MOBILE POWER AMPLIFIERSMOBILE POWER AMPLIFIERS
Ultimate Sound, Inc.
138 University Parkway
Pomona, CA 91768
Toll Free: 888- -909 9988
Telephone: 909- -594 2604
Fax: 909- -594 0191
TA4600TA4600
4 X 250 WATT
4 CHANNEL AMPLIFIER
4 X 140 WATT
4 CHANNEL AMPLIFIER
TA4320TA4320
2 X 250 WATT
2 CHANNEL AMPLIFIER
TA2300TA2300
2 X 165 WATT
2 CHANNEL AMPLIFIER
TA2160TA2160
2 X 600 WATT
2 CHANNEL AMPLIFIER
TA2700TA2700
ii
INTRODUCTION
I. Description
This device is a high power, audio amplifier. Use it responsibly. Very
loud music can cause permanent hearing loss. This amplifier is intended
for installation in vehicles with a 12-Volt, negative ground electrical
system. Attempting to connect or operate the amplifier in another type of
electrical system may cause damage to the amplifier or the electrical
system.
II. About This Manual
Read the Instructions-
Be sure that you have read all operating instructions and understand all
safety precautions before installing and operating the amplifier. We
recommend that you have your
TATA series amplifier installed by a
specialist.
Follow the Instructions-
The instructions are intended to help you safely obtain the best
performance from the amplifier. Carefully follow all installation and
operating instructions.
Save the Operating Manual-
Keep the manual in a safe place after installing the amplifier. You may
have questions later.
Text Conventions used in this Manual-
Bold-
Headings and important information.
Bold, Underlined-
Very important information.
"Bold"-
As labeled on the amplifier, or quoted from elsewhere in this
manual.
III. Safety and Operating Precautions-
Caution!
This symbol warns the user of a potential risk or hazard if instructions are
not followed.
This arrow symbol points to a specific instruction for avoiding a
potential hazard.
1
1. Installation
1.1 Installation- Mounting the Amplifier
Step 1- Disconnect the negative (-) battery cable before mounting the
amplifier or making any connections. Check the battery and alternator
ground (-) connections. Make sure they are properly connected and free of
corrosion
Step 2- Choose a mounting location for your amplifier. Find a location
on a flat surface away from heat and moisture. Be sure the mounting
location and the drilling of pilot holes for mounting will not present a
hazard to any wires, control cables, fuel lines, fuel tanks, hydraulic lines,
or other vehicle systems or components. Common mounting locations are
under the front passenger seat, or in the trunk area. Choose a location
with unimpaired air circulation. The amplifier will dissipate heat more
efficiently if mounted vertically.
Step 3- Use the supplied screws. Place the amplifier in the mounting
location, and mark the positions of the holes with a marker, pen or pencil.
Carefully drill the mounting holes in the marked positions.
Caution!
Check carefully before drilling any pilot holes.
Step 4- Use the supplied mounting screws to securely fasten the amplifier
to the mounting surface.
1.2 Installation- Power Connections
Step 1- Run a power cable from the battery to the amplifier mounting
location. Use rubber grommets to protect the cable anywhere it has to go
through metal.
TA4600, TA4320, TA2700, TA2300TA4600, TA4320, TA2700, TA2300 - Use #8 AWG or larger power
and ground cable.
TA2160TA2160
-
Use #10 AWG or larger power and ground cable.
Step 2- Connect one end of an in-line fuse holder to the power cable.
Connect the other end of the fuse holder to the positive battery post with
20 cm (or less) of the same cable. This fuse location will protect the
system and the vehicle against the possibility of a short circuit in the
power cable. Be sure to use a fuse and fuse holder adequate for the
application. Do not place a fuse in the holder at this time.
The maximum fuse rating for each amplifier in the
TATA
series is:
TA4600 TA4600
--
2 X 30 Amp
TA4320 TA4320 --
40 Amp
TA2700 TA2700
--
2 X 30 Amp
TA2300 TA2300 --
30 Amp
TA2160 TA2160 --
20 Amp
2
P O W E RP O W E R
+12 V R M T G N D+12 V R M T G N D
Caution!
Bridging fuses or replacing a fuse with one of a higher rating may
cause damage to the amplifier and the vehicle's electric
al system.
Step 3- Run a remote turn on cable from the switched +12V source you
will be using to turn on the system components. This may be a toggle
switch, a relay, or your source unit’s remote trigger wire, or power
antenna trigger wire. Run this lead to the amplifier mounting location.
Use #18 AWG wire or larger.
Step 4- Locate a secure grounding connection as
close to the amplifier as possible. Make sure the
location is clean and provides a direct electrical
connection to the frame of the vehicle. Connect
one end of a short piece of the same size cable as
the power cable to the grounding point. Run the other end of the cable to
the amplifier mounting location.
Step 5- connect the ground cable to the screw terminal labeled
“POWER, GND.
Step 6- Connect the power cable to the amplifier at the screw terminal
labeled POWER, +12V”.
Step 7- Connect the remote turn on cable to the screw terminal labeled
“POWER, RMT.
1.3 Installation- Speaker Connections
Step 1- Run #16 AWG or larger connecting wire from your speakers to
the amplifier mounting location. Keep speaker wires away from power
cables and amplifier input cables. Use grommets anywhere the wires have
to pass through holes in the metal frame or sheet metal. Connect to the
speakers acc
ording to the type of terminals on each speaker.
Step 2- Strip 3/8" of insulation from the end of each wire and twist the
wire strands together tightly. Make sure there are no stray strands that
might touch other wires or terminals and cause a short circuit.
Step 3- Crimp spade lugs over the wire ends or tin the ends with solder to
provide a secure termination.
Step 4- Connect the wire ends to your amplifier as follows:
3
SPEAKER TERMINALS
Follow the (A/B/C/D+) (A/B/C/D-), channel and polarity markings,
making sure they match the channel and polarity of the connections at
the speakers.
MULTIPLE SPEAKER CONNECTION
PARALLEL- Each additional speaker decreases the load impedance
for the amplifier. The amplifier delivers more current and works
harder.
(+)
(-)
+
-
(+)
(-)
4 Ohm 2 Ohm
PARALLEL CONNECTION USING 4 OHM SPEAKERS
A
M
P
L
I
F
I
E
R
O
U
T
P
U
T
(A+) (A-) (B+) (B-)
( + ) ( - )
BRIDGE
(C+) (C-) (D+) (D-)
( + ) ( - )
BRIDGE
SPEAKER
4
(A+) (A-) (B+) (B-)
( + ) ( - )
BRIDGE
SPEAKER
SERIES- Each additional speaker increases the load impedance for
the amplifier. Impedances higher than 8 ohms are rarely used for car
audio.
1.4 Installation- - Self Bridging, 2+1 Mode
BRIDGED MONO-
Connect a 4 ohm speaker to the
terminals marked (+), BRIDGE, (-)”,
making sure they match the polarity
of the connections at the speakers.
Caution!
Speaker or multiple speaker loads
totaling less than 4 ohms are not
recommended for Bridged or
“2+1 Mode”,
and may damage the amplifier.
TA4600, TA4320TA4600, TA4320--
Set the MODE switch to 2CH, 3CH, or “4CH and connect the
speakers accordingly. For “3CH operation, bridge the C”
and D”
channels.
2+1 MODE- - (TRI MODE)
Simultaneous stereo and mono operation, 2+1 Mode, requires a passive
crossover to send low frequencies to the mono speaker and higher
frequencies to the stereo speakers. The following table lists the
component values for a 6 dB/Octave crossover at common frequencies
using 4 ohm speakers for stereo and an 8
speaker for mono(subwoofer):
FREQUENCY INDUCTOR CAPACITOR
80 Hz 16 mH 470 uF
100 Hz 7.5 mH 330 uF
120 Hz 7.5mH 330 uF
150 Hz 7.5 mH 220 uF
(+)
(-)
+
-
(+)
(-)
4 Ohm 8 Ohm
SERIES CONNECTION USING 4 OHM SPEAKERS
A
M
P
L
I
F
I
E
R
O
U
T
P
U
T
