Enerco Technical Products, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 · 866-447-2194
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
UNVENTED NATURAL GAS FIRED ROOM HEATER
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or loss of life.
-Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
-WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegassupplier’sinstructions.
• If you cannot reach your gas supplier, call the fire department.
-Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to Fresh Air for
Combustion and Ventilation section on page 4 of this manual.
This appliance may be installed in an aftermarket permanently manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is
not convertible for use with any other gas.
Blue Flame Heaters
HSSVFBF30NGBT
HSSVFBF20NGBT
Plaque Heaters
HSSVFRD20NGBT
HSSVFRD30NGBT
OPERATING INSTRUCTIONS
ANDOWNER’SMANUAL
Model #
HSSVFRD20NGBT
HSSVFRD30NGBT
HSSVFBF20NGBT
HSSVFBF30NGBT
READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS Read and
follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has
not read these instructions to assemble, light, adjust or operate the heater.
2Installation Instructions and Owner’s ManualUnvented Natural Gas Vent Free Room Heaters
DANGER
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk
individuals.
WARNING: FIRE, EXPLOSION, AND ASPHYXIATION HAZARD
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Refer to this manual for correct installation and operational procedures. For
assistance or additional information consult a qualified installer, service agency, or gas supplier.
ReadandfollowinstructionsandprecautionsinUser’sInformationManualprovidedwiththis
heater.
WARNING: THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS
INCLUDING LEAD AND LEAD COMPOUNDS, WHICH ARE KNOWN TO
THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR
OTHER REPRODUCTIVE HARM. FOR MORE INFORMATION VISIT WWW.
P65WARNINGS.CA.GOV
Due to high temperatures, heater should be
kept out of traffic and away from furniture and
draperies.
Do not place clothing or other flammable material
on or near the appliance.
Children and adults should be alerted to the
hazard of high surface temperature and should
stay away to avoid burns or clothing ignition.
Young children should be carefully supervised
when they are in the same room with heater.
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with this
appliance and shall be installed for the protection
of children and other at-risk individuals.
If the barrier becomes damaged, the barrier shall
be replaced with the manufacturer’s barrier for
this appliance.
Any safety screen or guard removed for servicing
an appliance must be replaced prior to operating
the heater.
Installation and repair should be done by a
qualified service person. The appliance should
be inspected before use and at least annually
by a professional service person. More frequent
cleaning may be required due to excessive lint
from carpeting, bedding material, etc. It is
imperative that control compartments, burners,
and circulating air passageways of the appliance
be kept clean.
WARNING: This
appliance is equipped for Natural
gas. Field conversion is not
permitted.
WARNING: Do not use
a blower insert, heat exchanger
insert or other accessory not
approved for use with this heater.
SOCIAL MEDIA
In order to provide the best service possible HEATSTAR is now giving you more ways to get in touch with us:
WEBSITE: Heatstar Products’s full line of product are now at: WWW.HEATSTARBYENERCO.COM
YouTube: youtube.com/heatstarTV
3Installation Instructions and Owner’s ManualUnvented Natural Gas Vent Free Room Heaters
PRECAUTIONS:
1. An unvented room heater having an input rating of more
than 10,000 BTU (2931 W) (i.e. the HSSVFRD20NGBT,
HSSVFRD30NGBT, HSSVFBF20NGBT, and
HSSVFBF30NGBT) shall not be installed in a bedroom or
bathroom, or any place where a strong wind would shut
down the appliance.
2. This heater needs outside ventilation air to run properly.
The Oxygen Depletion Sensor (ODS) safety shutoff
system shuts down the heater if not enough fresh air is
available. See Fresh Air for Combustion and Ventilation,
page 5.
3. Keep all air openings in heater clear, free of debris or
any blockage. This will ensure that enough air for proper
combustion enters the heater.
4. If heater shuts off, do not relight until you provide fresh,
outside air. If heater keeps shutting off, it requires
servicing.
5. Turn off and let cool before servicing. Only a qualified
service person should service and repair heater.
**Operating heater above elevations of 4,500 feet could cause pilot/ODS to shutdown heater.**
CONTENTS
WARNINGS 2 ........................................................................
SPECIFICATIONS 3 .................................................................
PRECAUTIONS 3 ....................................................................
IGNITION SYSTEM BATTERY INSTALLATION .......................4
DETERMINING THE TYPE
OF HEATER LOCATION SPACE 5 .........................................
INSTALLATION 6 ...................................................................
FASTENING HEATER TO WALL 7 ............................................
FLOOR MOUNTING AWAY FROM WALL 8 .............................
CONNECTING TO GAS SUPPLY 8 ...........................................
OPERATING YOUR HEATER ............................................... 10
CLEANING AND MAINTENANCE .......................................11
TROUBLESHOOTING ........................................................ 14
PARTS LIST AND DIAGRAM .............................................. 17
WARRANTY .................................................................... 20
MODEL HSSVFRD20NGBT HSSVFRD30NGBT HSSVFBF30NGBT HSSVFBF20NGBT
BTU (Available) 20,000 30,000 20,000 30,000
Type of Gas Natural Gas Only Natural Gas Only Natural Gas Only Natural Gas Only
Ignition Battery igniter (1-AA) Battery igniter (1-AA) Battery igniter (1-AA) Battery igniter (1-AA)
Manifold Pressure 4.5 Inches of Water 4.5 Inches of Water 4.5 Inches of Water 4.5 Inches of Water
Inlet Gas Pressure (Maximum) 14 Inches of Water 14 Inches of Water 14 Inches of Water 14 Inches of Water
Inlet Gas Pressure (Minimum) 7 Inches of Water 7 Inches of Water 7 Inches of Water 7 Inches of Water
Electrical Rating /Blower* 120V, 60Hz , 1 120V, 60Hz , 1 120V, 60Hz , 1 120V, 60Hz , 1
Thermostatic Control Yes Yes Yes Yes
Clearances: inches (mm)
Top 36” (91.4cm) 36” (91.4cm) 36” (91.4cm) 36” (91.4cm)
Sides 10” (25.4cm) 10” (25.4cm) 10” (25.4cm) 10” (25.4cm)
Floor (min to top of carpet) 3” (76.2cm) 3” (76.2cm) 3” (76.2cm) 3” (76.2cm)
Fabric / ammable objects 36” (91.4cm) 36” (91.4cm) 36” (91.4cm) 36” (91.4cm)
6. Do not run heater:
• Where flammable liquids or vapors are used or stored
• During dusty conditions.
7. Before using furniture polish, wax, carpet cleaner or
similar products, turn heater off. If heated the vapors
from these products may create a white powder residue
within burner box or on adjacent walls or furniture.
8. Do not use heater if any part has been underwater.
Immediately call a qualified service technician to inspect
the room heater and to replace any part of the control
system and any gas control which has been underwater.
9. Operating heater above elevations of 4,500 feet
could cause pilot/ODS to shutdown heater.
DANGER: Carbon monoxide poisoning may lead to death.
Carbon Monoxide Poisoning:
Early signs of carbon monoxide poisoning resemble the
flu, with headaches, dizziness, or nausea. If you have these
signs, the heater may not be working properly. Get fresh
air at once! Have heater serviced. Some people are more
affected by carbon monoxide than others. These include
pregnant women, persons with heart or lung disease or
anemia, those under the influence of alcohol, and those at
high altitudes.
Natural Gas:
Natural gas is odorless. An odor making agent is added to
natural gas. The odor helps you detect a natural gas leak.
However, the odor added to the gas can fade. Gas may
be present even though no odor exists. Make certain you
read and understand all warnings. Keep this manual for
reference. It is your guide to safe and proper operation of
this heater.
* If Equipped
