AZZA Cube Plus Bruksanvisning
AZZA
Computerbehuizing
Cube Plus
Läs nedan 📖 manual på svenska för AZZA Cube Plus (13 sidor) i kategorin Computerbehuizing. Denna guide var användbar för 4 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/13
Cube
plus
Model
Model Name Cube Plus
Model Number CSAZ-1002
Specifications
Type NCT
Max CPU Cooler Height UP to 200 mm
Max Video Card Length Up to 400 mm long video card
Power Supply Not included
Motherboard Compatibility ATX(Back-connect supported) Micro ATX ITX、 、
External 5.25" Drive Bays 0
Internal 2.5" Drive Bays Up to 1
Internal 3.5" Drive Bays Up to 1
Expansion Slots 7
I/O Ports
Physical Specifications
Dimensions (HxWxD)
Weight
Addressable RGB Light Addressable RGB devices connected to the AZZA HUB can be controlled with
the LED button or motherboard lighting software.
Available Fan Port
3x120mm fan ports in the front (Included FNAZ-12DRGB3/HURRICANE III x 3)
3x120mm fan ports on the mb side
3x120mm fan port in the rear (Included FNAZ-12DRGB3/HURRICANE III x 3)
Water Cooling
Power Supply Support
Features
Expansion
Left side panel: Tempered glass
Power button, LED button, HD Audio Combo, USB 3.0 x 2,Type C x1
Side Panel Window:
689 x 626 x 723 mm / 27.1 x 24.6 x 28.4 inches
Supports radiators up to 360mm in the rear
Supports radiators up to 360mm in the mb side
Bottom mounted ATX Power Supply
12.7 Kg /28 lbs
Included Accessories AZZA Hub(ARGB+PWM controller)
Power button, LED button
HD Audio Combo, USB 3.0 x 2,Type C x1
Front I/O
Produktspecifikationer
| Varumärke: | AZZA |
| Kategori: | Computerbehuizing |
| Modell: | Cube Plus |
