www.avsl.com 100.5 78UK

ANC True Wireless Earphones with LED Screen

Ear Shots Pro LED

Item ref: 100.5 78UK

User Manual

Introducing Ear Shots Pro LED, the earphones that immerse you in a world of breathtaking audio free from distraction. Active noise cancelling technology blocks out

background noise allowing you to focus solely on the music. Bluetooth 5.4 connectivity gives you freedom to listen wirelessly wherever you go, with up to 5 hours of

continuous playback from a single charge. The innovative charging case delivers an additional 20 hours of playtime and incorporates a bright and responsive LED touch

screen for control of your music and calls without needing access to your device.

Features

• Active noise cancelling for immersive sound free from distraction

• LED touch screen for control of your music and calls at your fingertips

• Earbuds provide up to 5 hours listening on a single charge

• Bluetooth 5.4 connectivity for optimum transmission and connection speed

• Customisable silicone ear tips ensure a snug fit

• Built-in microphone for hands-free calls

• iOS and Android compatible

In the Box

• 2pcs earbuds

• LED charging case

• USB charging lead

• Spare earbud tips

• User guide

Technical Specifications

Speaker Driver

13 dynamic mmØ

Frequency Response

20Hz -20kHz

Noise Cancellation

30-35db

Impedance

32 Ohms

Power: Battery

30mah each earbud, 300mah charging case

Battery Life (hours)

5h earbuds @ 50% volume, 20h charging case

Charge Time

1h for earbuds, 1h for dock

Bluetooth Version

V5.4

Bluetooth Range

Up to 10m (clear line of sight)

Dimensions

23 x 45 x 60mm

Weight:

65g

Overview

Touch control panels

LED touch screen

USB-C charging port

Speaker

Screen/reset

button (back)

www.avsl.com 100.5 78UK

Before first use

Even though your Ear Shots Pro LED will come with some battery charge, it s advisable to fully charge them before first use. Connect the charging case with earbuds inside ’

to a suitable USB power source using the lead provided and leave for around 1 hour to ensure they are ready for use. When charging, the charging case LED screen will

display the current battery percentage.

Pairing to your device

Ear Shots Pro LED are fitted with an intelligent chipset that allows instant pairing on smart devices. To enter pairing mode simply open the lid of the charging case and the

LED screen will show an animation of the case opening Open the Bluetooth list on your smart device . and search for the pairing name “ ” and selectEar Shots Pro LED .

Once paired you can reconnect or disconnect to your device at any time by simply opening and closing the lid on the charging case. Remove either earbud for mono audio or

hands-free calls or both earbuds to experience the amazing immersive stereo sound experience of Ear Shots Pro LED.

Play/pause

Each earbud has a multi-function touch control panel which is located on the inside surface of the earbud stalk (see Overview above). To play or pause the current track, tap

the panel on either earbud once.

Next track/previous track

To move to the next music track, tap the touch contro panel on either earbud twice to move to the previous track either earbud 3 times. l or tap

Increase/decrease volume

To increase the master volume, hold then swipe the touch control panel upwards on either earbud to decrease the master volume hold then swipe downwards on either ,

earbud.

ANC mode select

Earshots Pro LED are fitted with an Active Noise Cancelling chipset, which allows you to block out various background noise using different settings. To scroll through the 3

ANC settings (ANC Off, ANC On and Transparency mode) press and hold the touch control panel on either earbud for 3 seconds.

ENC Hands-free operation

Ear Shots Pro LED incorporate ENC technology which is designed to eliminate background noise during hands-free calls. When you receive a call whilst wearing the earbuds,

a call announcement can be heard. To accept the call, press the touch panel on either earbud once or to reject the call press it twice When you have completed the call, MF .

hang up by pressing the touch panel on either earbud again. MF

Operation using the charging case LED screen

The charging case on Ear Shots Pro LED is fitted with an innovative LED touch screen which enables you to control various functions your connected device without of

needing to pick it up. There are 14 different control screens which can be accessed by swiping either left or right gently on the touch screen. These screens enable you to

play and pause the current track, increase or decrease the master volume, access the various ANC settings, adjust the graphic equalizer sound modes, set a countdown

alarm, adjust the light level of the LED screen, change the touch screen operating language, change the wallpaper, access the find my earphone function if you misplace one

or both of your earbuds, display or adjust the current date and time settings, “Like” a track in your playlist, take a photo remotely using your connected device, turn on or off

the touch tone/touch to wake screen/ear detection settings and use the LED flashlight function. When the LED touch screen is in sleep mode you can wake it by NOTE:

either pressing the screen/reset button on the back of the case or by tapping the screen twice (if enabled in touch to wake menu).

Charging the earbuds and case

To charge the earbuds, carefully place them in the corresponding magnetic ports of the charging case and close the lid. It usually takes around 1 hour to fully charge the

earbuds from ‘flat’. The charging case is compact, magnetic carry case and power bank, with capacity fully charge the earbuds up to 4 times. To charge the charging a to re

case, connect it to a compatible USB power socket using the charging cable provided.

Resetting the earphones

If you encounter any problems with your Ear Shots Pro LED the best solution is to perform a factory reset, erase them from your smart device and start again. To perform

this procedure first return the earbuds to the charging case close the lid then press and hold the screen/reset button on the back. Next open the Bluetooth device list on ,

your smart device and look for and select. Click on then repeat the procedure as seen above. “Ear Shots Pro LED” “Forget this device” “ ”Pairing to your device

FAQ

Q) A) Ear Shots Pro LED will not pair with device. my Check that the earphones are in pairing mode; Bluetooth is enabled on your device; and the device is set as

‘discoverable’.

Q) A) Ear Shots Pro LED disconnects with my device within the stated 10 transmission distance. m The maximum transmission distance stated is dependent on clear line of a

sight between the earphones and your device. If there are large metallic objects or other devices transmitting radio or wireless signals in the vicinity, they may impact on the

reception of the earphones.

Q) Ear Shots Pro LED won reconnect with my device. ’t A) On occasion, your Bluetooth device or the earphones may enter a locked state and need resetting. To do this,

follow the instructions for above. “ ”Resetting the earphones

Q) One of the earbuds drops in and out of signal. A) On occasion there may be something interfering with the connection between each earbud and your smart device which

may cause performances issues. When this happens try moving your smart device nearer to the earbuds or out of bags or pockets where the signal may be weakened. Its

also possible that a low battery in either earbud can cause a loss of signal strength.

Safety Disclaimer

Do not attempt to service this product yourself as opening or removing covers may result in fire, electric shock or equipment damage and will also invalidate

the warranty. This product must be kept away from water and high humidity along with high temperatures and direct sunlight. Prolonged listening at high

volumes can cause hearing damage. Keep away from young children as small parts can be a choking hazard.

This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life.

The goods must be disposed of according to your local council guidelines.
