Sida 1/16

Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343

Instruction Manual

Extending 4K & 1080p HDMI

using single Cat5e/6

eX-35-4K

WyreStorm Low Prole 4K HDBaseT Extender

Set with 2-Way IR, RS232 and POH

(4K: 35m/115ft - 1080p: 70m/230ft)

Thank you for choosing this WyreStorm product.

Please read these instructions carefully before installing to avoid complications later.

2Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343

Contents

1. Introduction

CONTENTS, INTRODUCTION AND FEATURES

2. Features

Get Real. Think Thin.

Pushing technology and design to the limit, the EX-35-

4K extender set oers long distance HDMI 4K and HD

distribution and control over UTP within an incredibly low

prole chassis of just 15mm for a greatly reduced form

factor behind even the slimmest display wall plate to

make installation a dream.

Featuring streamlined Class B HDBaseT technology

for projects that demand the benets of HDBaseT

transmission, but perhaps do not require full Class

A specication, the EX-35-4K supports 70m/230ft

transmissions of 1080p@60Hz and 36bit Deep Color HD

Introduction

Features

Safety Precautions

Package Contents

Connection & Operation

i. Typical Application

ii. RJ45 Termination & Distance

iii. Initial Connection

iv. IR/RS232 Control Connection

v. Updating RS232 Settings

Maintenance

Product Service

Panel Descriptions

Mail In Service

Warranty

i. Warranty Limits and Exclusions

Installation Notes

Specication

Troubleshooting

General FAQ

audio, 100W power, discrete bidirectional control via IR

and RS232 all along a single Cat5e/6 cable to display

zones.

UltraHD 4K transmissions are supported up to 35m/115ft

over Cat6 at 30fps with chroma sub-sampling color

palette of 4:2:2 and automatic internal handling of EDID

and HDCP 2.2 between connected source/display

devices.

Including serial control support with compatibility with

leading control systems and switchable RS232 selection

for rmware updates, improved 18v power connectivity is

also oered via threaded DC power port for standard and

locking DC power plugs on both transmitter and receiver,

should it be required.

Operation status is illustrated by panel LED indicators for

power supply, signal status for display connection, HDCP

2.2 in signal, and a HDBaseT link indicator to assess

the presence of transmissions and help identify potential

issues.

WyreStorm 4K HDBaseT solutions oer the features,

exibility and compatibility demanded by modern

integrations while future-proong for tomorrow, combined

with an ease of use and cost-eciency for reliable

distribution and control of digital content over distance

whether in a residential or commercial setting.

For further information on this product and other

WyreStorm ranges, visit our website or download our

latest product guide. wyrestorm.com

• Low prole chassis of 15mm / 0.6” for easier, more

convenient installations behind screens at display

zones.

• Extender set capable of HDMI transmissions using

single cable Cat5e/6 cable under recommended

conditions*:

- 35m/115ft: 3840 (UHD) 4096 (DCI) 2160 4K

video/24bit True Color @30Hz with 4K Chroma

subsampling color palette 4:2:2

- 70m/230ft: 1920x1080p HD video/36bit Deep

Color@60Hz

• Transmits discrete wide-band two-way IR control

signal / serial commands together within the HDMI

signal over a single Cat5e/6

• One-way PoH (Power over HDBaseT) 18v DC locally

powered Transmitter passes power along the Cat5e/6

to remotely power the Receiver - no mains power

required at display zones

Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343

SAFETY PRECAUTIONS AND PACKAGE CONTENTS

3. Safety Precautions

WARNING

To reduce the risk of re, electric shock

or product damage:

• Cable termination follows IEEE-568B standards

• Multichannel audio supports 7.1 DTS Master HD and

Dolby True HD

• Robust Class B HDBaseT transmission technology

for stable 4K/HD distribution and control resistant

to electrostatic and environmental interference

compared to conventional UTP transmission

• Supports all high denition resolutions: 4K UHD &

DCI), 1080p, 1080i, 720p with screen refresh rates

support of 24Hz, 30Hz (4K) 50Hz and 60Hz (1080p)

• HDMI v1.4 with full 3D compatibility up to 1080p -

frame packing/sequential (Blu-Ray) and interlaced

stereoscopic (satellite/ cable broadcasts)

• Switchable RS232 fucntion mode on Transmitter and

Receiver for rmware update

Note: Serial control via RS232 only supported when

connected to a compatible HDBaseT transmission

device. Check website or contact WyreStorm

representative for compatibility

• Receivers cascadable up to 7 times within a single

output zone using another EX-35-4K Transmitter or

compatible HDBaseT transmission device

• Threaded bushings on allow use of both standard and

locking DC power plugs

• Visual LED indication for power supply to units, signal

status to show established display connection, HDCP

2.2 presence in signal and HDBaseT link

• HDCP 2.2 compliant

• Automatically adjusts feedback, equalization and

amplication of signal for easy installation

• Energy ecient universal power supplies included

• Mounting brackets and IR connections included

*Recommended transmission conditions - cable

run within specied distance range of product, no

electrical interference, the use of straight cable runs

with no bends or kinks and no patch panels or wall

outlets used. Please be advised that the presence

of any of these factors in your installation may

compromise bandwidth and signal strength.

1. Do not expose this apparatus to rain, moisture,

sprays, drips or splashes and ensure that no

objects containing liquids are placed on the

apparatus, including cups, glasses and vases.

2. Do not place this unit in a conned space such as

enclosed shelving, cabinets or bookshelves.

Ensure the unit is adequately ventilated.

3. To prevent the risk of electric shock or re hazard

due to overheating, do not cover the unit or

obstruct ventilation openings with material,

newspaper, cardboard or anything that may restrict

airow into the unit.

4. Do not install near external heat sources such as

radiators, heat registers, boilers or any device that

produces heat such as ampliers or computers and

do not place near sources of naked ame.

5. Unplug apparatus from power supply during

lightening storms or when unused for long periods

of time.

6. Protect the power cable from being walked on,

pinched or restricted in any way, especially at plug

connections.

7. Only use attachments/accessories specied by the

manufacturer.

8. Units contain non-servicable parts - Refer all

servicing to qualied service personnel.

4. Package Contents

WyreStorm EX-35-4K extender set comprising of:

1 x TX-35-4K Transmitter

1 x RX-35-4K Receiver

1 x 18V DC 1A universal power supply

2 x 3.5mm phoenix male connector (3 pin)

2 x Wide-band IR emitter

2 x Wide-band IR receiver (30-50KHz)

2 x Pairs of EX-35-4K mounting brackets

1 x Printed Quickstart guide*

*Quickstart and full manual downloadable from product

page at wyrestorm.com
