Sida 1/5

ROSSFIRE

Congratulations on your purchase of a Crossfire

binocular. We know you’ll find this binocular offers

excellent optical resolution and performance—a

tremendous value for all your outdoor experiences.

Binoculars are not intended for looking at the sun, or any other

intense light source. Such viewing could damage the retina and

cornea of your eyes—even to the point of causing blindness.

Caution:

The

Binocular Series

ROSSFIRE

The Crossfire features fully multi-coated optics for

high light transmission and bright images.

Optical Quality.

www.vortexoptics.com

3 4

www.vortexoptics.com www.vortexoptics.com

Center Focus

Diopter Ring

Roof Prism Housing

Objective

Lenses

Center Hinge

Tripod Adapter

Socket

Neckstrap

Attachment

Point

The Crossfire is lightweight, but very rugged and durable.

Sporting an internal focusing mechansim,O-rings at

all open points, and nitrogen purging, this binocular is

waterproof, dustproof, and internally fogproof.

Rugged Design.

Adjustable Eyecup

The Crossfire binocular comes with two tethered

objective lens covers and a one-piece rainguard that

covers the eyepieces. For convenience, the rainguard

can be attached to the

neckstrap where it is within

easy reach. Simply slip

the neckstrap through the

attachment point on the

rainguard before connecting

the neckstrap to the

binocular.

The Lens Covers

The soft case of the Crossfire provides protection for

the binocular when not in use

and comes with a woven nylon

neckstrap for an easy carry in

the field.

The Case

Preparing the Crossfire for Use

5 6

www.vortexoptics.com www.vortexoptics.com

Attach the padded neckstrap to the binocular in

three simple steps. Begin with the right barrel of the

binocular and repeat the process for the left barrel.

The Neckstrap

1. Push a few inches of the

strap through the neckstrap

attachment point on the

binocular.

2. Loop the strap over the

attachment point, then

thread the strap through

the strap buckle.

3. Secure the end of the

strap by slipping it

through the strap loop.

IPD

The eyecups on the Crossfire binocular twist up and

down so any viewer can take advantage of the long eye

relief and enjoy comfortable, full-field viewing.

With eyeglasses or sunglasses,

retract the eyecups.

Without eyeglasses or sunglasses,

extend the eyecups.

Adjusting the Eyecups.

The twist-up eyecups are built on a solid frame and

covered with rubber.

Adjusting the Interpupillary Distance.

The interpupillary distance (IPD) is the distance

between the centers of the left and right eye pupils.

Match the IPD of your eyes

to that of the binocular by

rotating the binocular barrels

inward or outward until you

see a single image that is free of

shading.

Customizing the Crossfire
