Corsair K68 RGB Bruksanvisning

Corsair Tangentbord K68 RGB

Läs nedan 📖 manual på svenska för Corsair K68 RGB (22 sidor) i kategorin Tangentbord. Denna guide var användbar för 16 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/22
© 2017 CORSAIR COMPONENTS, Inc. All rights reserved. CORSAIR and the sails logo are registered trademarks in the United
States and/or other countries.All other trademarks are the property of their respective owners. Product may vary slightly from
those pictured. 49-001576 AB
47100 Bayside Parkway • Fremont • California • 94538 • USA
2
EMAIL: support@corsair.com
FACEBOOK: facebook.com/corsair
BLOG: blog.corsair.com
FORUM: forum.corsair.com
TWITTER: twitter.com/corsair
USA and CANADA: (888) 222-4346 | INTERNATIONAL: (510) 657-8747 | FAX: (510) 657-8748
corsair.com
MECHANICAL GAMING KEYBOARD
K68 RGB
K68 RGB
1 2
BA D
C E
F G H
I
J
The CORSAIR K68 RGB ultra-durable
mechanical keyboard combines vivid per-key
RGB backlighting, up to IP32 water and dust
resistance, and 100% CHERRY MX keyswitches.
Create stunning dynamic lighting effects and
game-changing macros in CORSAIR Utility
Engine (CUE) software to match your style and
give you an in-game edge. Dedicated volume
and multimedia controls allow you to adjust your
audio without interrupting your game, and 100%
anti-ghosting with full-key rollover guarantees
your commands and simultaneous keystrokes
always register. A dedicated Windows Key Lock
mode ensures interruption-free gaming, while a
removable wrist-rest provides optimal comfort
however you game. Whatever happens while
you game, you’ll be able to play on.
CONGRATULATIONS!
A – BACKLIGHT BRIGHTNESS KEY
B – WINDOWS KEY DISABLE
C – NUM LOCK LED INDICATOR
D – CAPS LOCK LED INDICATOR
E – SCROLL LOCK LED INDICATOR
F – MUTE KEY
G – VOLUME DOWN KEY
H – VOLUME UP KEY
I – DEDICATED MULTIMEDIA KEYS
J – USB CONNECTION CABLE
GETTING TO KNOW YOUR KEYBOARD
MODE FN KEY COMBO LIGHTING MODE
1 FN + 1 SPIRAL RAINBOW
2 FN + 2 RAIN
3 FN + 3 RAINBOW WAVE
4 FN + 4 VISOR
5 FN + 5 TYPE LIGHTING (KEY)
6 FN + 6 TYPE LIGHTING (RIPPLE)
7 FN + 7 COLOR SHIFT
RED / GREEN / BLUE / YELLOW / CYAN / PURPLE / ORANGE / WHITE
8 FN + 8 COLOR PULSE
RED / GREEN / BLUE / YELLOW / CYAN / PURPLE / ORANGE / WHITE
9 FN + 9 COLOR WAVE
RED / GREEN / BLUE / YELLOW / CYAN / PURPLE / ORANGE / WHITE
10 FN + 0 NO LIGHTING
11 FN + - STATIC. SWITCH THROUGH COLORS ON KEYPRESS
RED / GREEN / BLUE / YELLOW / CYAN / PURPLE / ORANGE / WHITE
BACKLIGHTING MODES
K68 RGB features dynamic per-key backlighting, fully-programmable with CORSAIR Utility
Engine (CUE) software to enable virtually unlimited lighting customization. It also comes with 11
pre-installed onboard lighting modes for instant illumination. Those modes can be accessed with
FN key. Below table outlines available lighting modes and keyboard shortcuts to access them.
SETTING UP YOUR KEYBOARD
> Turn on your computer
> Connect the keyboard to a USB 2.0 or
USB 3.0 port
> Download the CORSAIR Utility Engine (CUE)
software from www.corsair.com/downloads
> Run the installer program
> Follow the instruction for installation
Note: For use only with Nationally Recognized Testing Laboratory listed end product and USB output rated 5Vdc, 900 mA.
3 4!
NOTE ON ENVIRONMENTAL PROTECTION
After the implementation of the European
Directive 2012/19/EU in the national legal system,
the following applies:
—Electrical and electronic devices may not be
disposed of with domestic waste.
—Consumers are obligated by law to return
electrical and electronic devices at the end of
their service lives to the public collecting points
set up for this purpose of point of sale. Details
to this are defined by the national law of the
respective country. This symbol on the product,
the instruction manual or the package indicates
that a product is subject to these regulations. By
recycling, reusing the materials or other forms of
utilizing old devices, you are making an important
contribution to protecting our environment.
CAUTION!
The manufacturer is not responsible for any
radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications
could void the user authority to operate
the equipment.
FCC STATEMENT
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
> Reorient or relocate the receiving antenna.
> Increase the separation between the
equipment and receiver.
> Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
> Consult the dealer or an experienced radio/TV
technician for help.
This device must not be co-located or operating in
conjunction with any other antenna or transmitter.
Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
LIGHTING MODES FN + KEY
COMBO FUNCTION
1 2 3 4 5 6 7 8 9

Decrease speed (Fast -> Medium -> Slow)
 Decrease duration (Long -> Medium -> Short)

Increase speed (Slow -> Medium -> Fast)
 Increase duration (Short -> Medium -> Long)

Change direction from right to left
 Change direction counter-clockwise

Change direction from left to right
 Change direction clockwise
Dynamic lighting modes can be further customized for speed, duration or direction.
Press and hold FN + F4 for 5 seconds. All keys on the keyboard will blink twice rapidly in white color
to confirm all lighting modes have been reset to defaults.
FACTORY RESET
