Sida 1/32
Installation Guide
Kaba Mas
High Security
Pedestrian
Exit Device
Document Number 544.1116
Rev. B5 — August, 2018
Kaba Mas LLC
1051 Newtown Pike Ste. 150
Lexington, KY 40511 USA
Phone: 859-479-1329 FAX: 859-303-8993
Technical Support: 800-950-4744
WARNING: The Kaba Mas X-10 used with the DKX-10 is protected from Electrostatic Discharge (ESD) damage once
installed, but can be damaged during the installation process if proper precautions are not observed.
Follow these precautions to avoid ESD damage when installing the lock:
• Do not touch the end of the flex cable if the ESD protective cover has been removed.
• For the best protection, use an ESD wrist band grounded to the lock during installation.
• The lock is protected to greater than 25,000 V when correctly installed.
Note: The GSA approved Kaba Mas FF-L-2890B High Security Pedestrian (HSPED) Exit Device is available for
use with a Kaba Mas, Style 1, X-10 combination lock or a Sargent & Greenleaf (S&G) 2740B, Style 2
combination lock.
This document designates the Exit Device with a modified CDX-10 lock as: DKX-10
This document also designates the Exit Device with a modified CDX base with the S&G 2740B lock as:
DKX-19
The HSPED combines, through linkage, a Dorma model 9300 fire rated exit device and a Kaba Mas CDX-10
baseplate. If the system is ordered with a Kaba Mas X-10, the X-10 is mounted to the baseplate. If the
system is ordered with an S&G combination lock, the S&G lock is mounted to the CDX-10 baseplate. The
procedure to mount the DKX unit to the door is the same whether the combination lock is an X-10 or S&G
2740B lock. The process to install and set up the X-10 (once the CD base plate is mounted to the door) is
the same as it would be for any X-10 or CDX-10 installation. The installation and setup for the S&G 2740B
lock is also the same as it would be for any standard installation. A copy of Kaba Mas X-10 installation
instructions are provided when the device is ordered with an X-10. S&G’s 2740B lock installation
instructions are provided with the S&G lock when it is specified.
Only technicians who have successfully completed manufacturer certified training for combination locks
should install the DKX-10 or the DKX-19.
NOTE: One set of instructions should be left with the building owner after devices have been installed.
Trademarks
The following items are trademarks or registered trademarks of Kaba Mas in the United States and/or other countries.
PowerStar Technology
DKX-10, X-10
Document Number 544.1116
Rev. B5 - 08/18
