Subject to change without notice
Description
The MS08 actuator utilizes proven
microwave motion technology to ensure
consistent, dependable touchless
activation and can be adjusted to
comply with ANSI knowing act
applications.
The MS08 detects moving objects such
as a hand, cart, or wheelchair and is
ideal for use in hospitals, pharmacies,
clean rooms, food service facilities, and
other applications requiring a hygienic
touchless activation method.
Features & benefits
Detection zone from 4"– 24"
(pulse or toggle).
Silent activation for hospitals and
other noise-sensitive environments.
Water-resistant foam gasket
provides increased reliability when
exposed to liquid or cleaning
products.
Low profile, beveled design reduces
chance of accidental damage in
high traffic areas.
Available in black faceplate with
options for single or double gang
boxes.
MS08 touchless actuator
Automatic sliding & swinging doors
Entrance systems
Technology
Radiated frequency
Radiated power density
Microwave doppler radar
24.125 GHz
5 mW / cm2
Detection mode Motion (bi-directional)
Detection range 4" – 24" (adjustable)
Output
Max. contact voltage
Max. contact current
Max. switching power
Relay with switch-over contact (voltage free)
60 VDC / 125 VAC
1 A (resistive)
30 W (DC) / 60 VA (AC)
Output hold time 0.5 s (in pulsed mode)
Supply frequency 50 – 60 Hz
Supply voltage < 2.8 W 12 – 24 VAC ±10%
12 – 24 VDC 30% / −10%
Power consumption < 1.5 W
Material ASA, Nylon, PC
Cable type Standard cable up to 16 AWG - 1.5 mm 2
Temperature range F – 131ºF (−20ºC – 55ºC)
Norm conformance EMC: 2004 / 108 / EC; FCC: G9B-MS08;
IC: 4680A-MS08
MS08 touchless actuator
Technical specifications
Applications
Dual egress Sliding doors Industrial doors Swing doors
dormakaba Canada
1680 Courtney Park Dr. Unit 13
Mississauga, ON L5T 1R4
800.387.4938
www.dormakaba.ca
dormakaba USA Inc.
Dorma Drive, Drawer AC
Reamstown, PA 17567
844-SPECNOW
www.dormakaba.us
MS08 microwave touchless actuator
DX3339-007
SINGLE & DOUBLE
GANG FACEPLATES
MS08 dimensional drawings
2.75"
5
"
4.5"
4.5"
.25"
1.56"
1.56"
.25
1.75"
Double gang Single gang
Microwave cell
EO • 9.18 • 07000499-9
