MOBILE POWER AMPLIFIERSMOBILE POWER AMPLIFIERS

Ultimate Sound, Inc.

138 University Parkway

Pomona, CA 91768

Toll Free: 888- -909 9988

Telephone: 909- -594 2604

Fax: 909- -594 0191

TA4600TA4600

4 X 250 WATT

4 CHANNEL AMPLIFIER

4 X 140 WATT

4 CHANNEL AMPLIFIER

TA4320TA4320

2 X 250 WATT

2 CHANNEL AMPLIFIER

TA2300TA2300

2 X 165 WATT

2 CHANNEL AMPLIFIER

TA2160TA2160

2 X 600 WATT

2 CHANNEL AMPLIFIER

TA2700TA2700

INTRODUCTION

I. Description

This device is a high power, audio amplifier. Use it responsibly. Very

loud music can cause permanent hearing loss. This amplifier is intended

for installation in vehicles with a 12-Volt, negative ground electrical

system. Attempting to connect or operate the amplifier in another type of

electrical system may cause damage to the amplifier or the electrical

system.

II. About This Manual

Read the Instructions-

Be sure that you have read all operating instructions and understand all

safety precautions before installing and operating the amplifier. We

recommend that you have your

TATA series amplifier installed by a

specialist.

Follow the Instructions-

The instructions are intended to help you safely obtain the best

performance from the amplifier. Carefully follow all installation and

operating instructions.

Save the Operating Manual-

Keep the manual in a safe place after installing the amplifier. You may

have questions later.

Text Conventions used in this Manual-

Bold-

Headings and important information.

Bold, Underlined-

Very important information.

"Bold"-

As labeled on the amplifier, or quoted from elsewhere in this

manual.

III. Safety and Operating Precautions-

Caution!

This symbol warns the user of a potential risk or hazard if instructions are

not followed.

⇒ This arrow symbol points to a specific instruction for avoiding a

potential hazard.

1. Installation

1.1 Installation- Mounting the Amplifier

Step 1- Disconnect the negative (-) battery cable before mounting the

amplifier or making any connections. Check the battery and alternator

ground (-) connections. Make sure they are properly connected and free of

corrosion

Step 2- Choose a mounting location for your amplifier. Find a location

on a flat surface away from heat and moisture. Be sure the mounting

location and the drilling of pilot holes for mounting will not present a

hazard to any wires, control cables, fuel lines, fuel tanks, hydraulic lines,

or other vehicle systems or components. Common mounting locations are

under the front passenger seat, or in the trunk area. Choose a location

with unimpaired air circulation. The amplifier will dissipate heat more

efficiently if mounted vertically.

Step 3- Use the supplied screws. Place the amplifier in the mounting

location, and mark the positions of the holes with a marker, pen or pencil.

Carefully drill the mounting holes in the marked positions.

Caution!

⇒ Check carefully before drilling any pilot holes.

Step 4- Use the supplied mounting screws to securely fasten the amplifier

to the mounting surface.

1.2 Installation- Power Connections

Step 1- Run a power cable from the battery to the amplifier mounting

location. Use rubber grommets to protect the cable anywhere it has to go

through metal.

TA4600, TA4320, TA2700, TA2300TA4600, TA4320, TA2700, TA2300 - Use #8 AWG or larger power

and ground cable.

TA2160TA2160 - Use #10 AWG or larger power and ground cable.

Step 2- Connect one end of an in-line fuse holder to the power cable.

Connect the other end of the fuse holder to the positive battery post with

20 cm (or less) of the same cable. This fuse location will protect the

system and the vehicle against the possibility of a short circuit in the

power cable. Be sure to use a fuse and fuse holder adequate for the

application. Do not place a fuse in the holder at this time.

The maximum fuse rating for each amplifier in the

TATA

series is:

TA4600 TA4600 -- 2 X 30 Amp TA4320 TA4320 -- 40 Amp

TA2700 TA2700 -- 2 X 30 Amp TA2300 TA2300 -- 30 Amp

TA2160 TA2160 -- 20 Amp

P O W E RP O W E R

+12 V R M T G N D+12 V R M T G N D

Caution!

⇒ Bridging fuses or replacing a fuse with one of a higher rating may

cause damage to the amplifier and the vehicle's electrical system.

Step 3- Run a remote turn on cable from the switched +12V source you

will be using to turn on the system components. This may be a toggle

switch, a relay, or your source unit’s remote trigger wire, or power

antenna trigger wire. Run this lead to the amplifier mounting location.

Use #18 AWG wire or larger.

Step 4- Locate a secure grounding connection as

close to the amplifier as possible. Make sure the

location is clean and provides a direct electrical

connection to the frame of the vehicle. Connect

one end of a short piece of the same size cable as

the power cable to the grounding point. Run the other end of the cable to

the amplifier mounting location.

Step 5- connect the ground cable to the screw terminal labeled

“POWER, GND”.

Step 6- Connect the power cable to the amplifier at the screw terminal

labeled “POWER, +12V”.

Step 7- Connect the remote turn on cable to the screw terminal labeled

“POWER, RMT”.

1.3 Installation- Speaker Connections

Step 1- Run #16 AWG or larger connecting wire from your speakers to

the amplifier mounting location. Keep speaker wires away from power

cables and amplifier input cables. Use grommets anywhere the wires have

to pass through holes in the metal frame or sheet metal. Connect to the

speakers according to the type of terminals on each speaker.

Step 2- Strip 3/8" of insulation from the end of each wire and twist the

wire strands together tightly. Make sure there are no stray strands that

might touch other wires or terminals and cause a short circuit.

Step 3- Crimp spade lugs over the wire ends or tin the ends with solder to

provide a secure termination.

Step 4- Connect the wire ends to your amplifier as follows:

SPEAKER TERMINALS

Follow the (A/B/C/D+) (A/B/C/D-), channel and polarity markings,

making sure they match the channel and polarity of the connections at

the speakers.

MULTIPLE SPEAKER CONNECTION

PARALLEL- Each additional speaker decreases the load impedance

for the amplifier. The amplifier delivers more current and works

harder.

(+)

(-)

(+)

(-)

4 Ohm 2 Ohm

PARALLEL CONNECTION USING 4 OHM SPEAKERS

(A+) (A-) (B+) (B-)

( + ) ( - )

BRIDGE

SPEAKER

(C+) (C-) (D+) (D-)

( + ) ( - )

BRIDGE

SPEAKER

(A+) (A-) (B+) (B-)

( + ) ( - )

BRIDGE

SPEAKER

SERIES- Each additional speaker increases the load impedance for

the amplifier. Impedances higher than 8 ohms are rarely used for car

audio.

1.4 Installation- - Self Bridging, 2+1 Mode

BRIDGED MONO-

Connect a 4Ω ohm speaker to the

terminals marked “(+), BRIDGE, (-)”,

making sure they match the polarity

of the connections at the speakers.

Caution!

⇒ Speaker or multiple speaker loads

totaling less than 4 ohms are not

recommended for “Bridged” or

“2+1 Mode”, and may damage the amplifier.

TA4600, TA4320TA4600, TA4320--

Set the “MODE” switch to “2CH, 3CH”, or “4CH” and connect the

speakers accordingly. For “3CH” operation, bridge the “C” and “D”

channels.

2+1 MODE- - (TRI MODE)

Simultaneous stereo and mono operation, “2+1 Mode”, requires a passive

crossover to send low frequencies to the mono speaker and higher

frequencies to the stereo speakers. The following table lists the

component values for a 6 dB/Octave crossover at common frequencies

using 4 ohm speakers for stereo and an 8

Ω speaker for mono(subwoofer):

FREQUENCY INDUCTOR CAPACITOR

80 Hz 16 mH 470 uF

100 Hz 7.5 mH 330 uF

120 Hz 7.5mH 330 uF

150 Hz 7.5 mH 220 uF

(+)

(-)

(+)

(-)

4 Ohm 8 Ohm

SERIES CONNECTION USING 4 OHM SPEAKERS
