Installation Guide
Kaba Mas
DKX-10
Type II
Preliminary / /19 04 03
Kaba Mas LLC
1051 Newtown Pike Ste. 150
Lexington, KY 40511 USA
Phone: 859-479-1329 FAX: 859-303-8993
Technical Support: 800-950-4744
WARNING: The Kaba Mas X-10 used is protected from Electrostatic Discharge (ESD) with the DKX-10 type II
damage once installed, but can be damaged during the installation process if proper precautions are not
observed. Follow these precautions to avoid ESD damage when installing the lock:
• Do not touch the end of the flex cable if the ESD protective cover has been removed.
• For the best protection, use an ESD wrist band grounded to the lock during installation.
• The lock is protected to greater than 25,000 V when correctly installed.
NOTE: The GSA Lever for approved Kaba Mas FF-L-2890B type II Release Lockset is available use with a Kaba
Mas, Style 1, X-10 combination lock a Sargent & Greenleaf 2 combination lock. or (S&G) 2740B, Style
This document designates the Cylindrical Lockset with a modified CDX-10 as: Best 9K lock DKX-10 Type II.
This document also designates the Cylindrical Lockset with a modified CDX the S&G Best 9K base with
2740B lock as: -19 . DKX , Type II
The combines, through linkage, a Best 9K DKX-10, Type II cylindrical lockset and a Kaba Mas CDX-10 base-
plate. If the system is ordered with a Kaba Mas X-10, X-10 is mounted to the baseplate. If the system the
is ordered with an S&G combination lock, the S&G lock is mounted to the CDX-10 baseplate. The
procedure to mount the DKX unit to the door the same whether the combination lock is an X-10 is or an
S&G 2740B lock. The process to install and set up the X-10 (once the CD base plate is mounted to the
door) is the same as it would be for any X-10 or The installation and setup for the CDX-10 installation.
S&G 2740B lock is also the same as it would be for any standard installation. of A copy the Kaba Mas X-10
installation instructions is provided the device is ordered with an X-10. S&G’s 2740B when lock installation
instructions are provided the S&G lock when it is specified. with
Only technicians who have successfully completed manufacturer certified training for FF-L 2740B
combination locks should install -10 or the -19.the DKX DKX
NOTE: One set of instructions should be left with the building owner after devices have been installed.
Trademarks
The following items are trademarks or registered trademarks of Kaba Mas in the United States and/or other countries.
PowerStar echnologyT
-10, X-10DKX
Document Number 548.0418
Rev. A 09/18
