Installation Instructions
1. Specifications
2. Chassis Parts
3. Control Panel Functions
4. Removable Side Panel/ Bottom Dust Filter
5. Video Card Holder Instructions
6. 3.5″ ″ SSDHDD/2.5 Installation
7. Cooling System Installation
8. Parallel Connection ("daisy-chaining")
ZIRCON 7000
CSAZ-7000
ATX Full Tower
Black/Black(interior), White/White(interior)
Tempered glass on both sides
UP to 165mm
Up to 390mm long video card (Horizontal/ Vertical)
Not included
0
Up to 5
Up to 5
8(Horizontal)+2(Vertical)
Power button, reset button, HD Audio, USB 3.0 x 2,Type C
515 x 233 x 515mm / 20.3 x 9.2 x 20.3 inches
14.9kg /32.8lbs
High-quality tempered glass side window allows for clear visuals to inner components
Addressable RGB light I/O ports and strip on the front panel. All Addressable RGB light
devices sync with the motherboard, allowing the motherboard software to directly control
the lighting.
3x120mm or 2x140mm Fan ports in the front
3x120mm or 2x140mm Fan ports on the top
1x120mm Fan port in the rear
(Included fan: Front - 1 x Black fan ; Rear - 1 x Black fan)
Supports radiators up to 280/360mm in the Front
Supports radiators up to 280/360mm on the Top
Removable (magnetic) dustproof net on the top and front, slide-out dust filter on the
bottom of chassis.
Bottom mounted ATX Power Supply
Cable management bar on both sides.
Can adjust the video card holder to fit your system needs.
Pump bracket included, compatible with a 2.5" SSD, or a 3.5" HDD.
Model
Model Name:
Model Number:
Specifications
Type:
Color:
Side Panel Window:
Max CPU Cooler Height:
Max Video Card Length:
Power Supply:
Motherboard Compatibility:
External 5.25" Drive Bays:
Internal 2.5" Drive Bays:
Internal 3.5" Drive Bays:
Expansion Slots:
Top Ports:
Physical Specifications
Case Dimensions (HxWxD):
Weight:
Tempered Glass Sides Window:
Addressable RGB Light Effects:
Available Fan Ports:
Water Cooling:
Dust Filters:
Power Supply Support:
Others Features:
Expansion
Features
E-ATX(<270mm) ATX Micro ATX、、
Produktspecifikationer
| Varumärke: | AZZA |
| Kategori: | Computerbehuizing |
| Modell: | Zircon |
