Sida 1/22
E-730 Series630 750 Series Series 79E/RT/E7900 Series
Exit Device Operators
630/750/79E/RT/E7900 Series/
Generation E-730
Installation instructions
PK3677-T - 2018 - 09
EN
2 Exit Device Operators 630/750/79E/RT/E7900 Series/ Generation E-730 PK3677_T 10-18
A- Checklist and Exploded Views 3
B- Introduction and Disclaimers 4
C- Prepare the Door For the Appropriate Exit Device 4
D- Install the Lock and the Exit Device 5
1. Install the Mortise 5
2. Install the Outside Lever on the Outside Housing 5
3. Install the Battery Holder 5
4. Install the Lock and Exit Device on the door 6
5. Install the lock and Exit Device with Messenger/Bluetooth on the door. 7
E- Test the Operation of the E-730 / 750 / 79E Lock 8
F- Program the E-730 / 750 / 79E Lock 9
G- Operating the Emergency Override 10
H- Test the operation of the 630 Lock 11
J- Installing the Mechanical Override 12
Parts and Tools List 12
1. Upon unpacking the Lock 13
2. Preparing the Outside Housing for the Installation of the Lever 13
3. Preparing the Lever Handle and Cylinder for Installation 14
4. Steps to attach the Lever Handle to the Lock Housing 14
5. Attaching the Lever Handle to the Lock 15
6. Verify the Attachment of the Lever Handle 16
7. Test the Movement of the Lever Handle 16
8. Test the Mechnical Override Function 17
9. Cover the Keyhole and Cylinder with Cap 17
10. How to Change Lock Cylinders 17
2018 dormakaba Canada Inc. All trademarks and registered trademarks are the property of their respective owners.
Table of contents
Exit Device Operators 630/750/79E/RT/E7900 Series/ Generation E-730 PK3677_T 10-18 3
Each lockset for E-730/630/750/79E/E7900 includes:
(A) Outside lever handle
(B) Outside housing
(C) Gasket (when required)
(G) Exit Device (Included if ordered with lock operator)
(J) Battery holder with 3 AA batteries
Parts inside hardware bag:
(D) 1 x Spindle except for the following Exit Device which
have 3: Detex F10, Dorma F9300 and Precision21/22/
FL21/FL22
(E) 1 x Inside Adaptor Plate
(F) 3 x Mounting Screw 12-24 1/8” Hex
(H) 2 x Pan Head Screws 1
/4” 28 X 3/4” for Yale
2 or 4 Pan Head Screws 10-24 X 3
/4” for Detex,
Dorma, Von Duprin or 4 Flat Head screw 10-24 X
5/8” for Precision, Arrow
(K) 1 x Spanner-head Screw
(Q) 2 or 4 Flat Washer ⁄ OD for Detex Exit Device Only
Messenger / BLE Generation includes:
(S) Double enclosure.
(T) 2 X Pan Head Screws 8-32 X 1/2’’
Tools Required:
Safety glasses
5/16” (7.9mm) drill bit
1
/2” (13mm) drill bit
1” (25mm) drill bit
Drill
Awl or center punch
Hammer
Rubber mallet
Small flat screwdriver
Philips #2 screwdriver
Spanner screwdriver (No 6)
1
/8” Allen key
Adjustable square
Tape measure
Pencil
Tape
Cleaning supplies
(drop cloth, vacuum)
B
A
C D
E
F
Q
G
H
G
J
K
E
S-COVER
T
S-SUPPORT
W
W
S-SCREW
Mechanical Override Models ONLY:
(L) Cylinder Cap
(M) Cylinder Plug
(N) Outside Lever Handle
(O1) Adapter
(O2) Adapter & Screw
(P) Cylinder (for 630 series lock with cylinders keyed
different ONLY)
E7900 Messeger/BLE Generation includes:
(S) Battery/Antenna enclosure with spacer.
(T1) 2x Flat Head Screws 8-32 X ⁄''
(T2) 2x Flat Head Screws 8-32 X 1 ⁄''
(P) Cylinder (for 630 series lock with cylinders keyed
different ONLY)
Mechanical Override Models ONLY
L
P
M
N
** Dorma 9100/9300/9400/9500 Series are Panic Hardware only (not fire rated)
Dorma F9100/F9300/F9400/F9500 Series are Fire Rated Hardware
A Checklist
