OPERATING INSTRUCTIONS AND OWNER’S MANUAL
READ INSTRUCTIONS CAREFULLY: Read and follow all
instructions. Place instructions in a safe place for future
reference. Do not allow anyone who has not read these
instructions to assemble, light, adjust or operate the heater.
HEATSTAR High-Intensity Infrared Heaters
MODELS
Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference.
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
WARNING:
— Donotstoreorusegasolineorotherflammablevaporsandliquidsinthevicinityofthisorany
other appliance.
— WHATTODOIFYOUSMELLGAS
 • OpenWindows
 • DO NOT try to light any appliance.
 • DO NOT use electrical switches.
 • DO NOTuseanytelephoneinyourhouse.Immediatelycallyourlocalgassupplierfroma
  telephoneremotefromtheareaoftheleak.Followthegassupplier'sinstructions.
 • DO NOT touch any electrical switch; do not use any phone in your building.
 • Installationandservicemustbeperfomedbyaqualifiedinstaller,serviceagencyorthegas
supplier.
 • Ifyoucannotreachyourgassupplier,calltheFireDepartment.
Thisisanunventedgas-firedheater.Itusesair(oxygen)fromtheareainwhichitisused.Adequate
combustionandventilationairmustbeprovided.Refertopage5.
ENERCOGROUPINC.,4560W.160THST.,CLEVELAND,OHIO44135•866-447-2194
4000 & 8000 Models 9000 Models
HS4030 HS8070 HS9100
HS4040 HS9080 HS9120
HS8050 HS9090 HS9140
HS8060 HS9100S
WARNING: Improperinstallation,adjustment,alteration,serviceormaintenancecancauseproperty
damage, injury or death. Read the installation, operation, and maintenance instructions thoroughly before
installingorservicingthisheater.Forassistanceoradditionalinformationconsultaqualifiedinstaller,service
agency, or gas supplier.
E4
Enerco Group, Inc. |Gas-Fired Infra-Red Space Heaters Operating Instructions and Owner’s Manual
NOTE:
1.OnlyUseAPipeCompoundWhichIsResistantToLiquefied
GasesOnL.P.Installations.
2.FittingsShownAreNotIncludedWithHeater.
Figure 3. Typical Piping Installation
Sediment trap
TABLE 1
MODEL NO.
BTU/HR.RATING NORMAL
MOUNTING
POSITION
CLEARANCESTOCOMBUSTIBLES
GAS
NATURAL PROPANE SIDES BELOWTOP BACK
4030** 30,000 30,000 Horiz.-45° 54”30” 30” 30”
4040* 40,000 40,000 Horiz.-45° 68”34” 30” 30”
8050** 50,000 50,000 Horiz.-45° 36” 30” 30” 78”
8060* 60,000 60,000 Horiz.-45° 40” 84”30” 30”
8070** 70,000 – Horiz.-45° 40” 84”30” 30”
9080** 80,000 80,000 Horiz.-45° 46” 40” 40” 104”
9090** 90,000 90,000 Horiz.-45° 46” 46” 46” 114”
9100S* 100,000 100,000 Horiz.-45° 48” 46” 46” 118”
9100** 100,000 100,000 Horiz.-45° 44” 40” 40” 104”
9120* 120,000 120,000 Horiz.-45° 46” 46” 46” 114”
9140** 140,000 – Horiz.-45° 46” 46” 46” 114”
*HighIntensityHeatersareonlysoldas4040,8060,9100S,and9120
**Differentmodelnumbersareachievedbyusingsupplementalorificesincludedwithheaterstochangeheatoutput.
6. GAS PRESSURE
Whenahigherthanthemaximumrecommended
gas pressure is being maintained at the main gas line,
a separate regulator must be installed ahead of the
heater.RefertoTable2formaximumallowablepres-
sure for stated model and gas.
See heater rating plate for minimum gas supply pres-
sure“ForthePurposeofInputAdjustment”
On a multiple heater installation it may be possible
touseonelargecapacityregulatororanindividual
regulatorforeachheater.Nevertheless,itis
recommended practice to make the entire pipe system
aloop.Contactyourlocalrepresentativeorthefactory
for proper gas pressure reducing design stage.
WARNING: DONOTEXCEED½P.S.I.INLET
PRESSURETOHEATERSSHOWNINTABLES1AND2
Theclearancestocombustiblesrepresentasurfacetemperatureof90°F(32°C)aboveroomtemperature.Buildingmaterialswithlowheat
tolerancemaybesubjecttodegradationatlowertemperatures.Itistheinstaller’sresponsibility.
E9 Operating Instructions and Owner’s ManualEnerco Group, Inc. | Gas-Fired Infra-Red Space Heaters
Replacement Parts List For Heaters
4000 Series Models / Less Control
Item
No.
No.
Req’d.
Stock
No. Description
1 1 00435A ReflectorAssembly
2 1 BurnerAssembly02523A
3 1 Venturi03397P
4 1 BurnerOrificeN.G.404005437
5 1 BurnerOrificeN.G.403005443
6 1 BurnerOrificeL.P.404005449
7 1 BurnerOrifiL.P.403005452
8 1 Gasket–Venturi12366
1 3 4 8
4040Nat.Gas 2
or
1 3 5 8
4030Nat.Gas 2
or
1 3 6 8
4040Propane 2
or
1 3 7 8
4030Propane 2
or
Replacement Parts List For Heaters
8000 Series Models / Less Control
Item
No.
No.
Req’d. Stock No. Description
1 1 00442A ReflectorAssembly
2 1 BurnerAssembly02524A
3 1 Venturi03421P
4 1 Orifice–Br.N.G.807005429
5 1 Orifice–Br.N.G.806005430
6 1 Orifice–Br.N.G.805005430
7 1 Orifice–Br.L.P.806005443
8 1 Orifice–Br.L.P.805005445
9 1 Gasket–Venturi12366
1 3 4 9
8070Nat.Gas 2
or
1 3 5 9
8060Nat.Gas 2
or
1 3 6 9
8050Nat.Gas 2
or
1 3 7 9
8060Propane 2
or
1 3 8 9
8050Propane 2
or
5
6
7
8
1 2
9
3
5
6
7
8 9
1 2
10
3
8
4
5
6
7
