Sida 1/32

SEQ MOD LPG1 LPG2 BBD MIX2 MIX3VCO1 VCO2VCO CTRL MIX1 VC EG1 VC EG2

TUNE EXP FM TUNE LVL1 OFFSET OFFSET TIME LVL1RATE ATTACK ATTACK MASTER OUT

PWM LIN FM SHAPE LVL2 DECAY DECAY RESO RESO FBK LVL2 LVL1CLK IN

1V/OCT EXP FM 1V/OCT IN1 PULSE ATTACK CV ATTACK CV CV1 CV1 IN1 IN1

PWM CV VCA CV SHAPE CV IN2 RND PULSE DECAY CV DECAY CV CV2 CV2 IN2TIME CV IN2

PULSE

CLK IN

2 4

IN/LIN FM SHAPE IN3 S&H TRIGG TRIGG IN IN IN3IN OUT

TRICV OUT VCA OUT TRI OUT OUT OUT OUTOUT SUM OUTNOISE OUT OUT

VCA OFFS LVL3 SINE

LOOP

FREE

LOOP

FREE

VCA

VCF

VCA

VCF

+1OCT

-1OCT

+1OCT

-1OCT DRY/WET LVL3 LVL2

User

manual

patch

book

ERICA PICO SYSTEM III

Erica Synths Pico System III is affordable, compact, yet powerful sounding,

full analogue modular system. It comes in two formats – eurorack and

desktop.

Pico System III brings modular synthesis back to the basics – the system has

multi functional (instead of single-function, like Pico Drums or Pico Trigger in the

Pico System II) analogue modules and is intended to encourage creativity in

modular patching. The system has 31 inputs and 20 outputs (master output is

dublicated) + 7 switches; if you have enough patch cables at your disposal, you can

patch the system in 121000931215044250740178662400 or 1.21x1029 variations (we

ignored possibility to adjust potentiometers here). Even though only 0,0001% of all

patches will sound more-less enjoyable, you and all your future generations can

spend a lifetime only patching the Pico System III.

Voicecards with preset patches set it apart from other eurorack systems –

they allow user to change patches instantly and radically, which makes the

system well suited for experimental live performances. The system comes

with 5 great sounding “factory preset” voicecards, and that 5 DIY voicecards

are empty and user can develop his/her own patches. More voicecards are

available from shop.Erica Synths

Pico System III features a set of modules for advanced sound design, exper-

iments in modular patching and educational purposes. The system includes:

2-3-4 step sequencer, 2xVCOs, VCO controller/VCA module, several mixers

that work both with CV and audio signals, Modulator (syncable LFO, random

CV and noise source), 2X voltage controlled ASR envelope generators, 2x

lowpass gate and BBD delay.

QUICK START – DESKTOP VERSION

The Pico System III is plug and play! Connect the power connector cable,

connect the MASTER OUT to mixing console or amplifier using 3,5mm

stereo cable (if you use top output connector. The system does not

output actual stereo signal – the mono signal from the output is split to

both left and right channels) or 3,5mm mono cable (if you use the

connector on the back of the system), flip the power switch and start

patching! You can also connect headphones to the MASTER OUT.

QUICK START – EURORACK VERSION

Just install the system in your eurorack case and start patching!

3,5mm mono cable

3,5mmstereo cable

mixer or amplifier

mixer, amplifier

or headphones
