Sida 1/4
Step 7. Final Adjustment
Installation Complete
Your Telehook Wall Mount Swing Arm is complete and ready to use.
Position and angle your Display as desired, ensuring the Swing Arm moves freely.
Adjust the tension of the joints to suit, using the Allen Keys supplied.
4mm Allen Key
6mm Allen Key
As Display Manufacturers are constantly releasing new monitor models, Atdec does not accept responsibility if the VESA mounting does not comply with the international standards.
Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. Published: 27.11.09 ©
LOOSEN
T GHTENI
LOOSEN T GHTENI
Step 6. Cable Management
127( Leave enough
slack in the cables to
allow for full movement.
Connect cables
Cable Cover (x2)
Cable Clip
To utilise the Telehook Swing Arm cable
management system, use the Cable Covers
and Cable Clip as shown.
IM A I F MA IPORT NT N OR T ON
,03257$17,QVWDOO7HOHKRRN:DOO0RXQW6ZLQJ$UPDVSHU ,QVWDOODWLRQ,QVWUXFWLRQVWKH
! Telehook Wall Mount Swing Arm supports displays weighing up to 20kg (44lbs), with VESA hole configurations:
75x75mm (3”x3”), 100x100mm (4”x4”), *200x100mm (8”x4”), and *200x200mm (8”x8”) (*using extension tabs supplied)
! The Manufacturer accepts no responsibility for incorrect installation.
Step 1. Check Components
Check you have received all parts against the Component Checklist and Hardware above.
Step 2. Installing the Wall Bracket
Component Checklist
Stud
Masonry Wall
Nylon Anchor (x2)
Wall Mount
Screw (x2)
Wall Mount
Screw (x2)
Wall Material
H ward are
Flat Screen Wall Mount | Swing Arm
Installation Instructions
70
OR
TOOL RE RES QUI D:
Power Drill
4mm ( 5/32”) Drill Bit
11mm ( 7/16
”) Masonry Drill Bit
Phillips Head Screwdriver
Spirit Level
Mounting to a Mounting to a 7LPEHU6WXG:DOO 0DVRQU\:DOO:
7+9)0
Swing Arm
Vesa Plate
- Position the Wall Bracket vertically on the wall and mark the
2 mounting holes (use a spirit level to check).
- Drill two 60mm (23/8“) deep holes using an 11mm (7/16”)
masonry drill bit.
- Secure the Wall Bracket using the Wall Mount Screws and
Nylon Anchors supplied.
- Position Wall Bracket vertically on the wall and mark the
2 mounting holes (use a spirit level to check).
- Drill two 60mm (23/8”) deep holes using a 4mm (5/32 ”) drill bit.
- Secure the Wall Bracket using the Wall Mount Screws supplied.
2.5mm Allen Key
4mm Allen Key
5mm Allen Key
6mm Allen Key
Washer (x4)
Nylon Anchor (x2)
Wall Mount Screw (x2)
Wall Bracket
Extension
Tabs (x4)
E wxtension Mounting Scre s
M4x12mm/M4x16mm (x4 each)
M5x12mm/M5x16mm (x4 each)
M6x12mm/M6x16mm (x4 each)
Display Mounting Scre sw
M5x12mm (x4)
75 or 100mm
VESA
Top of
Display
Ste 4. Att ch the VESA te t ur p a pla o yo Display
Fasten the VESA plate to your Display using the Display Mounting screws and Washers provided.
Select the appropriate size screw to suit your Display.
Display Mounting Screw (x4)
Top of VESA plate
Washer (x4)
Display Mounting hole
Back of Display
Ste 3. Att ch the Exten n b t the VESA te p a sio Ta s o pla (optional)
Only use the Extension Tabs if the display you wish to mount has a 200x200mm (8”x8”),
or 200x100mm (8”x4”) VESA hole mounting configuration.
If not, skip to Step 4.
200mm (8”)
200mm (8”)
Secure the Extension Tabs to the VESA plate using
the M5x12mm Extension Mounting Screws supplied.
M5x12mm
Screw (x4)
Extension
Tab (x4)
VESA
plate
TIGHT NE
FIRMLY
OPTION - 200 200mm (8” 8”)A x x
200mm (8”)
OPTION B - 200 100mm (8” ”)x x4
100mm (4”) Extension
Tab (x4)
VESA
plate
M5x12mm
Screw (x4)
TIGHT NE
FIRMLY
NOTE: Position the Extension Tabs to
suit your display mounting hardware.
Large Hole
(M6-M8)
Small Hole
(M4-M5)
( required)
Ste 5. Att ch ur t the Sw ng Arp a yo Display o i m
Back of
Display
bb
TIGHT NE
Tighten both grub screws with the
2.5mm Allen Key supplied.
Slot the VESA plate on to the Swing Arm.
Ensure the display is level,
using the horizontal
adjustment.
+/- °5
r t t no a io
5mm
Allen Key
