44-Pin IDE Flash Module
(Horizontal)
Description
With an IDE interface and strong data retention
ability, 44-Pin IDE Flash Modules are ideal for use in
harsh environments where Industrial PCs, Set-Top
Boxes, etc. are used.
Placement
Features
•
RoHS
compliant
•Power supply: 3.3V
±
5% or 5V
±
10
%
•Operating temperature: 0oC to 70oC
•
Storage
temperature:
-40
o
C
to
85
o
C
•
Humidity
(Non
condensation)
:
0%
to
95%
•
Built-
in
72
bit
per
1K
Byte
ECC
(Error
Correction
Code)
functionality to ensure high reliability of data transfer
•
Global
wear-leveling
algorithm
to
eliminate
excessive
write operation and extend product life
•
Supports
S.M.A.R.T
(Self-defined)
•
Supports
Security
Command
•Supports Host Protected Area
•Supports Ultra DMA Mode 0 to 5
•
Supports
Multiword
DMA
Mode
0
to
2
•
Supports
PIO
Mode
0
to
4
•
Durability
of
connector:
100
times
•MTBF: 1,000,000 hours (in 25 C)°
Dimensions
Side Millimeters Inches
A46.00 0.40 1.81 0.016± ±
B28.00 0.20 1.10 0.008± ±
C6.00 0.50 0.24 0.020± ±
Specifications
Physical Specification
Form Factor
Storage Capacity 128 MB to 4 GB
Dimensions (mm)
Length 52.00 ±0.40
Width 29.50 0.50±
Height 7.20 0.20±
Input Voltage 3.3V ±5% or 5V ±10%
Connector 44 pin IDE female connector (Horizontal)
Environmental Specifications
Operating Temperature 0 to 70 ℃ ℃
Storage Temperature - 40 to 85 ℃ ℃
Humidity Operating 0% to 95% (Non-condensing)
Non-Operating 0% to 95% (Non-condensing)
Reliability
Data Reliability Supports BCH ECC 72 bit per 1K byte
Connector Durability 100 times
MTBF 1,000,000 hours
TBW TBT
Regulations
Compliance CE, FCC and BSMI
Note: 25 oC, test on GA-Z87-UD3H-CF, 4GB RAM, Windows®8.1 with AHCI mode, benchmark utility Crystal Disk Mark (version 3.0), copied file 1000MB.
Actual Capacity
Model P/N User Max. LBA Cylinder Head Sector
TS512MPTM820 1,000,944 993 16 63
TS1GPTM820 1,957,536 1,942 16 63
TS2GPTM820 3,915,072 3,884 16 63
Performance
Model P/N Read Write Random Read
(4KB QD32)
Random Write
(4KB QD32)
TS512MPTM820 20.79 MB/s 7.637 MB/s 8.139 MB/s 0.338 MB/s
TS1GPTM820 20.85 MB/s 13.75 MB/s 6.382 MB/s 0.237 MB/s
TS2GPTM820 20.57 MB/s 22.45 MB/s 6.308 MB/s 1.091 MB/s
