www.avsl.com 100.575UK

True Wireless Earphones & Power Case

Ear Shots

Item ref: 100.575UK

User Manual

Ear Shots: a unique pair of earphones, designed to stand out and stay put. Portable, lightweight and featuring true wireless technology, providing

impressive audio performance without the hassle of tangling wires. The ergonomic design ensures the earphones securely fit in your ear. Comes with

dynamic drivers for a deeper, more immersive sound experience and the latest Bluetooth connectivity for ultimate device compatibility. The handy

power case not only stores your earphones when not in use but also charges them, providing up to hours listening time for music on- -go. An 12 the

inbuilt microphone and hands-free function allow for more freedom when answering calls.

Features

• Compact, lightweight and ergonomic design

• Dynamic drivers for deep, immersive sound

• Bluetooth 5.0 connectivity provides hassle-free pairing

• Up to 10m wireless range

• Rechargeable with 400 Power Case mAh

• Inbuilt mic for hands-free calls

• iOS and Android compatible

In the Box

• 2pcs True wireless earphones

• Chargeable Power Case

• USB charging cable

• User guide

Technical Specifications

Speaker Driver

10mmØ dynamic

Frequency Response

20Hz -20kHz

Sensitivity

Earphones: ≥98dB, Microphone:-42dB

Impedance

32 Ohms

Power: Battery

Earphones: 2x internal 40mAh, Power Case: 400mAh

Battery Life (hours)

Earphones: 3 hours max, Power Case: Up to 9 additional hours playback

Standby Time

120 hours (approx.)

Charge Time

Earphones: 60 mins (approx), Power Case: 2 hours (approx)

Connections

Bluetooth 5.0, Micro USB (for charging the Power Dock)

Bluetooth Range

Up to 10m (clear line of sight)

Dimensions

Earphones: 45mm long x 16mm Ø, Power Case: 55 x 45 x 22mm

Weight:

Earphones: 2x 4g, Power Case: 38g (inc. earphones)

Overview

LED

indicators

b uttons

Charging

button

www.avsl.com 100.575UK

Before first use:

Even though your Ear Shots will come with some battery charge, it s advisable to fully charge them before first use. Connect the Power Case and ’

earbuds to a suitable USB power source and leave for around 2 hours to ensure they are ready for use. When charging, the Power Case LED will flash

blue and when fully charged it will stop flashing.

Pairing in True Wireless mode:

On first use, you need to pair the earbuds to each other and then your device. Press and hold the button both earbuds for around 5 seconds MF on

until the LED indicators flash red and blue and a voice guide says “pairing”. Next, double press the MF button on one earbud and it will then begin

searching for the other. Once they are paired with each other you will hear a beep then a voice message saying “connected” followed by flashing blue

L s both earbuds. The earbuds are now in Bluetooth pairing mode and ready for you to connect to your smart device. Open the Bluetooth device ED’on

list on your device and search for the pairing name “AV:LINK EAR SHOTS” and select. If asked for a pairing code, please enter “0000” and your

device should connect with the earphones and you will hear a voice message saying “connected” as confirmation. You are now ready to begin enjoying

the true wireless sound experience AV:Link Ear Shots. of

Track control:

Once connected to your smart device you can use the MF bu s on the earbuds to control your music and phone calls After selecting a track press tton .

the MF button once on either earbud to play then pause the current track. Double press the MF button on either earbud to enable your devices voice

assistant. Y can then speak your command and the microphone in the earbuds will relay it to your smart device. Press the MF button three times ou on

the right earbud to increase the volume and the left earbud to decrease the volume accordingly. Press and hold the MF button on the right earbud to

move to the next track and the left earbud to move to the previo track in your playlist. us

Hands-free operation

When you receive a phone call during audio playback, a voice telling you the caller’s telephone number can be heard. To accept the call, press the MF

button either earbud once. To reject the call, press the button on either earbud twice When you have completed call, hang up by press on MF . the ing

the button either earbud once. MF on

Disconnecting and reconnecting to your device

To disconnect and switch off the earphones, press and hold the button on either earbud for 2-3 seconds, until the LED indicator turns red. Both MF

earphones will switch off at the same time and you will hear a voice message saying “power off”. To reconnect to the same device, press and hold the

MF button on both earbuds for 2-3 seconds, until the LED indicators turn red and blue. e earphones will pair to your device automatically and a voice Th

message saying “connected” will be heard.

Charging the earbuds

To charge the earbuds, carefully place them in the corresponding magnetic ports the Power se and press the charging button on the back of the of Ca

case once. The LED indicators on the Power Case will light blue and the earbuds red. When charging is complete, the LED indicators will all go out. To

fully charge the earbuds from ‘flat’ usua takes ound mins. To Stop charging the earbuds at any time, press the charging button on the Power lly ar 60

Case again and the charging lights will go out.

The Power Case

The Power Case is compact, magnetic carry case and power bank, with capacity charge the earphones up to 3 times. To charge the Power a to fully re

Case, connect it to a compatible USB power socket using the USB cable provided. When charging, the LED indicator on the front of the Power Case will

flash red and when fully charged, it will light constant red.

FAQ

Q) The Bluetooth phones will not pair with device. Check that the phones are in pairing mode; Bluetooth is enabled on your device; and ear your A) ear

the device is set as ‘discoverable’.

Q) The Bluetooth phones disconnect with m device within the stated 10 transmission distance. ear y m A) The maximum transmission distance stated is

dependent clear line of sight between the phones and your device. If there are large metallic objects or other devices transmitting radio or on a ear

wirele signals in the vicinity, they may impact on the reception of the phones. ss ear

Q) The Bluetooth phones won reconnect with my device. ear ’t A) On occasion, your Bluetooth device or the earphones may enter a locked state and

need resetting. To do this, find the earphones in your device list and select “forget this device”. Then, refollow the instructions for “Disconnecting

and reconnecting to your device ”, above.
