Sida 1/10
STA 8616 AR/ARJ/ARP
Round arm for regular, top jamb, parallel mount
Stainless steel, corrosion resistant
Installation instructions
08280720 – 03-2021
| | EN
dormakaba 8616 AR/ARJ/ARP Installation Instructions
08280720 03-20218600 Surface Applied Closers
2
1 Instructions
Fig.1
1.1 Overall - installation types
ATTENTION!
Before you begin,
determine installation
type AT, ARJ, or ARP
and hand of door (RH
or LH).
Also, make sure you
have the tools listed
below.
Right hand installation Left hand installation
8616 AR RH
8616 ARJ RH
4” reveal maximium
8616 ARP RH
8616 AR LH
8616 ARP LH
Tools
Tape, Tape Measure
Center Punch and Hammer
3/16” Slotted Screw Driver
#3 Cross-Point Screw Driver
1/2” Box Wrench
10” Adjustable Wrench
List:
7/32, 5/32, 1/8 Drill Bits and Drill
1/4-20 Tap & Holder
5mm hex wrench
8616 ARJ LH
4” reveal maximium
Caution: sex nuts are required for attachment
of components to unreinforced doors and to
wood or plastic faced composite type fire doors,
unless an alternative method is identified in the
individual door manufacturer’s listings.
When installing main arm attachment observe
directions closely.
Confirm dead stop degree prior to door and
frame preparations.
Make sure door efficiently operates prior to
installing closer.
dormakaba 8616 AR/ARJ/ARP Installation Instructions
08280720 03-20218600 Surface Applied Closers 3
1.2 Installing arm STA 8616 AR - Arm round (Regular)/mount pull side door
Fig.2
2
3
Pry apart connecting arm (3)
tube from main arm (2).
12
Thread the connecting tube (3) and
rod shoe (4) together.
5 6
Combo Flat
Head Screw x4
Pan Head
Combo Screw
x2
Standard closing
power foot orientation
shown above, for 15%
more closing power
invert shoe 180
degrees.
Right Hand Left Hand
3A
3
Prepare door and frame using the template
provide in the back of the instructions.
Attach the closer (1) to the door using 4 combo
flat head screws (5).
Attach connecting arm (4) to the frame with 2
combo pan head screws (6).
Attach main arm (2) per hand and secure tightly
with socket head screw (7) see 3A.
Parts list:
No. Description Qty
1) Closer 1
2) Main Arm 1
3) Connecting Arm 1
4) Rod and Shoe 1
5) Flat Head Combo Screws 4
6) Pan Head Combo Screw 2
7) Socket Head Cap Screw 1
8) Dust Cap 1
Right Hand Left Hand
