and Linux Operating
Systems
• Integrated Four-Port Hub
• Bus-Powered Local Unit
• Power Adaptor for Remote Unit
• Plug-and-Play
Product - Installation Diagram
