Sida 1/2

www.avsl.com 100.573 UK

True Wireless Earphones and

Wireless Charging Plate

InFuse

Item ref: 100.573 UK

User Manual

A sleek, compact in-ear fusion of dynamic sound, style and convenience without compromise. Set includes true wireless earphones with Bluetooth connectivity, compact

charging case and wireless charging plate, compatible with not only the earphone case but also the latest wireless charging devices. The sleek earphones fit securely in any

size of ear with touch buttons providing simple control over audio tracks and hands-free phone calls, and true wireless technology offering dynamic sound on the move

without the hassle of tangling wires. An inbuilt microphone and hands-free function allow for more freedom when making and answering calls.

The compact, magnetic charging case is sleek enough to slip safely into a bag or coat pocket, and doubles as a power dock with capacity for up to 3 full charges of the

earphones. When the case runs low on power simply place on the supplied wireless charging plate to recharge your earphones ready for action.

Features

• True wireless technology provides impressive audio performance without

the hassle of tangling wires

• Sleek, compact earphone design for a secure and comfortable fit

• Wireless rechargeable power case and charging plate

• Push button controls handle your music and calls with ease

• Bluetooth v5.0 connectivity provides hassle-free pairing

• Built-in microphone for hands-free calls

• iOS and Android compatible

In the Box

• 2pcs True wireless earphones

• Wireless charging case

• Wireless charging plate

• USB charging cable

• User guide

Technical Specifications

Speaker Driver

10mmØ dynamic

Frequency Response

20Hz -20kHz

Impedance

16 Ohms

Sensitivity

≥93 dB

Power: Battery

Earphones: mAh, Charging case: 350mAh 35

Battery Life (hours)

Earphones 2.5 hours max, Charging case: 7.5 hours :

Charge Time

Earphones: 1.5 hours (approx), Charging case: hours (approx) 3

Bluetooth Range

Up to 10m (clear line of sight)

Power: input

5.0V 2.1A (charging plate)

Power: output

5.0V 1A (charging plate)

Connections

Bluetooth 5.0, Micro USB (charging case and plate)

Dimensions

40 x 18 x 20mm (earphones), 53 x 22 x 43mm (charging case), 95 x 95 x 10mm (charging plate)

Weight:

4g (earphone x2), 28g (charging case), 58g (charging plate)

Overview

LED

indicators

M -function ulti

b uttons

Micro USB

connec tion

Micro USB

connection

LED

indicators

www.avsl.com 100.573 UK

Before first use

Even though your new InFuse headphones will come with some battery charge, it s advisable to fully charge them before first use. Either connect the charging case and ’

earphones to a suitable USB power source using the USB lead provided or place on provided wireless charging plate and leave for around 2 hours to ensure the case and the

earphones are fully charged and ready for use. When charging, the charging case LED will flash red and when fully charged it will go out.

Pairing True Wireless modein

Remove the earphones from the charging case and they will automatically wer on with the voice command , t LED indicators will flash blue and red slowly po “ ”POWER ON he

on bot earphones then they will then attempt to enter TWS mode and pair with each other. If iring is successful, one earphone will flash blue and red quickly, while the h pa

other will flash only blue intermittently and you will hear the voice command . Next open the Bluetooth vice list on your smartphone or “ ”C SUCCESSFULLYONNECT de

tablet and search for the pairing name and select it. Once connection is successful you will hear the voice command “ ”AV:Link InFuse , “ ”CONNECT SUCCESSFULLY

again and both earphones will only flash blue intermittently to i icate they are in paired mode. Once connected the earphones will automatically re-connect to your smart nd

device they are switched on and w hin the 10m transmission range and your device has Bluetooth mode enabled. , if it

NOTE: if TWS pairing is unsuccessfu or to reset the earphones at any time, double click the multi-functi button one of th and they will both flash blue and r l on on em ed

slowly followed by the voice comman It is now possible to use th earphones as individual handsfree devices or to reconnect them with d “ ”DISCONNECT CONNECTION . e

each other by replacing in the charging case and following the pairing procedure above.

Multi-function controls

Both earphones have a multi-function button which can be used to control music and basic function your smart device: s on

1. Play/pause: To play or pause the current track, press the multi-function button on either earphone firmly once.

2. To increase the master volume press the multi-functio button on the right earphone twice and to decrease the master volume repeat the Increase/decrease volume: , n

procedure on the left earphone.

2 Next track/previous track. : To move to the next music track, press the multi-function button on the right earphone three times and to move to the previous track

repeat the procedure on the left earphone.

3 Voice assistant. : To activate your device’s in-built voice assistant (Siri, Alexa etc), press and hold one of the multi-function buttons for around 3 seconds then release.

You will hear the message “Voice dial” prompting you to give your voice command.

Hands-free operation

If you receive a phone call whilst connected to a smartphone, the incoming call number can be heard in both earphones. To accept the call, press the mul -function button ti

on either earphone to reject it press and hold one of the mul - ction buttons for 2-3 seconds. When you have completed the call, hang up by e ing the mul -or ti fun pr ss ti

function button on eith earphone once ain. er ag

Charging the earphones

To charge th earphone place them carefully in the corresponding ports of the case and charging will start automatically. While the earphones are charging, the LED e s

indicator on the charging case will light up blue, and this light will go out when charging is complete. The battery life of the earphone is approx. 1.5 hours, but this will s

depend on the type of music input and volume used.

Charging the case

The charging case is compatible with the wireless charging plate supplied along with any other 5W wireless charging devices st connect the charging plate to a computer . Fir

or suitable USB power supply using the lead provided, then place the case on the centre of the pla facing downwards and charging should start automatically. The LEte D

indicator in the centre of the charging plate will flash blue to indicate charging is taking place, along with the LED indicator on the case flashing red. If charging does not

start, try slightly justing the case position on the plate. Once charging is comp te the LED indicator on the plate will turn red and the one on the case will go out. Its also ad le

possible to connect the USB charging lead provided directly to the charging case without using the plate. I this instanc the charging case light will flash red when charging n e

is taking place and go out when fully charged. The case should take no longer than 3 hours to fully charge and once complete should be removed from the power source to

avoid overcharging an damage to the product. s also possible to use the wireless charging plate supplied in this kit with other compatible smart phones and wireless d It’

charging devices. Simply place the relevant device on the centre of the charging plate to achieve a maximum of 5W wireless charging.

FAQ

Q) A) The earphones will not pair with device. my Check that the earphones are in pairing mode; Bluetoo is enabled on your device; and the device is set as th that

‘discoverable’.

Q) A) e earphones disconnect with my device within the stated 10 transmission distance. Th m The maximum transmission distance stated is dependent on clear line of a

sight betw the earphones and your device. If there are large metallic objects or other devices transmitting radio wireless signals the vicinity, they may impact on the een or in

reception of the earphones.

Q) The earphones won reconnect with my device. On occasion, your Bluetooth device or the earphones may enter a locked state and need resetting. To do this, find the ’t A)

earphones Then, follow t instructions for above. in your device list and select “forget this device”. he “ ”Pairing in True Wireless mode

Q) The charging case won t charge on my wireless charging compatible device’. A) Some wireless charging devices designed for fast charging and may not be compatible are

with the case. Ensure the device you are usin is 5W compatible and that the charging case is placed squarely on the centre of the charging plate. g

Q) The charging plate won t charge my wireless charging compatible device’. A) Some wireless charging devices designed for fast charging and may not be compatible are

with the plate. Ensure the device you are trying to charge is 5W compatible and is placed squarely on the centre of the plate.

Do not attempt to service this product yourself as opening or removing covers may result in fire, electric shock or equipment damage d will also invalidate the warranty. This oduct is an pr

only designed for indoor use and must be kept away from water and high humidity, along with high temperatures and direct sunlight.

This product is classed as Electrical or Electronic equipment and should not be disposed with other house ld or commercial waste at the end of its useful life. The goods must be disposed of according ho

to your local council guidelines.

Hereby, AVSL Group Ltd. declares that the radio equipment type complies with Directive 2014/53 U : 100.573UK /E

The full text of the EU declaration of conformity for 100.5 UK is available at the following internet address: www.avsl.com/assets/doc/1/0/1005 UK.pdf 73 73

Errors and omissions excepted.

Taylor Road, Trafford Park, Manchester M41 7JQ. ,
