BTS75V/A,G, 75V BF/A,G, 80/A,G

Package A & G

Aluminum door & frame, center hung

Single and double acting

Installation instructions

08076341 – 02-2021

| | EN

2BTS80 Closers 02-202108076341

dormakaba BTS75V/A,G, 75V BF/A,G, 80/A,G

Installation Instructions

Table of Contents

Table of contents

1 Installation 3

1.1 Attach spindle and install closer 3

1.2 Adjust pivot for door clearance 3

1.3 Install pivot channel in top of door 3

1.4 Install bottom arm in bottom of door (7422) 4

1.5 Install the door 4

2 Templates 5

2.1 Top pivot template 5

2.2 Bottom arm (7422) template 6

2.3 Cement case template 7

3 Adjustments 8

3.1 Adjust bottom door clearances (if necessary) 8

3.2 Adjust closing speeds 8

3.3 Adjust spring tension (if necessary) 9

3.4 Sealing compound (optional) 9

4 Covers 9

4.1 Install cover 9

dormakaba BTS75V/A,G, 75V BF/A,G, 80/A,G

Installation Instructions

08076341 02-2021BTS80 Closers 3

Installation

. Attach spindle and install closer

1 Installation

. Adjust pivot for door clearance

Fig.

Fig.

1.1.1 Slide washer over tapered

square end of spindle until

fully seated in groove.

1.1.2 Fasten spindle with

spindle screw provided.

1.1.3 Tighten securely with

5mm hex key.

1.1.4 Center closer in cement case.

1.1.5 Tighten fastening screws.

NOTE: Top of cement case must be flush with finished floor.

NOTE: Cement case must be level and installed parallel to frame.

NOTE: Spindle center line must be accurately located.

NOTE: Grout cement case in place.

Single acting applications

3° offset spindle

Stop side

Double acting applications

Standard spindle

CRITICAL:

WASHER MUST BE INSTALLED

Spindle screw

Spindle

Washer

Fastening screws

Finished floor

. Install pivot channel in top of door

Fig.

1.2.1 Determine clearance between

door and frame, and adjust

projection of pivot pin, if

required.

NOTE: Pivot pin projection allows

1/8” clearance as shipped

from the factory.

1.2.2 Remove walking beam pivot

screw.

1.2.3 Push pivot pin out until walking

beam is disengaged.

1.2.4 Install extended pivot pin and

engage walking beam into

appropriate hole in pivot pin to

obtain required projection.

NOTE: Be sure opposite end of

walking beam is engaged in

adjustment screw.

1.2.5 Reinstall walking beam pivot screw.

1.2.6 Retract pivot pin: turn adjustment screw

CCW and install pivot into header.

1.2.7 Install cover plate.

1.3.1 Fasten pivot channel in top of door.

1.3.2 Place bearing insert into pivot channel.

1.3.3 Turn adjustment screw approximately

halfway into pivot channel.

1.3.4 Adjust pivot point accordingly.

1.3.5 Lock bearing insert in place with set

screw.

Walking

beam

Adjustment

screw

Pivot

screw

Position Stnd pin Extended pin

A 1/8” [3] 3/4” [19]

B 3/8” [10] 1” [25]

C 3/4” [19] 1-5/16” [33]

Pivot

Cover plate

Adjustment screw

Bearing insert

Pivot channel

Set screw

Adjustment

screw
