STA 8916 AR/ARJ/ARP
Round arm for regular, top jamb, parallel mount
Stainless steel, corrosion resistant
Installation instructions
08279481 – 10-2019
| | EN
28900 Surface Applied Closers 10-201908279481
dormakaba 8916 AR/ARJ/ARP Installation Instructions
Table of Contents
Table of contents
1 Technical specifications 3
1.1 Overview 3
1.2 Tools recommended 3
1.3 Handing the door 3
2 Instructions - AR regular mount 4
2.1 Installing backplate and surface closer 4
2.2 Installing arms (AR) 4
3 Instructions - AR top jamb mount 5
3.1 Installing plate and surface closer 5
3.2 Installing arms (AR) 5
4 Instructions - AR parallel mount 6
4.1 Installing drop plate and closer 6
4.2 Installing parallel mount bracket and arm shoe 6
4.3 Securing main arm to closer 7
5 Adjustments 8
5.1 Adjust closing speeds: sweep, latch,
backcheck, delayed action 8
5.2 Adjust spring force 9
6 Install covers 9
dormakaba 8916 AR/ARJ/ARP Installation Instructions
08279481 10-20198900 Surface Applied Closers 3
Technical specifications
1 Technical specifications
. Overview
Caution: sex nuts are required for attachment
of components to unreinforced doors and to
wood or plastic faced composite type fire doors,
unless an alternative method is identified in the
individual door manufacturer’s listings.
Maximum door opening degree is 180°.
Know the swing of the door which is being
installed prior to installation.
Verify closer spring size prior to installation.
Make sure door efficiently operates prior to
installing closer.
Drill bits: # Phillips screwdriver
Metal: /” drill bit; /-
tap
/” flat head screwdriver
Wood: /” and /” bit mm hex key
/” box wrench
. Tools recommended
Table
. Handing the door
Fig.
Hinge Hinge
Exterior side of door
Interior side of door
Left hand door (LH) Right hand door (RH)
