Sida 1/11
TG 9387 Non-locking Ladder Pulls
Back-to-back and Single-sided
Installation instructions
905381 – 08-2021
| | EN
2Non-Locking Ladder Pulls 08-2021905381
dormakaba TG 9387 Back-to-back and Single-sided Non-locking
Ladder Pulls Installation Instructions
Table of Contents
Table of contents
1  Technical specifications 3
1.1 Overview 3
1.1.1 General information 3
1.1.2 Intended use 3
1.1.3 Glass requirements/fittings/mounting 3
1.1.4 Requirements for glass panel 3
1.1.5 Safety instructions 3
1.1.6 Symbols used - Safety/Installation 3
1.1.7 Maintenance, care, repair 3
1.1.8 Disposal 3
2 Installation Instructions Glass Door:
B2B non-locking ladder pulls 4
2.1 Assemble outside pull 4
2.2 Assemble inside pull 5
3 Installation Instructions Glass Door:
Single-sided non-locking ladder pulls 6
3.1 Assemble inside pull (with rose) 6
4 Installation Instructions Wood Door:
B2B non-locking pull 7
4.1 Assemble outside pull 7
4.2 Assemble inside pull 8
5 Installation Instructions Wood Door:
Single-sided non-locking pull (with rose) 9
5.1 Assemble inside pull (with rose) 9
6 Installation Instructions Wood Door:
Single-sided non-locking pull (without rose) 10
6.1 Assemble inside pull (without rose) 10
dormakaba TG 9387 Back-to-back and Single-sided Non-locking
Ladder Pulls Installation Instructions
Non-Locking Ladder Pulls 08-2021905381 3
Technical specifications
1  Technical specifications
1.1 Overview
These instructions are for installation of TG 9387
Back-to-Back and Single-Sided Non-Locking Ladder
Pulls for the following mounting and style versions:
1. Glass mount
1.1.1 General information
• dormakaba requires use of tempered laminated or
tempered monolithic glass.
• dormakaba glass hardware is not suitable for
harsh environment; for example, applications where
chemicals (e.g. chlorine) are used such as indoor
swimming pools, saunas, or salt-water pools.
• Never move sliding panels faster than walking
speed and always stop the door manually before it
reaches end position.
• Do not swing/slide doors with excessive force.
Ensure proper installation of limiting stop to
prevent door from opening too far.
1.1.2 Intended use
• For swinging/sliding doors in dry indoor areas only.
• For manual slow opening and closing only.
1.1.3 Glass requirements/fittings/mounting
• Fasteners must be sufficiently dimensioned for the
substructure/wall and weight of the door.
• When adjusting glass components, always stick to
the required clearance for the respective hardware.
Adjust clearance so glass does not come in contact
with any hard surfaces such as glass, metal or
concrete.
• Do not use excessive force when installing the glass
(avoid over tightening screws.)
1.1.4 Requirements for glass panel
• dormakaba requires use of fully tempered glass,
which complies with ASTM C 1036 and ASTM C
1048. Secondary heat soaking processes are
recommended but not required. This applies to
both tempered monolithic and tempered laminated
glass.
• Clamping area must be flat and uncoated (no
self-cleaning coating!)
• Never use glass with conchoidal fractures and/or
damaged edges.
1.1.5 Safety instructions
• Always wear protective clothing.
• Only properly qualified and specially trained staff
are authorized to mount dormakaba glass
hardware.
• Due to crushing hazards and possible injury caused
by breakage of glass during mounting,
corresponding protective clothing (especially gloves
and protective goggles) is required.
• Never clamp metal fitting hardware directly to
glass surface.
1.1.6 Symbols used - Safety/Installation
CAUTION
Mounting components must meet the
requirements of substructure/wall and door
weight. Please read the technical information
for fittings.
WARNING
Risk of breaking glass. When installing the
door, support the door panel with a block of
wood or similar object.
CLOSING EDGE OF DOOR
1.1.7 Maintenance, care, repair
• Immediately replace damaged parts.
• Always use original dormakaba parts.
• Clean clamping area with alcohol-based standard
commercial cleaning agent before mounting the
glass hardware.
• Use a damp cloth for occasional cleaning.
• Always use silicone - and oil-free cleaners (e.g.
acetone).
• Check glass hardware at regular intervals for
proper positioning, smooth operation and correct
adjustment.
• High traffic door systems require inspection by
properly qualified staff (specialized companies or
installation firms.)
1.1.8 Disposal
Disposal in accordance with local, state and national
regulations.
