Sida 1/2
November 24, 2015
©2015 SONNEMAN - A WAY OF LIGHT 1 of 2
LED Product Information and Warnings
Important
• Always disconnect the power before installing or replacing bulbs and before cleaning or other maintenance.
• Consult a qualied, licensed electrician to ensure correct branch circuit conductor.
• Please read all included assembly instructions and warnings carefully before installation. Contact
Customer Service if you have any questions or concerns. Before installation, please conrm that the xture
is compatible with your supply voltage and dimming system, if present.
• LEDs are highly sensitive electronic devices, and must be treated with care. Do not open any factory
sealed compartments, and avoid touching the LEDs with your hands or any object.
• Although all our xtures are equipped with protective devices, LED xtures are vulnerable to power surges
and supply variations. Do not install LED xtures on the same circuit as any motors, appliances, or HVAC
systems.
• Do not remove or bypass any LED Driver or Transformer that is provided with the xture, and do not
replace or substitute with another power supply.
• Remote LED Driver or Transformer installation must be done by a licensed electrician and in accordance
with local codes. Remote installations should be in an accessible location, as close to the xture as possible.
• Fixtures must be wired in parallel on independent leads; do not "daisy chain" multiple xtures together or
wire them in series.
• All factory-made splices and connections must remain intact. LED circuits are carefully designed and built,
and improper connections may damage the xture.
• The ends of coaxial pendant cords have been precisely stripped and split at the factory and must not be
eld cut. Excess cord or cable should be neatly coiled and reserved in the xture canopy.
• Any mounting hardware is provided for your convenience and should be used with discretion. Always use
the appropriate hardware for the mounting surface.
November 24, 2015
©2015 SONNEMAN - A WAY OF LIGHT 2 of 2
Assembly Instructions
INSTRUCTIONS D’INSTALLATION
Stix Series - 18" LED Bath Bar, 24" LED Bath Bar, 32" LED Bath Bar, 40" LED Bath Bar
Important
• Always disconnect the power before installing or replacing bulbs and before cleaning or other maintenance.
• Consult a qualied, licensed electrician to ensure correct branch circuit conductor.
Consulter un électricien qualié pour vous assurer que les conducteurs de la dérivation sont adéquats.
1. Shut off power to the outlet box (A).
2. Make appropriate electrical connections using wire nuts:
a. Connect the transformer's (B) live wire (black) to the live outlet box wire.
b. Connect the transformer's (B) neutral wire (white) to the neutral outlet box wire.
c. Connect the fixture's ground wire (green or uncoated) to the ground outlet box wire. If no ground is present in outlet box, connect
fixture's ground wire to the mounting plate (C) using the green screw (included).
d. Carefully place connections and transformer (B) in outlet box (A).
3. Attach the mounting plate (C) to the outlet box (A), secure with outlet box screws (D).
4. Install the back plate (E) to the mounting plate (C) by hooking the bend (F) onto the bracket in the back plate. Secure with set screws (G)
using included Allen wrench (H).
5. Restore power to the fixture.
Note
• This fixture is dimmable with Electronic Low Voltage (Trailing-Edge) type dimmers only.
Care Instructions
• Dusting: Use a clean, dry cloth.
• Cleaning: To protect the finish, avoid any harsh abrasives or chemicals.
2770
2769, 2770, 2771, 2772
A
B
C
D
E
F
G
H
27712769 2772
