www.avsl.com 100.598 User Manual UK

Multifunction Audio Convertor

and Bluetooth Receiver

Item ref: 100.598UK

User Manual

An extremely versatile USB powered unit housed in a sleek aluminium chassis that converts Bluetooth and

many other formats of digital audio to analogue. Supplied with an IR remote control and wide range of

connection cables this handy little device is easy to install and operate and is ideal for use with games

consoles, LED TV's, projectors and Blu-Ray players that have no RCA or 3.5mm audio outputs.

Technical Specifications:

Bluetooth version

V5.1

Bluetooth range

15m (obstruction free)

Bluetooth profile

A2DP and AVRCP

Input connections

Bluetooth, Mic, Aux (3.5mm), USB, Toslink, Coaxial

Output connections

AUX (3.5mm), RCA (L&R)

Remote battery

CR2025 (supplied)

Power input

DC/5V (USB lead supplied)

Dimensions

110 x 25 x 85mm

Weight

125g

Application Diagram:

www.avsl.com 100.598 User Manual UK

Connectio ns (front and back):

Remote Control:

Standard operation:

1. Using the correct leads provided connect the unit to the required input and output devices.

2. Using the Power lead provided connect the unit to a suitable 5V USB power supply.

3. Power on by turning the Power/Volume knob on the front of the unit clockwise.

4. Next select the required protocol using either the Input mode switch on the front of the unit or the

relevant button on the remote control.

5. Use either the volume control on the front of the unit or remote control to adjust the volume to a

suitable level for your output media.

6. If any issues occur ensure the connections are made correctly and that the correct protocol is selected

for the input media.

1. Power on/off

2. Previous track

3. Volume down

4. Bluetooth input mode

5. AUX input mode

6. Coaxial input mode

7. Track rewind (USB mode)

8. Loop playback (USB mode)

9. Mute

10. Play/Pause

11. Track fast forward (USB mode)

12. Volume up

13. Optical input mode

14. USB input mode

15. Next track

16. Sequential playback (USB mode)

10.

11.

12.

13.

14.

15.

16.

www.avsl.com 100.598 User Manual UK

Bluetooth connection:

1. Ensure the unit is switched on and your smart device’s Bluetooth is enabled.

2. Enable Bluet mode by either using the Input mode switch on the front of the unit or the BT button ooth

on the remote control.

3. The blue LED on the front of the unit will flash to indicate Bluetooth pairing mode.

4. Next open your smart device s Bluetooth list and search for T02 then select to connect. ’ “ ”

5. If your smart device asks for a pairin code, please enter . g “0000”

6. Once correctly connected the blue LED on the unit will stay lit.

7. You can use some of the function buttons on the remote control for the music tracks on your device.

USB Playback:

1. Insert a compatible USB flash drive into the USB port on the front of the unit.

2. The unit will scan the content on the drive and automatically begin playing the first compatible MP3

track.

3. If the unit fails to detect the drive, try pressing the USB button on the remote control.

4. You are now able to control the MP3 content on the drive using the relevant buttons on the remote

control.

NOTE: Ensure the USB flash drive used is no larger than 32MB in size and formatted in FAT32 to be

compatible with this device.

In The Box:

1. Main unit

2. IR Remote Control

3. DC jack to USB power lead (1m)

4. Fibre optic Toslink lead (1m)

5. AUX (3.5mm) to RCA lead (1m)

6. AUX (3.5mm) to AUX (3.5mm) lead (1m)

7. Coaxial to Coaxial lead (1m)

8. User Manual

Warning:

• For reasons of electrical safety this device must never be immersed in water, exposed to damp conditions

or excessive force.

• Please do not use this device if you find that it is damaged in any way and only use the power lead

provided by the manufacture r.

• When not in use for long periods please disconnect from the power supply.

• Do not attempt to repair this device or take apart under any circumstances, as this will invalidate your

warranty.

This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at

the end of its useful life. The goods must be disposed of according to your local council guidelines.

Errors and omissions excepted.

Taylor Road, Traffor Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland. d
