AZZA Noir Bruksanvisning
AZZA
Computerbehuizing
Noir
Läs nedan 📖 manual på svenska för AZZA Noir (12 sidor) i kategorin Computerbehuizing. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/12
RGB Lighting Switching
Fan Installation
Cooling System Installation
Remove the Front Panel Instructions
3.5"HDD/ 2.5" SSD Installation
7.
8.
Model Name: NOIR
Model Number CSAZ-130
Type: Micro ATX Mid Tower
Color: Black(exterior)/black(interior)
Side Panel Window: Le side panel: tempered glass with rubber mounts
Max CPU Cooler Height: UP to 165mm
Max Length Up to 300mm long video card
GPU
Motherboard Compa bility: Micro ATX
External 5.25" Drive Bays: 0
Internal 2.5" Drive Bays: Up to 6
Internal 3.5" Drive Bays: Up to 2
Expansion Slots: 4
Top Ports: Power bu on, LED bu on, HD Audio, USB 3.0 x 1, USB2.0x2
Case Dimension (HxWxD) 397x215x404mm/15.6x8.5x16 inches
Weight: 4.3kg /9.5lbs
Outer Appearance: High-quality tempered glass side window allows for clear visuals to inner components
Addressable RGB Light Effects: All ARGB light devices sync with the motherboard, allowing the motherboard so ware or
LED bu on to directly control the ligh ng.
Available Fan Ports:
3x120mm fan ports in the front (1 x 120mm LFO-3212D ARGB fan included)
2x120mm or 2x140mm fan ports on the top
1x120mm fan port in the rear(1 x 120mm LFO-3212D ARGB fan included)
Water Cooling: Supports radiators up to 240mm in the front
Dust Filters Removable (magne c) dustproof net on the top, iron net on bo om of chassis.
Expansion
Features
Model
Specifications
Physical Specifications
Power Supply Support: Boom mounted ATX Power Supply
Produktspecifikationer
| Varumärke: | AZZA |
| Kategori: | Computerbehuizing |
| Modell: | Noir |
