Sida 1/22

WEB: cors air.com

PHONE: (888) 222-4346

SUPPORT: support.corsair.com

BLOG: corsair.com/blog

FORUM : forum.corsair.com

YOUTUBE: youtube.com/corsairhowto

are registered trademarks in the United States and/or other countries. All other

trademarks are the property of their respective owners. Product may vary slightly

from those pictured. 49-002215 AA

60% Mechanical Gaming Keyboard

K65 RGB MINI

ENGLISH ....................................................... 1

FRANÇAIS ..................................................... 5

DEUTSCH ..................................................... 9

NEDERLANDS ............................................ 13

ITALIANO ..................................................... 17

ESPAÑOL .................................................... 21

PORTUGUÊS .............................................. 25

POLSKI ........................................................ 29

PУССКИЙ ..................................................... 33

ﺔﻴﺑﺮﻌﻟا ............................................................ 37

1 2

ENGLISHENGLISH

GETTING TO K NOW YOUR KEYBOARD

Connect the detachable USB cable (C) to the keyboard USB Type-C port (B) and to an available USB 3.0 or

better Type-A port on your Windows ® PC, Apple Mac®, or Microsoft Xbox One ®.*

*www.corsair.com/xbox-one-support

SETTING UP YOUR KEYBOARD

To clear the onboard memory at any time, hold the ESC key while plugging in the USB cable (C) to your

system, then release the ESC key after two seconds. The keyboard will then power on normally and be

reset to factory defaults.

FACTORY RESET

A — PBT DOUBL E-SHOT KEYCAP SET

B — USB T YPE-C PORT

C — DETACHABLE USB TYPE-C

TO TYPE-A CABLE

D — KEYCAP PULLER

E — CORSAIR LOGO ABS ESC KEYCAP

F — RADIANT AB S SPACE BAR

SOFTWARE MODE

When iCUE is running the keyboard operates in software mode and is controlled by iCUE.

Install iCUE on a Windows PC or Apple Mac to connect all of your CORSAIR iCUE

compatible products together in a single interface, giving you complete control of

everything from lighting to powerful macros. Download iCUE from

www.corsair.com/downloads.

When playing iCUE-integrated games your RGB lighting dynamically reacts to in-game actions and

events in real-time. Learn more at www.corsair.com/icue.

HARDWARE MODE

When iCUE is not running or the keyboard is connected to a device that does not support iCUE, the keyboard

operates in hardware mode which uses lighting settings and recorded macros saved onboard.

With iCUE and the new dynamic proﬁle system, you can create as many custom proﬁles

as can ﬁt onto the 8MB of onboard storage. Each proﬁle can store complex backlighting

effects (up to 20 layers), actions & macros, and set tings.*

*The number of lighting effects layers per proﬁle and number of proﬁles that can be saved to onboard storage

will vary based on complexity.

A C

HARDWARE LIGHTING

Basic hardware lighting effects can be controlled via the below shortcuts when iCUE is not running or the

keyboard is connected to a device that does not support iCUE.

*Functions supported on select effects.

SHORTCUT FUNCTION

FN + V CHANGE LIGHTING EFFECT DIRECTION*

FN + B CHANGE LIGHT ING EFFECT SPEED*

SHORTCUT FUNCTION

FN + C

CHANGE LIGHTING EFFECT

WATER COLOR SPIRAL RAINBOW RAIN

RAINBOW WAVE VISOR T YPE LIGHTING (PER-KEY)

T YPE LIGHTING (RIPPLE) COLOR SHIFT

COLOR PULSE COLOR WAVE STATIC COLOR (8 COLORS)

HO L D FN + C RESET BACKLIGHTING TO ONBOARD DEFAULT
