Sida 1/14
I N N O V A T I V E T R E M P E R E D G L A S S G A M I N G C A S E
CSAZ-804VCSAZ-804V
Installation Instructions
1. Specifications
2. Chassis Parts
3. Removing The Top Glass Panel
4. Overview
5. Supported Motherboards
6. Power Supply Installation
7. Water Radiator Installation
8. 2.5"SSD / 3.5"HDD Installation
9. Fan Installation
10. Digital RGB Fan Installation For Motherboard
Specifications
Model
Model Name: PYRAMID 804
Name: CSAZ-804V
Specifications
Type:
Color:
Side Panel Window:
UP to 95mm
Power Supply: Not Included
Motherboard Compa bility:
External 5.25" Drive Bays:
Internal 2.5" Drive Bays:
Internal 3.5" Drive Bays:
Expansion slots:
Physical Specifications
Metal Chassis Dimensions (HxWxD) 558x490x490/22x19.3x19.3 inch
Dimendion with Case Stand(HxWxD)
Weight: 14.1kg /31.1lbs
Tempered Glass Side Window:
Available Fan Ports:
Water Cooling:
isolated chamber:
Easy installa on Cooler:A pre-cut hole for easy installa on of CPU Cooler,
elimina ng the need to remove the motherboard
Accessories
High-quality tempered glass side window allows for clear visuals to inner components
1x120mm Fan port in the Top(1x 120mm Hurricane II Digital RGB Fan included )
3x120mm Fan port in the Bo om
Supports radiators up to 360mm on the Bo on
CPU Air Coolers <95mm
ATX Power supply inside its own isolated chamber,
preven ng its heat from a ec ng other components
Stand & Tempered glass(op onal)
Up to 1 (Conver ble with 2.5"SSDx1 )
、 、 、 HD Audio Type C Metal power bu on
Features
ATX Tower
1.5~2.0mm SPCC+ 2.5mm Aluminum
4 sides panel are Tempered Glass
Expansion
0
Up to 2
2xUSB 3.0
589x490x490mm/23.2x19.3x19.3 inch
7
<305x280mm SSI-CEB ATX、
Max. CPU Cooler Height:
Max. GPU Dimensions:
Front Ports:
※PWM Fan:The model comes with PWM fans and will run at top speed unless connected to a motherboard or controller.
